- Page 1 4VR 400 HOSES Do not sterilize ENG INSTRUCTIONS FOR USE. Other languages available on https://dental.bienair.com/IFU Rx Only REF 2100037-0001/2022.10...
- Page 2 Devices HOSE 4VR 400 GREY REF 1600397-001 Optional accessories COUPLING SOCKET B B-MX2 MAINT SPRAYNET® (BOX OF 6 CANS) REF 1300753-001 REF 1600036-006 REF 2100037-0001/2022.10 HOSE 4VR 400 • © Bien-Air Dental SA...
-
Page 3: Table Of Contents
Table of contents formation 1 Symbols 5.2 Cleaning 1.1 Description of symbols used 5.3 Rinsing 2 Identification & Intended Use 5 5.4 Drying 2.1 Identification 5.5 Packing and storage 2.2 Intended use 5.6 Servicing 2.3 Intended patientpopulation 6 Transport & disposal 2.4 Intended user 6.1 Transport 2.5 Use environment... -
Page 4: Symbols
ENG INSTRUCTIONS FOR USE 1 Symbols 1.1 Description of symbols used Symbol Description Symbol Description Manufacturer.. Catalogue number. Consult instructions for use or consult electronic CE Marking with number of the notified body. instructions for use. WARNING: hazard that could result in serious injury or damage to the device if the safety instructions MedicalDevice. -
Page 5: Identification & Intended Use
2 Identification & 2.5 Use environment Intended Use Professional healthcare facility en- vironment. 2.1 Identification 2.6 Intended medical Medical devices manufactured by Bien- conditions Air Dental SA. General dentistry which includes res- torative dentistry, dental prophylaxis, Type: orthodontics and addresses the main- Hose with a short and rotating coupling, tenance or reestablishment of dental ensuring easy use of the MC3 mi-... -
Page 6: User And Patient Safety: Warnings And Precautions For Use
To prevent any risk of infection, the Electrical safety in conformance with warning below must be observed: IEC 60601-1 can only be claimed when the device is used with Bien-Air Dental compatible devices (drive motors and WARNING motors). In addition, only medical... - Page 7 To prevent any material damage the cautions below must be observed: CAUTION Do not use the hose to pull the unit or the cart. This misuse could damage the internal wires and/or the external sheath. It is essential to use dry, purified compressed air in the dental unit in order to ensure the long work- ing life of the device.
-
Page 8: Description
They may not give rise to any claim. The original language of those instructions for use is English. For any further information, please contact Bien-Air Dental SA at the address given on the back cover. -
Page 9: Assembly And Preparation
Move in the direction indicated. direction indicated. 1. To connect the motor to 4VR400 Bien-Air Dental hoses, remove the sleeve from the motor by pushing it (FIG. 2a). 2. Check that the rear of the motor and the joint on the hose are clean. Position the motor and its proprietary hose as shown in FIG. 2b. -
Page 10: Assembly
FIG. 4 4.3 Assembly FIG. 4 Preserve the initial alignment of the wires and tubes. Place the metal re- inforcement ring (9) in the chucking zone (FIG. 4a). The securing cord (8) must be attached to the chassis of the unit or table-top device to avoid any traction on the wires and tubes (FIG. 4b). -
Page 11: Installing The Socket In The Unit
4.4 Installing the socket in the unit FIG. 5-8 Drilling for the wall Ø 18 mm ± 0.2 Machine a countersink for the catch FIG. 5. Tighten nut (150 Ncm maximum) Minimum wall thickness 1.5 mm Maximum wall thickness 6 mm Quick connector on unit side only for Ø 18 mm hole, with rotation prevention notch. - Page 12 FIG. 9 Installing the hose on the unit: The dot engraved on the rear cover of the hose should be aligned with the contra- angle tool fitted on the MC3 motor (FIG. 9). Accessories: Quick connector on unit side only for Ø 18 mm hole, with rotation prevention notch.
-
Page 13: Technical Data
4.5 Technical data CAUTION These hoses are not suitable for pressure higher than 5 bar (500 kPa, 72 psi). Standard length 1.70 m Note : See the technical data of the micromotor MOT MC3 (REF 1600680-001), MOT MC3 LK (1600077-001) or MOT MC3 IR (REF 1600071-001) for more information. 4.6 Classification Class IIa in accordance with the European Medical Regulation (EU) 2017/745. -
Page 14: Maintenance And Servicing
5 Maintenance and servicing 5.1 Maintenance – General information CAUTION Non-sterilizable. Never submerge the hose in disinfectant solutions (the connectors should never be completely submerged). Do not use an ultrasonic cleaner. 5.2 Cleaning Clean with a clean cloth moistened with either tap water, sterile demineralized (de- ionized) water or any appropriate product for dissolving protein and blood residues. -
Page 15: Servicing
5.6 Servicing Bien-Air Dental SA recommends that the user change the hose every two years. CAUTION Never disassemble the device. For any inquiry, contact your regular supplier or Bien-Air Dental service centre. 6 Transport & disposal 6.1 Transport Transport conditions Temperature range: -20°C —... -
Page 16: General Information
The warranty period is: 12 months from the date of invoicing. In the event of justified claim, Bien-Air Dental or its authorised representative will fulfil the company’s obligations under this guarantee by repairing or replacing the product free of charge. - Page 17 Tel. +41 (0)32 344 64 64 Fax +41 (0)32 344 64 91 dental@bienair.com Other addresses available at www.bienair.com Bien-Air France Sàrl 19-21 rue du 8 mai 1945 94110 Arcueil France REF 2100037-0001/2022.10 HOSE 4VR 400 • © Bien-Air Dental SA...
