  • Page 1 TECHNICAL MANUAL SIMPLEBUS2 Simplebus2 Audio System...

  • Page 2: Table Of Contents

    • any purpose other than the intended use, • failure to observe the indications and warnings contained in this Manual / Instruction sheet. Comelit Group S.p.A. reserves the right to change the information provided in this Manual / Instruction Sheet at any time and without prior notice.

  • Page 3: System Functions

    1210A CA2100P CA2100P UT2010 UT2010 Operating distances A MAX B MAX C MAX Comelit Art. 4577/4579 1 260 m 130 m 130 m mm² (Ø 1.2 mm AWG 17) (850 feet) (425 feet) (425 feet) UTP5 cat. 5 0.2 mm²...

  • Page 4: Maximum System Expansion

    Maximum system expansion Devices 6751W 2738W 2738W/A 2719W Maximum number of door-entry phones that can be powered from art. 1210A Call repetition devices that can be used 1229A 1229A 1229A With the Ciao entrance panel, the system can manage up to 72 users by connecting to MAX 100 door-entry phones for every riser Maximum expansion per apartment Devices...

  • Page 5: Wiring Diagrams

    Wiring diagrams Apartment block door-entry phone system 6751W Apartment 5 6751W Apartment 4 2719W Apartment 3 2738W 2738W/A Apartment 2 2719W Apartment 1 1210A CA2100P UT2010 + CA2200P...

  • Page 6: Variant With Ciao Entrance Panel

    AUDIO DOOR-ENTRY SYSTEM RISER 6751W 6751W 2738W 2719W 2738W/A 2719W 230V 34-35 Vdc 34-35 Vdc 1210A 32-34 Vdc R GND NO NC UT2010 UT9200 (MAX 8) Max 20 m. Local door-opener button. For configurations other than those indicated in the diagram, refer to the full manual for product number UT2010. Variant with Ciao entrance panel 1210A CA2100P...

  • Page 7: System With 2 Main Entrances

    System with 2 main entrances 6751W 6751W 2719W 2738W 2738W/A 2719W 1404 1210A 1210A UT2010 UT2010 1404 1 2 3 4 1 2 3 4 1 2 3 4 230V 230V 1210A 1210A R GND R GND NO NC NO NC UT2010 UT9200 UT2010...

  • Page 8: System With 2 Risers, One Main Entrance And N Secondary Entrances

    System with 2 risers, one main entrance and n secondary entrances 6751W 6751W 6751W 6751W 2719W 2719W 2738W 2738W 2738W/A 2738W/A 2719W 2719W 1404 1404 1210A 1210A 1210A UT2010 UT2010 UT2010 CA2100P + CA2200P 1404 1404 1 2 3 4 1 2 3 4 1 2 3 4 1 2 3 4...
  • Page 9 C E R T I F I E D M A N A G E M E N T S Y S T E M S w w w . c o m e l i t g r o u p . c o m Via Don Arrigoni, 5 - 24020 Rovetta (BG) - Italy...
