Seats and Seat Belts
Overview
Your occupant restraint system has been developed and tested specifically for Utilimaster delivery
vehicles. The high usage associated with delivery vehicle application and exposure of this seat belt to
severe environmental conditions make it crucial to inspect the seat belt system regularly. The seat belt
system must be inspected during every routine maintenance.
A seat belt system should be replaced immediately if it shows any problems, such as cuts; fraying;
extreme or unusual wear; significant discoloration due to ultraviolet exposure; significant dirt; abrasion
to the seat belt webbing; or damage to the buckle, latch plate, retractor, or hardware.
Replace the seat belt only with a belt recommended by Utilimaster. If any part of the seat belt
requires replacement, the entire belt must be replaced.
An installation guide is attached to every replacement belt. If the seat belt is replaced, all components
must be mounted back in the same position as the original components. This will maintain the design
integrity of the mounting points for the seat belt assembly.
The information in this document is generic. Images and procedures may differ from
those for vehicles you are servicing. Because Utilimaster manufactures customized
vehicle solutions, this document cannot list and illustrate every possible option for every
vehicle. The most common body options are described here. Use this information as a
guideline.
03103436-A10015 Rev. C
Aeromaster
July 16, 2021
Service
Guide
1 of 11

Advertisement

loading
Need help?

Need help?

Do you have a question about the Aeromaster and is the answer not in the manual?

Questions and answers

Related Manuals for Utilimaster Aeromaster

Summary of Contents for Utilimaster Aeromaster

  • Page 1 Replace the seat belt only with a belt recommended by Utilimaster. If any part of the seat belt requires replacement, the entire belt must be replaced.
  • Page 2 Read vendor instructions carefully. Failure to install and inspect can result in injury or death of user. Do NOT remove cardboard spacer until the retractor is mounted. The retractor must be mounted at the proper angle before web will freely extend.
  • Page 3 D-LOOP UPPER SEAT BACK LOWER JUMP SEAT SEAT BELT BUCKLE RETRACTOR Bulkhead-mounted jump seat overview 3 of 11 03103436-A10015 Rev. C July 16, 2021...

  • Page 4: Maintenance

    Maintenance Belts must be inspected during every routine maintenance. Failure to properly inspect and maintain the seat belts can cause serious injury or loss of life. The seat belt in a delivery vehicle application has a finite life and must be replaced as needed throughout the life of the vehicle. Whenever a vehicle is involved in an accident, the entire seat belt system must be evaluated for replacement, even if there is no visible wear or damage to the seat belt system.
  • Page 5 Pedestal Seat Belt Replacement The outboard side refers to the side closest to the door. The inboard side is the side toward the center of the vehicle. When a seat belt is replaced, both halves must be replaced. Use the new mounting hardware furnished with the replacement belt. Do NOT use old hardware when installing replacement seat belts.

  • Page 6: Seat Belt Installation

    Seat Belt Installation The retractor must be located in the proper position on the bracket for the seat belt web to extract and function properly. When a seat belt is replaced, both halves must be replaced. 1. Mount the seat belt D‑Loop in the existing hole in the seat belt mounting bracket.
  • Page 7 Jump Seat Belt Installation Do NOT remove the cardboard spacer until the retractor is mounted and seat belt is fully installed; otherwise the belt will retract and bind. 1. Remount the seat belt D-Loop using the existing hole in the bulkhead. 2.

  • Page 8: Pedestal Installation

    Pedestal Seat Replacement Seat Removal 1. Remove and retain the (4) nuts and washers attaching the seat to the pedestal. 2. Pull the seat off the pedestal. SEAT STUD SEAT STUD WASHER WASHER LCK WASHER LCK WASHER 5/16 NUT 5/16 NUT PEDESTAL PEDESTAL Seat to pedestal fasteners...
  • Page 9 Shield Jump Seat Replacement 5/16 NUT 5/16 NUT 1/2-13 BOLT 1/2-13 BOLT WASHER WASHER Jump Seat Removal 1. From the cargo area, brace the two‑way 5/16 locknuts attaching the jump seat back and remove the bolts attaching the back to the bulkhead. Discard fasteners. 2.
  • Page 10 Jump Seat Replacement BACK PAD BACK PAD 1/4-20 SCREW 1/4-20 SCREW 3/8-16 BOLT 3/8-16 BOLT WASHER WASHER Jump Seat Removal 1. Remove the locknuts attaching the jump seat wall mount and discard the 3/8‑16 fasteners. 2. If replacing jump seat back pad, remove 1/4‑20 screws from the cargo side. Jump Seat Installation 1.
  • Page 11 No part of this document may be photocopied, reproduced, or translated to another language without the prior written consent. Utilimaster® is a registered trademark of The Shyft Group, Inc. All other products or name brands mentioned in this document are trademarks of their respective owners.
