Combined Lift & Leveler System
This Manual Covers DUAL-DOKs
C78008 and up
PRINTED IN U.S.A.
RITE-HITE
PRINT SHOP
DUAL-DOK
Owners Manual
®
Built After Serial Numbers:
®
2200
LEVELER
END LOADING
• To position for below dock
endload, Push and release
"RAISE" button.
• To store from below dock
endload, Push and
immediately release (pulse)
"RAISE" button.
MOMENTARY
PAUSE
Push and hold "MOMENTARY PAUSE"
to pause any movement of platform
and lip. Release to continue operation.
MANUAL/RESET
Press "MANUAL/RESET" button to reset
DUAL-DOK after a fault has been cleared at
dock height. If a fault has been cleared below
dock height, press "MANUAL/REST" button and
corresponding manual function button to move
unit to dock height.
OUTSIDE LIGHT
• Outside light is on when LED flashes.
• Check outside lights is both LEDs are off.
• The outside light switch must be
turned to RED to operate the system.
WARNING
Do not turn switch to GREEN unit
loading/unloading is complete.
1. Do not operate leveler with anyone standing on or in front of leveler.
2. Do not operate in any mode with anyone standing under or in front of leveler.
3. Never enter a truck/trailer until its brakes are set, air has been dumped from air ride suspension (if applicable), and you have visually inspected to be sure truck/trailer is
securely held in place by a vehicle restraint or wheel chock per OSHA regulations.
MILWAUKEE, WISCONSIN 1-800-456-0600
F1
F2
F3
F4
LIFT
LEVELER RAISE
LIFT UP
AUTO-LIP
Platform
Verify that the platform is at dock height and that no load is on
Push to raise lift.
platform. Push to Raise platform.
LIP EXTEND
LIFT DOWN
• In Auto-Lip mode, lip
automatically extends
Lip
whenever the "DOWN" button
is pushed.
• To engage Auto-Lip, push
and release "AUTO-LIP"
button with platform at dock
height.
• To cancel Auto-Lip, push and
relase "AUTO-LIP" button
Push both to extend lip. Release both to lower leveler onto trailer.
with platform at dock height.
Push to lower lift.
• To change unit to Lift Mode, push and release "DOWN" button with no
load on platform.
• Do not place load on plaftorm unless unit is in Lift Mode.
MANUAL FUNCTIONS
• When lift operations are complete, always return platform to dock height.
Leveler Raise: Disengage Pins
Push and release leveler "RAISE" button to change unit to Leveler Mode.
Lip Extend: Extend Lip
Auto-Lip: Unlock Velocity Fuse
A pulsing horn indicates that the platform has been below dock for 15
Lift Up: Raise Lift
minutes.
Lift Down: Lower Lift
WARNING
ADDITIONAL WARNINGS AND INSTRUCTIONS ON SIDE OF ENCLOSURE
COMBINED LIFT & LEVELER SYSYEM
MADE IN U.S.A.
PUBLICATION NO. 1290
PART NUMBER: 134072
JANUARY 2010
R
R
