Weight Limit: Bed: 450 Lb / 204 Kg
KT. - 2020/6/8
© 2014 Dorel Home Products All Rights Reserved
4447929CL(Green) 4450029CL(Black)
Thank you for purchasing from DHP!
DO NOT RETURN TO THE STORE !
If parts are missing or damaged, we will gladly ship your
replacement parts free of charge.
Visit www.dhpfurniture.com/eng/replacement-parts
or call Toll-Free 1-800-267-1739
Date of Purchase
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY
INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
4453329CL(Ivory)
Upholstered Bed
Lot Number
B344447929CL00
Full
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 4447929CL and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Dorel Home Products 4447929CL

Summary of Contents for Dorel Home Products 4447929CL

  • Page 1 Visit www.dhpfurniture.com/eng/replacement-parts or call Toll-Free 1-800-267-1739 Date of Purchase Lot Number THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE. KT. - 2020/6/8 B344447929CL00 © 2014 Dorel Home Products All Rights Reserved...

  • Page 2: Limited 1-Year Warranty

    Limited 1 year Warranty Read Before Beginning Assembly DHP warrants this product to be free from defects in material and workmanship ● Work in a spacious area and near where the unit will be used, preferably on a and agrees to remedy any such defect. This warranty covers one year from the carpet, or use a piece of the cardboard packaging to protect your floor and product.
  • Page 3 Parts Replacement Parts, visit www.dhpfurniture.com/eng/replacement-parts This item is packed in 2 boxes! All parts listed on this page are in Box A. If Box B is missing please contact your Retailer. There are inner box(es) that include components required to complete this assembly. Headboard Support Leg Wooden Slats...
  • Page 4 Parts Replacement Parts, visit www.dhpfurniture.com/eng/replacement-parts This item is packed in 2 boxes! All parts listed on this page are in Box B. If Box A is missing please contact your Retailer. There are inner box(es) that include components required to complete this assembly. Footboard Side Panel Side Rail...
  • Page 5 Parts IMPORTANT: Below part numbers list is unique to your product. Replacement Parts, visit www.dhpfurniture.com/eng/replacement-parts Please keep it on hand when calling for replacement parts. Part number 4447929CL(Green) 4450029CL(Black) 4453329CL(Ivory) T982410 T982480 T982510 T982420 T982490 T982520 T982430 T982500 T982530 T982440...

  • Page 6: Hardware Pack

    Hardware Pack Hardware Pack #: T4447929CL-00 1/4" X 3/4" X 29 1/4" X 1 3/16" 1/4" X 1 9/16" Please do not completely tighten all the hardware, until the entire assembly is complete, unless otherwise indicated in the step-by-step instructions. The screw(s), bolt(s) to be used at each step are shown in actual size in the lower right corner of the page.
  • Page 7 Step 1 Attach E to C with Repeat the same step for remaining parts E and C. The slat holes on part E should be facing upward. X 12...
  • Page 8 Step 2 Small holes of slot on S and T should Attach S and T to C with be facing upward. Repeat the same step for remaining parts C, S and T. X 12...
  • Page 9 Step 3 Attach Z x 4 and H x 4 to A and B.
  • Page 10 Step 4 Do not completely tighten the Screw into A and into B, leave half BOLTS, leave half of the thread of the thread exposed. exposed.
  • Page 11 Step 5 Hang sub-assembly C on A and B as illustrated, don't completely tighten the bolts until STEP 8 is complete.
  • Page 12 Step 6 Attach L x 2 to F with...
  • Page 13 Step 7 Attach F to A and B with...
  • Page 14 Step 8 Attach G to E x2 and F with Then properly tighten all the bolts.
  • Page 15 Step 9 9.1 Insert P into X, 9.2 Press X into E, repeat the same procedure for the opposite side of the bed with a new P and X . 9.3 Insert ends of both P into Y, then press Y into F as illustrated.

  • Page 16: Helpful Hints

    Helpful Hints CAUTION: This unit is intended for use only with the products and/or maximum weights indicated. Use with other products and/or products heavier than the maximum weights indicated may result in instability or cause possible injury. ● Move your new furniture carefully, with two people lifting and carrying the unit to its new location.
  • Page 17 4447929CL(Verde) 4450029CL(Negro) ¡NO LO REGRESE A LA TIENDA! 4453329CL(Marfil) Si le faltan piezas o las que se incluyen están dañadas, con mucho gusto le enviaremos sus piezas de reemplazo sin Cama Tapizada cargo extra. Visite www.dhpfurniture.com/spa/replacement-parts Matrimonial o llame gratis al 1-800-267-1739 Fecha de compra Número de lote...
  • Page 18 También confirme que ha recibido todos los componentes necesarios para el real en la esquina inferior derecha de cada página. ensamblaje al compararlos con la tabla de piezas indicadas en la sección en inglés. Número de pieza 4447929CL(Verde) 4450029CL(Negro) 4453329CL(Marfil) T982410 T982480...

  • Page 19: Consejos Útiles

    Instrucciones Límites de peso: 450 Lb / 204 Kg Paso 1 Consejos útiles Una la parte E con C con los . Repita el paso para las othas partes E y C. Paso 2 • Mueva sus muebles nuevos con cuidado, se requiere de dos personas para Una la parte S y T con C con los .

  • Page 20: Informations Sur La Garantie

    4447929CL(Vert) 4450029CL(Noir) NE PAS RETOURNER CE PRODUIT AU MAGASIN ! Si une pièce est manquante ou endommagée, nous vous 4453329CL(Ivoire) expédierons avec plaisir vos pièces de remplacement Lit Rembourrée gratuitement. Visitez www.dhpfurniture.com/fre/replacement-parts Lit deux places ou appelez au 1-800-267-1739 Date d'achat Numero de lot CE FEUILLET CONTIENT DES INFORMATIONS DE SÉCURITÉ...
  • Page 21 à l'assemblage en les comparant avec le tableau des pièces (illustrations disponibles dans la section en anglais). Número de pieza 4447929CL(Vert) 4450029CL(Noir) 4453329CL(Ivoire) T982410 T982480...

  • Page 22: Conseils Utiles

    Instructions Limite de Poids: 450 Lb / 204 Kg Étape 1 Conseils utiles . R é p étez la m ême étape pour les autres E y C. Attacher E et C avec • Étape 2 Déplacez votre nouveau mobilier avec soin, nous recommandons deux Attacher S à...
