4 POST
MODEL
MODEL:
FPA12144 (Alignment) / FPF12144 (Service)
(12000 LB.)
READ and SAVE THIS
INSTRUCTION MANUAL
MAY 2012 REV.-
6-2616

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FPA12144 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Hofmann FPA12144

  • Page 1 4 POST MODEL MODEL: FPA12144 (Alignment) / FPF12144 (Service) (12000 LB.) READ and SAVE THIS INSTRUCTION MANUAL MAY 2012 REV.- 6-2616...
  • Page 2: Owner / Employer Obligations

    1.0  OWNER / EMPLOYER OBLIGATIONS  1. The Owner/Employer shall ensure that lift operators are qualified and that they are  trained in the safe use and operation of the lift using the manufacturer’s operating  instructions; ALI/SM 93‐1, ALI Lifting it Right safety manual; ALI/ST‐90 ALI Safety Tips  card; ANSI/ALI ALOIM‐2008, American National Standard for Automotive Lifts ‐ Safety  Requirements for Operation, Inspection and Maintenance, Appendix A (Operator  Training Log); ALI/WL Series, ALI Uniform Warning Label Decals/Placards; and in the case  of frame engaging lifts, ALI/LP‐GUIDE, Vehicle Lifting Points/Quick Reference Guide for  Frame Engaging Lifts.  2. The Owner/Employer shall establish procedures to periodically inspect the lift in  accordance with the lift manufacturer’s instructions or ANSI/ALI ALOIM‐2008, American  National Standard for Automotive Lifts ‐ Safety Requirements for Operation, Inspection  and Maintenance, Appendix B and Appendixes C through F; and the Employer shall  ensure that the lift inspectors are qualified and that they are adequately trained in the  inspection of the lift.  3. The Owner/Employer shall establish procedures to periodically maintain the lift in  accordance with the lift manufacturer’s instructions or ANSI/ALI ALOIM‐2008, American  National Standard for Automotive Lifts ‐ Safety Requirements for Operation, Inspection  and Maintenance, Appendix G (Planned Maintenance Log); and the Employer shall  ensure that the lift maintenance personnel are qualified and that they are adequately  trained in the maintenance of the lift.  4. The Owner/Employer shall maintain the periodic inspection and maintenance records  recommended by the lift manufacturer’s instructions or ANSI/ALI ALOIM‐2008, American  National Standard for Automotive Lifts ‐ Safety Requirements for Operation, Inspection  and Maintenance  5. The Owner/Employer shall display the lift manufacturer’s operating instructions; ALI/SM  93‐1, ALI Lifting it Right safety manual; ALI/ST‐90 ALI Safety Tips card; ANSI/ALI ALOIM‐ 2008, American National Standard for Automotive Lifts ‐ Safety Requirements for  Operation, Inspection and Maintenance; ALI/WL Series, ALI Uniform Warning Label  Decals/Placards; and in the case of frame engaging lifts, ALI/LP‐GUIDE, Vehicle Lifting  Points/Quick Reference Guide for Frame Engaging Lifts in a conspicuous location in the  lift area convenient to the operator.  6. The Owner/Operator shall provide necessary lockout/tagout means for energy sources per  ANSI Z244.1‐1982 (R1993), Safety Requirements for the Lockout/Tagout of Energy ...
  • Page 3: Important Safety Instructions

    2.0 IMPORTANT SAFETY INSTRUCTIONS  When using this lift, basic safety precautions should always be followed, including the following:    1. Only trained and authorized personnel should operate the lift or rolling jacks. Do not allow  customers or bystanders to operate the lift or be in the shop area while lift is in use.  2. Read all instructions in this manual and on the lift. Thoroughly train all employees in the use and  care of lift and rolling jacks.  3. Inspect lift daily.  Do not operate if it malfunctions or problems have been encountered.  4. Ensure no one is standing in front or behind the lift while vehicle is being driven onto, or backed  off the lift.  5. Before driving vehicle on, make sure lift is in the fully down position.  6. Before removing the vehicle from the lift, make sure the lift is in the fully down position and  ensure that all tools have been removed from the deck surfaces.  7. Always raise the lift off safety locks before lowering.  8. Do not allow rear tires or portion of the vehicle to interfere with approach ramp.  9. Be sure front wheel stops are always installed on the lift.  10. Never allow front wheels to strike the front wheel stops.  11. Do not permit employees or customers on lift when it is either being raised or lowered.  12. Never raise vehicle with passengers inside.  13. Always stand clear of lift when raising or lowering and observe “Pinch points” warning.  14. Before lowering the lift, check area for any obstructions    15. Never attempt to overload the lift.  The manufacturer’s rated capacity is shown on the  identification label on the power side column.  16.
  • Page 4: Table Of Contents

    TABLE OF CONTENTS                PAGE  OWNER / EMPLOYER OBLIGATIONS  ................ 2     IMPORTANT SAFETY INSTRUCTIONS ............... 3     GENERAL SPECIFICATION .................. 6     TOOLS REQUIRED FOR INSTALLATION .............. 6     CONTENTS ....................... 7     GENERAL LIFT SPECIFICATIONS ................ 8     INSTALLATION INSTRUCTIONS ................ 9     CHALK LINE LAYOUT .................. 9     FRONT AND REAR CROSSMEMBER ASSEMBLY .......... 11     SHEAVE INSTALLATION  ................... 12  ...
  • Page 5 CABLE BREAK SAFETY MECHANISM ............... 30     AIR CYLINDERS, AIR LINES, VALVE AND FITTINGS .......... 30     HYDRAULIC POWER PACK AND HOSE ............ 30     HYDRAULIC CYLINDER .................. 31     8.10 RUNWAYS ....................... 31     8.10.1 CHECK RUNWAYS .............. 31     8.10.2 INSPECT JACK BEAM TRACKS ............ 31     8.11 COLUMNS ....................... 31     8.11.1 CHECK COLUMNS .............. 31     8.11.2 CHECK COLUMN ANCHORS ............ 31     8.12 APPROACH RAMPS, CHOCKS, FRONT WHEEL STOPS ........ 32     8.13 FRONT AND REAR STEER PLATES ...
  • Page 6: General Specification

    3.0 GENERAL SPECIFICATION    Maximum Capacity:  12000 lbs.  5443 kg  Overall Length:  235”  5969mm  Overall Width:  137”  3480mm  Down Position Height:  9.5”  241mm  Maximum Lifting Height:   71”  1803mm  Maximum Wheel Base:  144”  3658mm  Rise Time:  60 Seconds    Power Rating:  230 Volts AC, 1Ph., 20 Amp, 60Hz.    Air Requirements:  90‐120 psi Shop Air  Shipping Weight:  3450 lbs.  1565kg    CHECK CONTENTS OF ACCESSORY BOX WITH THE PACKING LIST ENCLOSED 4.0  TOOLS REQUIRED FOR INSTALLATION ...
  • Page 7 ATTENTION! This lift is intended for indoor installation only. It is prohibited to install this product outdoors. Operating environment temperature range should be 41 – 104 °F (5 – 40 °C). Failure to adhere will result in decertification, loss of warranty, and possible damage to the equipment.
  • Page 8: General Lift Specifications

    6.0 GENERAL LIFT SPECIFICATIONS    Figure 1    8 of 44...
  • Page 9: Installation Instructions

    7.0  INSTALLATION INSTRUCTIONS    PLEASE TAKE THE TIME TO READ THESE INSTRUCTIONS COMPLETELY.  A QUICK CHECK OF  THE CONTENTS OF THE ACCESSORY BOX WOULD ALSO DECREASE THE OVERALL TIME OF THE  INSTALLATION.     Gather the tools and materials required for the installation.     Select the location best suited for your lift.    NOTE:  In determining lift area check for the following:     Ease of driving a vehicle on and off the lift.     Overhead obstructions, low ceiling height, overhead doors, overhead heaters, etc.     Floor obstructions, uneven floor in lift area, floor drains, work benches, electrical   in floor, etc.     An outline matching the dimensions listed below will need to be marked on the floor.   Refer to Figure 2 for outline dimensions.  Refer to General Lift Specifications for overall lift  dimensions.  Figure 1.    7.1 CHALK LINE LAYOUT      Figure 2      9 of 44...
  • Page 10 Refer to Figure 2.  Make a chalk line parallel to the doorway at least 246 inches in from the doorway.   This will be the furthest front face of the front post location.  Call this line “A”.  Determine the center of  the doorway and bay.  Make a centerline to intersect with line “A”.  Measure from the centerline along  line “A” 60 1/4 inches in both directions.  This will be the location of the inside face and front face of the  front posts.  Measure back from this line “A”      179 1/2 inches.  Make a chalk line parallel to line “A”.   Call this line “B”.  This will be the location for the back face of the rear posts.  Measure from the  centerline along line “B” 60 1/4 inches in both directions.  This will be the location of the inside face and  back face of the rear posts.  Position work stands inside of line “A” and “B” of outline, to support the  front and rear of each deck assembly.    IMPORTANT    NOTE:  To determine the front, rear, left side and right side of the decks check                  the following:     The left deck has the hydraulic cylinder mounted to its underside.  The rear of the decks  have approach ramp brackets to install the drive on approach ramps.  The work steps,  attached to the turn plate pocket cutouts will face towards the front outside of the lift.     Position decks on work stands.    NOTE:  To determine the front and rear crossmember assembly see Figure 3, and check                       the following:     The front crossmember assembly will have two (2) small openings for the cable routing.   The openings will face the rear of the lift.     The rear crossmember assembly will have one (1) small opening and one (1) larger opening  for cable routing.  These openings will face the front of the lift.     The crossmember assemblies are fully assembled and the PULLEYS DO NOT NEED TO BE  REMOVED FOR CABLE INSTALLATION.  ALIGN CROSS‐MEMBER ASSEMBLIES SO THAT THE  DIAGONALS MEASURE WITHIN HALF AN INCH SQUARE.   ...
  • Page 11: Front And Rear Crossmember Assembly

    7.2   FRONT AND REAR CROSSMEMBER ASSEMBLY      Figure 3        CABLE AND ROUTING IN CROSSMEMBER ASSEMBLY TYPICAL        Figure 4      11 of 44...
  • Page 12: Sheave Installation

    7.3   SHEAVE INSTALLATION      Figure 5    12 of 44...
  • Page 13: Cable Installation

    7.4 CABLE INSTALLATION     Locate cables and set out on the floor.  Check the part numbers located on each stud of  each cable.      CABLE #1...PART #2‐0643  (318”LG. ‐ L.F.)    CABLE #2...PART #2‐0644  (151”LG. ‐ L.R.)    CABLE #3...PART #2‐0645  (203”LG. ‐ R.R.)    CABLE #4...PART #2‐0646  (367”LG. ‐ R.F.)    NOTE:  THE PULLEYS (SHEAVES) ON THE CROSSMEMBERS DO NOT HAVE TO BE REMOVED FOR CABLE  INSTALLATION.  A 3/8” ‐ 16 UNC  2 3/4” LG. HEX HEAD BOLT MUST BE REMOVED FROM THE  CROSSMEMBERS TO ALLOW CABLE INSTALLATION AROUND THE PULLEYS.  THIS 3/8” ‐ 16  UNC  2 3/4” LG. HEX HEAD BOLT MUST BE REINSTALLED     AFTER THE CABLES ARE ROUTED  THROUGH THE CROSSMEMBER ASSEMBLIES.    WARNING!!!  DO NOT APPLY LUBRICANT TO SHEAVE ASSEMBLY.  FIBRE BUSHING IS PTFE SELF‐ LUBRICATING.  THE ADDITION OF LUBRICANT WILL SHORTEN THE LIFE OF THE FIBRE  BUSHING.      Before beginning cable routing, refer to Figure 4 Cable and Routing Diagram.     Begin routing cable #4 (part #2‐0646) from the right side of the front crossmember  assembly using the non threaded end of the cable as described in Figure 4, and out  through the opening under the front of the right deck.     CHECK FOR CORRECT ARRANGEMENT OF SPACERS ON SHEAVE STACKS, FIGURE 5.    ...
  • Page 14 NOTE:  Similar arrangement for sheave stack.  Right deck rear spacer sizes are not equal ‐  larger goes on top of stack.     Continue to pull cable #4 over the center support of the right deck.     Begin routing cable #3 (Part # 2‐0645) from the right rear crossmember assembly using  the non threaded end of the cable as described in figure 4, and out through the  crossmember assembly to the opening under the rear of the right deck.    TIP:  TAPE THE TWO CABLES TOGETHER, CABLE #3 ON TOP OF CABLE #4.  THIS WILL KEEP THE TWO  CABLES FROM TWISTING IN THE REAR CROSSMEMBER ASSEMBLIES.     Continue to feed cables #3 and #4 through the rear crossmember assembly and out of the  opening under the rear of the left deck.     Install the sheave into the rear of the right deck as shown in figure 5.     Route cable #2 (Part # 2‐0644) from the left side of the rear crossmember assembly using  the non threaded end of the cable as described in figure 4, and out through the  crossmember assembly to the opening under the rear of the left deck.     Route cable #1 (Part # 2‐0643) from the left side of the front crossmember assembly using  the non threaded end of the cable as described in figure 4, and out through the  crossmember assembly to the opening under the front of the left deck.     Install the sheave into the front of the left deck as shown in figure 5.    NOTE:  MAKE CERTAIN THAT ALL CABLES ARE IN THE RIGHT POSITIONS AND ARE NOT TWISTED.   VERIFY THAT ALL FOUR (4) OF THE 3/8”‐16 UNC          2 3/4”LG. HEX HEAD BOLTS ARE  REINSTALLED ON THE CROSSMEMBER ASSEMBLIES.   ...
  • Page 15: Power Pack Installation

    7.5 POWER PACK INSTALLATION     Bolt the power pack to the mounting bracket on the front face of the left front post using  four (4) 5/16”‐18UNC  1”LG. hex head bolts and four 5/16” lockwashers. Refer to Figure  7.      NOTE:  WHEN WORKING WITH HYDRAULIC LINES AND VALVES, IT IS IMPORTANT TO KEEP  ALL COMPONENTS CLEAN AND FREE OF DIRT.      POWER PACK DETAILS      Figure 7        15 of 44...
  • Page 16: Electrical Connections

    7.6 ELECTRICAL CONNECTIONS    CAUTION:  ALL ELECTRICAL CONNECTIONS SHOULD BE MADE BY A QUALIFIED  ELECTRICIAN.    Please refer to Figure 8, Electrical Diagram for 230 volts/1 phase electrical connections.  Electrical Breaker Size Recommendation:  20Amps    Electrical Diagram for 208‐230V/1Ph/60Hz                               Figure 8    7.7 HYDRAULIC INSTALLATION     Refer to Parts Manual, Hydraulic and Air Kit Diagram    TIP:  TAPE ONE END OF THE HYDRAULIC HOSE TO THE TWO POLYTUBES AND FEED THEM  THROUGH THE BLACK PLASTIC PIPING.  THEN REMOVE THE TAPE.     Connect 3/8” JIC, M end of the flexible hydraulic hose to the fitting at the cylinder.      DO NOT OVER TIGHTEN.     Install flow control assembly.     Attach the other end 3/8” JIC, F of the flexible hydraulic hose to the adapter fitting on the  power pack (3/8” JIC, M).    NOTE:  THE HYDRAULIC CYLINDER IS NOT EMPTY   ...
  • Page 17: Air Installations

      NOTE:  AS ROD EXTENDS, OIL FROM CYLINDER RETURNS TO POWER PACK.  RELEASE  HANDLE ON POWER PACK NEEDS TO BE HELD DOWN (OPEN) TO ALLOW OIL TO  RETURN TO POWER PACK.     Continue to extend the rod until the non‐threaded end of the cables are reached.     Remove the clamp from the cable flange.     Install the cables as shown in Figure 4, Cable and Routing Diagram.     Reinstall the clamp to the cable flange.    HYDRAULIC AND AIR KITS INSTALLATIONS     Locate the supply lines:  1/4” and 3/8” polytube, 3/8” flexible hydraulic line, and the black  plastic piping.     Install the black plastic piping to the steel pipe welded to the underside of the front left  side crossmember assembly.    7.8 AIR INSTALLATIONS     Attach the air valve assembly using two (2) #8 ‐ 32 UNC  1”lg. Phil. HD. screws to the two  (2) #8 ‐ 32 UNC hex nuts on the outside face of the left front post.    NOTE:  MOST OF THE 1/4” AND 3/8” POLYTUBE CONNECTIONS HAVE BEEN MADE IN THE  CROSSMEMBERS ASSEMBLIES AND LEFT DECK.  ONLY FINAL CONNECTIONS ARE REQUIRED TO  BE MADE.  THE 1/4” POLYTUBE WILL BE USED FOR THE AIR CYLINDER LOCKS AND THE 3/8”    POLYTUBE WILL BE USED FOR THE AIR OUTLETS TO THE JACKING BEAMS.
  • Page 18: Safety Retaining System

         Hook up an air supply to the inlet of the water trap on the air valve assembly located on  the outside of the left post.     Check for air leaks.     Check the operation of the air cylinder locks by depressing the air valve on the outside of  the left front post.     Press the “UP” button on the hydraulic ALL power pack.  Continue raising until the lift is  supported by the cables.    NOTE:  MAKE CERTAIN THAT THE MECHANICAL SAFETY LOCKS AND CABLE ROLLERS ARE WORKING    PROPERLY. 4.9  SAFETY RETAINING SYSTEM   Assemble the safety retainer bracket assemblies using the supplied hardware as shown in  Section 10.     Install one 5/16”x ¾” long hex head bolt with one 5/16” lock washer and one 5/16” flat  washer into the top mounting hole location on the crossmember but do not tighten.   Leave at least 3/16” space between the lock washer and the crossmember.     Insert the bracket assembly inside the post and slide up into place between the post and  the crossmember so that the bolt and washers slide into the upper slot.     Install the second 5/16”x ¾” long hex head bolt and 5/16” lock washer and flat washer  through the lower slot and into the bottom mounting hole in the crossmember.  Tighten  both of the bolts.  See Figure 9.    ...
  • Page 19: Leveling Procedure

    7.9 LEVELING PROCEDURE   7.9.1 LEVELING LIFT TO FLOOR   Lower the lift completely to the floor.     Determine the highest corner of the lift and adjust remaining towers to level the lift, front‐ to‐back and side‐to‐side (See positions 1, 2, 3 and 4 in Fig. 11). Use shims under tower  base plate, as needed.  7.9.2 DECK LEVELING PROCEDURE    NOTE:  Use a four (4) foot level to adjust the cables to level the decks side‐to‐side and front‐ to‐rear.  All cable adjustments can be made at the threaded end of the cable at the  top of each of the four (4) posts.     Tighten the two (2) 7/8” ‐ 14 UNF hex nuts on each cable at the top of each post.     Raise the lift to check operation.     Lower lift by depressing the air valve while pulling down on the release lever of the power  pack.     Remove hand from air valve and allow the lift to hang on the cables.     Use a four (4) foot level.  Level and square all four posts.     Begin leveling the highest post.    POST LEVELING    Figure 10   ...
  • Page 20: Leveling Procedure - Safety Ladders

    DECK LEVELING        Figure 11  (Lift may not be as shown)    NOTE:  Check and adjust the decks for level using the 4’ level.  Both the front plate cut‐outs  and rear steer plates should be checked.  7.9.3 LEVELING PROCEDURE ‐ SAFETY LADDERS    1.  After the lift has been leveled on the cables, adjust the safety racks.    2.  To check the mechanical safety locks, raise the lift up; make sure all locks engage at the  same time making one noise.  If the safeties are off slightly, gently bump the up button  until you hear the first safety lock engage.  Determine at which post the safety engaged;  adjust each of the other safety racks until you hear the safety engage.  Recheck to make  certain that the safeties are engaging together.    3.  To do this loosen the 3/8” ‐ 16 UNC  1” lg. hex bolt at the bottom back of each post and  pull safety racks up until they come into full contact with each of the   safety shoes on the  crossmember assembly.    20 of 44...
  • Page 21: Approach Ramps, Wheelstops, Pulley Covers

    4.  When level, tighten the two (2) 5/8” ‐ 11 UNC hex nuts at the top of each safety rack and  the 3/8” ‐ 16 UNC  1” lg. hex bolts at the bottom back of each post.    5.  Raise the lift to check for full operating height of 71”.  This measurement is taken from the  top of the decks to the floor.      7.10 APPROACH RAMPS, WHEELSTOPS, PULLEY COVERS      1.   Install approach ramps using ramp pins and cotter pins provided.  Ensure the proper  operation of the ramps.    2.  Install front wheel stops using six (6) 1/2” ‐ 13 UNC  1” lg. hex bolts and         1/2”  lockwashers.    3.  Install the four (4) sheave covers over the sheaves in the crossmember assembly.    4.  Cycle the lift several times to check proper operation of the cables, safety lock, air locks,  etc...        STOP IMMEDIATELY IF THE LIFT IS NOT OPERATING PROPERLY.  Adjust and recheck for  proper operation.    7.11  ANCHOR INSTALLATION     The 1/2”  4 1/2” lg. wedge anchor bolts supplied allow for the thickness of the base  plates plus a maximum of 3/4” of shim stock.  DO NOT USE ANCHORS SUPPLIED IF MORE  THAN 3/4" INCH OF SHIM STOCK IS USED.   ...
  • Page 22 ANCHOR INSTALLATION         Tighten all anchor bolts to a torque of 55 ft. lbs.     Recheck and adjust the level of post(s) and cable(s) if necessary.    NOTE:  IN CASES WHERE THE FLOOR IS EXTREMELY OUT OF LEVEL, THE MECHANICAL  SAFETIES MAY NOT ENGAGE ON THE SAME LOCK.            NOTE: THE 1/2”  4 ½” LG. WEDGE ANCHOR BOLTS SUPPLIED MUST HAVE A MINIMUM EMBEDMENT OF 2” INTO CONCRETE FLOOR. NOTE: IN CASES WHERE THE FLOOR IS EXTREMELY OUT OF LEVEL, THE MECHANICAL SAFETIES MAY NOT ENGAGE ON THE SAME LOCK.
  • Page 23: Safety And Operating Instructions

    7.12 SAFETY AND OPERATING INSTRUCTIONS    1.  Inspect your lift daily.  Do not operate it if malfunctions occur or damaged parts have  been found.    2.   Never attempt to overload the lift.  The manufacturer’s rated capacity is shown on the  serial number tag on the power post.    3.  Operating controls, DO NOT OVERRIDE the safeties.  The mechanical safeties are  designed to engage automatically on the way up.  Press the up switch of the power pack  to go up.  When the desired height is reached, lower onto the safety.  To lower, raise off  of the safety locks, then press the air release valve and the lowering release lever at the  same time.    4.  Only trained and authorized personnel should operate the lift.  Do not allow customers or  bystanders to operate the lift or be in the lift area.      5.  Caution, never work under the lift unless the mechanical safety locks are engaged.    6.  Before driving vehicle on, make sure lift is in the fully down position.    7.  Before removing the vehicle from the lift, make sure the lift is in the fully down position  and ensure that all tools have been removed from the deck surfaces.    8.  Always keep the lift area free from debris.  Grease and oil spills should always be cleaned  up immediately.  Never leave any tools or parts lying on the decks.    9.  Never operate lift with passengers in vehicle.      NOTE:  DO NOT ATTEMPT TO OPERATE THIS LIFT IF ANY PART IS NOT WORKING PROPERLY  OR YOU HAVE NOT READ THE COMPLETE OPERATING INSTRUCTION MANUAL. ...
  • Page 24: Final Check Of Assembled Lift

      7.13 FINAL CHECK OF ASSEMBLED LIFT   Final dimension check after anchoring. ____ Check for air and hydraulic leaks. ____ Ensure cables are properly routed and free from obstructions. ____ Ensure all safety lock mechanism are working correctly. ____ Re-check level of post and decks. ____ Makes sure ramps are secured correctly with cotter pins and washers.
  • Page 25: Operation Test With Vehicle

    7.14 OPERATION TEST WITH VEHICLE  Lower lift to ground. Drive vehicle on to lift, install wheel chocks (Front & Back). Raise lift to and lower onto 3-4 lock positions during full rise to ensure all locks are working correctly. Double check level of runways, front to rear and side to side while on locks. Re-adjust cables if necessary while vehicle is on.
  • Page 26 INSPECTION FREQUENCY COMPONENT  SEMI‐ DAILY  WEEKLY  MONTHLY  QUARTERLY  ANNUALY  ANNUALY  Entire Lift and  8.15          surrounding area  Entire Lift  8.15          Operation  Fasteners    8.3        Wire Ropes    8.2.3  8.2.4  8.2.5    Sheaves    8.4.1    8.4.2   ...
  • Page 27: Wire Ropes

      8.2 WIRE ROPES   Wire ropes are critical to safe and reliable performance of your lift.   Cables are expendable items and should be replaced as a set.  8.2.1 WIRE ROPE CONDITIONS GUIDE  Typical good cable Cable with necking Broken wires Excessive wear of wires Corrugated sheave groove Rust on sheave stack and ropes Figure 15 27 of 44...
  • Page 28: Wire Rope Replacement Criteria

    8.2.2   W IRE ROPE REPLACEMENT CRITERIA:  If any cable is found to be in need of replacement, the entire cable set,  pulleys and safety rollers must be replaced immediately.  See 8.2.1, cable conditions guide.  In the following table, "lay" means the distance measured  along a line parallel to the axis of the rope in which the strand  makes one complete turn about the axis of the rope, or the  wires make a complete turn about the axis of the strand.     The wire rope must be removed from service if one or more of the following criteria are met:  1.  More than six randomly distributed broken wires in one rope lay or 6d length.  2.  More than three broken wires in one strand in one rope lay or 6d length.  3.  Three or more broken wires at rope terminations.  4.  One outer wire broken at the point of contact with the core of the rope which has worked its  way out of the rope structure and protrudes or loops out from the rope structure  5.  Heavy rusting, corrosion, or pitting.  A light surface corrosion on outer wires is normal.   6.  Wear or scraping of one‐third of the original diameter of outside individual wires  7.  Excessive stretch.  It is normal for new cable to require adjustment during “break‐in”, after  which  small  periodic  adjustments  may  be  required.  However,  if  a  cable  that  has  been  in  service for 6 months should suddenly require frequent adjustments or has used all the cable ...
  • Page 29: Inspect Cable Flange

    Wire rope tension adjustment should be performed when installing the lift and every three  months. 8.2.6 INSPECT CABLE FLANGE  Make sure the edges of the counter‐bores in the cable flange are not damaged or worn,  indicating that cable sleeves may not be properly seated at all times.  8.3 FASTENERS  Check all the attaching bolts and nuts for tightness.  Note: Air cylinder bolts and nuts should allow movement of the cylinder.  8.4 SHEAVES AND PINS  Sheaves and pins are expendable items. Sheaves and pins should be replaced when worn. Use  of sheaves and pins with excessive wear will lead to reduced service life of the cables.    Bushings inside sheaves work best in “dry” condition. Applying oil will  diminish their performance and greases will degrade performance even  further. DO NOT GREASE SHEAVE BUSHINGS OR SHAFTS.  8.4.1 VISUAL INSPECTION OF SHEAVES   Check sheaves and replace if cracks or other damage are found.   Visually inspect alignment of sheaves. Misalignment of sheaves indicates excessive wear.  Remove, inspect, and, if needed replace sheave and pin.  8.4.2 MEASURE SHEAVE WEAR   Inspect sheaves in cross‐members with lift in lowered position and resting on safety  latches   Place safety stands under front and rear cross‐members. Stop lift on mechanical safety  locks. One person should hold the lowering handle on power unit down while another  person pulls on cables in each column to create slack in cables.   Check for ease of rotation. If sheaves do not turn freely, the sheave and sheave pin  should be removed, inspected, fixed or replaced.   Fully raise the lift, to inspect sheaves in runways. Hold lowering handle down to lower  lift onto safety latches  ...
  • Page 30: Sheave Pins

    side, or mov ve in and out t more than  1/32 (0.8 m m), the shea ave and shea ave pin (sha ft)  should be re eplaced. Rep place immed iately if nee ded.  8.4.3 SH EAVE PINS S  Sheav e pins are he eld in place  by a Hex He ead Bolt, was sher and loc k washer.   Check k for loose sh heave pins, l oose or miss sing fastene rs to hold sh heave pins in n place.  Remed diate situati on immedia tely.  MECHANI CAL SAFET TY LATCHE S (DOGS)  ...
  • Page 31: Hydraulic Cylinder

    Check fluid level of lift power unit and refill if needed. If refill was needed, inspect all fittings,  hoses and seals. Tighten, repair or replace as required.  Change hydraulic fluid every 2 years.  8.9 HYDRAULIC CYLINDER  Inspect the hydraulic cylinder mounting to the runway. Inspect cylinder and hydraulic hose for  leaks. Repair or replace as required.  Check and tighten the hydraulic cylinder rod nuts holding the cable flange.  Inspect bolts holding anti‐rotation bar onto cable flange and tighten if required. (If applicable)  Inspect sliders on anti‐rotation bar for excessive wear or damage. Replace if required. (If  applicable)  Failure to do so will lead to reduced service life, which could result in  property damage and/or personal injury.  8.10 RUNWAYS  8.10.1   CHECK RUNWAYS  Check level of runways on the floor, on the locks and on the cables: Refer to Section 6.10.  Adjust as required.  Check runways for damage or abnormal deformation. If such conditions exist, contact Snap‐on  Equipment Technical Support.  8.10.2 INSPECT JACK BEAM TRACKS  Inspect rolling jack / oil drain pan tracks for cleanliness, corrosion, excessive wear or damage.  Clean dirty tracks. Worn or damaged tracks should be repaired immediately.  8.11 COLUMNS  8.11.1 CHECK COLUMNS  Check columns for corrosion, giving special attention to the area at the base of the column.  Check severely corroded areas by pecking with an awl or welder’s chipping hammer. If column  is corroded through at any point, it must be replaced immediately. If not corroded through,  remove old paint and rust scale, then coat with a high quality corrosion resistant paint. Clean  and lubricate glide blocks.  8.11.2 CHECK COLUMN ANCHORS  Check column anchor bolts for tightness (if loose, re‐torque to 55 ft‐lb). If anchors do not  tighten to required torque, or continue to loosen, contact Snap‐on Equipment Technical  Support.  Verify proper embedment of anchors after tightening. ...
  • Page 32: Approach Ramps, Chocks, Front Wheel Stops

    8.12 APPROACH RAMPS, CHOCKS, FRONT WHEEL STOPS  Inspect for excessive wear or damage. Repair or replace if required.  Inspect hinge pins. Replace if excessively worn. Lubricate if in good condition  8.13 FRONT AND REAR STEER PLATES    8.13.1 VISUAL INSPECTION  Check front turn tables and rear slip plates for unusual deflection, damage, fluid spills. Clean  or further inspect if needed.  8.13.2 CLEAN REAR SLIP PLATES AND FRONT TURN TABLES  Clean foreign debris from front turn tables and rear slip plates by blowing out with  compressed air.  Check and clean steer plates. Lubricate with oil or light grease.  8.13.3 MAINTENANCE OF REAR STEER PLATES  Inspect the non‐skid coating on rear slip plates for wear. All areas found to be worn smooth  should be resurfaced with an Anti‐Slip abrasive floor tread tape or a heavy duty Anti‐Slip Floor  Coating.    Remove rear slip plate covers. Clean runway surface and touch up any paint wear with a rust  resistant paint. Allow paint to dry thoroughly. Inspect transfer balls for excessive wear,  deformations or corrosion. Inspect plastic pads (pucks) for excessive wear or deformation.  Replace if needed.  8.13.4 MAINTENANCE OF REAR STEER PLATES ‐ IF EQUIPPED WITH  PLASTIC BEARING CAGE.  Remove top Slip Plate covers by first removing the four (4) shoulder bolts on each cover.  Remove polyethylene‐bearing cages insuring that all the Delrin bearings remain in the cages.   Additional Delrin bearings may be purchased if required.  Clean runway surface and touch up any paint wear with a rust resistant paint.   Allow paint to  dry thoroughly.  To obtain optimum performance, the position of the slip‐plate bearing cage should be rotated  every quarter to change the wear pattern.       With the first quarter maintenance, flip the bearing cage over to the opposite side.       With the second quarter maintenance, rotate the bearing cage end‐to‐end.      ...
  • Page 33: Rolling Air Jacks

    8.14 ROLLING AIR JACKS  Lubricate roller bearings and roller guide springs.   Dismantle and clean lift arms.  Clean and lubricate rollers/sliders and hinge points.  Clean and lubricate safety mechanism.  Change hydraulic oil every two years  8.15 ENTIRE LIFT  Wire ropes, columns, runways and other lift parts should be kept free of corrosive agents,  solvents, and road salts. If such agents are spilled or splashed on any lift component,  immediately rinse thoroughly with water and wipe down with a clean rag. Lubricate again  wire rope as shown at 8.2.4.    Check general operation of lift. Observe any structural noise, imbalance, binding, or other  malfunctions.    Failure to keep the lift free of corrosive agents and solvents will lead to  reduced component service life, cable failure, etc., which could result                 in property damage and/or personal injury.      33 of 44...
  • Page 34: Lift Assembly

    9.0 LIFT ASSEMBLY    34 of 44...
  • Page 35   PARTS LIST      ITEM            QTY.  DESCRIPTION            PART#        1    1  POWER PACK, 230V/1PH/60HZ      6‐1936      2    1  POWER POST            4‐1361      3    4  SAFETY RACK            3‐0487 ...
  • Page 36 ITEM            QTY.  DESCRIPTION            PART#       41    4  DECK SHEAVE PIN          2‐0566     42    4  SHOULDER BOLT, 3/8”DIA. X 1 1/2”LG.    6‐0801     43    12  SHOULDER BOLT, 3/8”DIA. X 5/8”LG.     6‐0069     44    4  LOCK SAFETY PIN          1‐0769     45 ...
  • Page 37: Hydraulic And Air Kits Assembly

    10.0 HYDRAULIC AND A A IR KITS AS SSEMBLY  37 of 44...
  • Page 38 HYDRAULIC AND AIR KITS PART LIST      ITEM            QTY.  DESCRIPTION            PART#        1    4  90 ELBOW, 1/8”NPT X 1/4”POLY TUBE    6‐0709      2    4  AIR CYLINDER            6‐0651      3           50 FT.  1/4” DIA. POLY TUBE          6‐0706      4    3  ADAPTER, 3/8” POLY TUBE X 1/4”NPT ...
  • Page 39: Cable Routing Diagram

    11.0 CABLE RO O UTING DIAGRAM         39 of 44...
  • Page 40 PARTS LIST    ITEM            QTY.  DESCRIPTION            PART#        1    1  CABLE ASSEMBLY, 318”LG. (LEFT‐FRONT)    2‐0643      2    1  CABLE ASSEMBLY, 151”LG. (LEFT‐REAR)    2‐0644      3    1  CABLE ASSEMBLY, 203”LG. (RIGHT‐REAR)    2‐0645      4    1  CABLE ASSEMBLY, 367”LG. (RIGHT‐FRONT)    2‐0646      5    8  HEX NUT, 7/8”‐14UNF, GR.5     ...
  • Page 41: Safety Retainer Bracket

    12.0 SAFETY RETAINER BRACKET            ITEM        QTY.   DESCRIPTION                  PART #    1  8  SAFETY RETAINER BRACKET  2‐2589  2  8  SAFETY RETAINER PAD  1‐1674  3  8  SHCS 3/8” NC x 1” LG  6‐2048  4  16  FLAT WASHER #10  6‐0816  5  16  SCREW, SELF TAPPING, #10 x ¾” LG  6‐0297  6  8  LOCK WASHER 3/8”  6‐0058  7  8  HEX NUT 3/8”‐16 UNC GR5 PL  6‐0034 ...
  • Page 42 13.0 POWER P P ACK: #6‐1 1 936 (AB‐1 1400) 208‐2 2 30V/1PH/60HZ            42 of 44...
  • Page 43 POWER PACK PARTS LIST: #6‐1936 (AB‐1400) 208‐230V/1PH/60Hz      ITEM    QTY.    DESCRIPTION            PART #    1    1    VALVE CARTRIDGE CHECK                     6‐1087  2    1    LABEL INSTALLATION AUTOHOIST                   6‐2136  4    1    BREATHER CAP & BLADDER        6‐1376  6   ...
  • Page 44 AUTIO N        ALL SAFE ETY LADDER RS USED O ON 4‐POST  LIFTS ARE  PRELOADE ED.     REMOVIN NG THE BO OLT HOLDI ING THE BO OTTOM PO ORTION O F THE  SAFETY L LADDER W WITHOUT P ROPER PR RECAUTION NS CAN RE SULT IN  INJURY.    PLEASE C CONTACT C CUSTOMER R SERVICE  FOR PROP ER REMOV VAL  INSTRUCT TIONS.       ...
