OPERATION MANUAL

DOUBLE-SIDED PLANER

WINTER DUOMAX

WARNING!

The operator must thoroughly read this manual before operation.

Keep this manual for future reference.

Henrik Winter Holztechnik GmbH

Druckereistr. 8

04159 Leipzig

Tel: +49 (0)341/ 4619021 Fax: +49 (0)341/4618358 Funk: +49 (0)171/2820443

Em@il: info@winter-holztechnik.de Internet: www.winter-holztechnik.de

Need help?

Do you have a question about the DUOMAX GT-400BRD-CE and is the answer not in the manual?

Questions and answers

Summary of Contents for H. Winter DUOMAX GT-400BRD-CE

Page 1 OPERATION MANUAL DOUBLE-SIDED PLANER WINTER DUOMAX WARNING! The operator must thoroughly read this manual before operation. Keep this manual for future reference. Henrik Winter Holztechnik GmbH Druckereistr. 8 04159 Leipzig Tel: +49 (0)341/ 4619021 Fax: +49 (0)341/4618358 Funk: +49 (0)171/2820443 Em@il: info@winter-holztechnik.de Internet: www.winter-holztechnik.de...
Page 2 3. INSTALLATION 3. INSTALLATION 3.1. SAFETY RULES FOR MACHINE LIFTING 1. Pay special attention to the balance of the machine while lifting. 2. Use a forklift with sufficient loading capacity to lift the machine. 3. Have another person help guide the way when lifting the machine. 4.
Page 3 3. INSTALLATION 3.5. INSTALLATION AND LEVELLING Install this machine on a solid and level concrete floor. Leave proper space around the machine for handling the materials to be machined. Four steel pads are furnished with the machine, which are to be placed under the levelling screws at the four corners. After the machine has been located at a proper work site, proper leveling needs to be made.
Page 4 3. INSTALLATION 3.6. POWER SUPPLY REQUIREMENT Insufficient voltage from factory power source may affect the power output of the motor and the function of the controller. It is important to connect this machine to the correct voltage in the factory power source.
Page 5 3. INSTALLATION 3.7. CONNECT POWER SOURCE WIRES 1. Before connecting the power wires make sure the voltage between the machine and your factory power source is the same. 2. Connect the power wires to the L1, L2, L3 connection points inside the electrical control box.
Page 6 3. INSTALLATION 3.8. CHECK POWER WIRES CONNECTION 1. After the power wires have been connected it is necessary to check if the power wires are connected to the correct connection points. 2. Press the power switch on the control panel. 3.
Page 7 U p p e r p l a n n i n g t a b l e u n i t 2000/12/10 Description Q ’ t y NO. Description Q ’ t y Upper planning table Spring Motor Shaft Screw Hexagon nut Washer...
Page 8 U p p e r p l a n n i n g t a b l e u n i t 2000/12/10 Description Q ’ t y NO. Description Q ’ t y Washer Screw Slide guard (L) Slide guard (R) Screw Infeed safety device Screw...
Page 10 Va r i a b l e s p e e d u n i t 2000/12/10 Description Q ’ t y NO. Description Q ’ t y Worm gear reducer Rear cover Spring washer Screw Motor Driven pulley Drive pulley Belt Front cover Washer...
Page 12 U p p e r c u t t e r h e a d u n i t 2000/12/10 Description Q ’ t y Description Q ’ t y Upper cutterhead Screw Spring Washer Set screw Hexagon nut Knife Screw Plate guard Pressure plate bracket...
Page 14 P r e s s u r e r o l l e r u n i t 2000/12/10 Description Q ’ t y NO. Description Q ’ t y Outfeed roller Washer Link Bearing housing Screw Bearing Chain wheel Retaining ring Bearing Bearing cover...
Page 16 S p i k e c o n v e y o r u n i t 2002/08/03 Description Q ’ t y NO. Description Q ’ t y Flange bearing Bracket Spring washer Shaft Screw Shaft Spike chain wheel Chain wheel Drive shaft Setscrew...
Page 17 S p i k e c o n v e y o r u n i t 2002/08/03 Description Q ’ t y NO. Description Q ’ t y Spring pin Screw Bracket Screw Ring Spring Hexagon nut...
Page 19 T o r q u e l i m i t e r u n i t 2000/12/10 Description Q ’ t y NO. Description Q ’ t y Torque limiter Chain wheel Chain wheel Body Lining Bush Friction piece Disk spring Pressure adjustment piece Adjustment nut...
Page 21 M a c h i n e b a d u n i t 2000/12/10 Description Q ’ t y NO. Description Q ’ t y Machine bad Fence Hexagon nut Screw Adjustment screw Belt guard Fixing nut Screw Adjustment screw Washer Spring washer Support rod...
Page 23 I n f e e d t a b l e u n i t 2000/12/10 Description Q ’ t y NO. Description Q ’ t y Table elevation base Worm gear Infeed table Setscrew Tapered gib Worm box Hexagon nut Worm Screw Thrust ball bearing...
Page 25 L o w e r c u t t e r h e a d u n i t 2000/12/10 Description Q ’ t y NO. Description Q ’ t y Cutterhead holder Screw Cutterhead Spring pin Bearing upper housing Screw Spring washer Hexagon nut...
Page 27 E l e v a t i o n u n i t 2000/12/10 Description Q ’ t y NO. Description Q ’ t y Elevation block Chain wheel Thickness indication pointer Washer Setscrew Screw Washer Graduation scale Screw Elevation motor Washer Chain wheel Hexagon nut...
Page 28 E l e v a t i o n u n i t 2000/12/10 Description Q ’ t y NO. Description Q ’ t y Fix screw Roller chain Chain joint Elevation nut (R) Elevation screw (R)
Page 30 L o w e r c u t t e r h e a d d r i v e r u n i t 2000/12/10 Description Q ’ t y NO. Description Q ’ t y Motor bracket Fixing piece Shaft Spring washer Retaining ring...
