INSTALLATION & OPERATING INSTRUCTIONS
(2022/09/06)
( Model: TR2001; Transmitter: T1001 + Receiver: RR11)
IF YOU CAN NOT READ OR UNDERSTAND THESE INSTALLATION INSTRUCTIONS, DO NOT ATTEMPT TO INSTALL OR OPERATE.
INTRODUCTION
This Durablow remote control system is to provide a safe and reliable remote control system for gas heating appliances,
such as fireplace, stove, fire-pit. This remote turns ON or OFF the gas valve. The system operates on radio frequencies
(RF) within a 20-foot range using non-directional signals.
Read ALL sections and original manufacturer manual for safety installation before any action. These safety features shut
down the system and appliance, such as fireplace when a potentially unsafe condition exists, such as high-heat.
PACKING LIST:
Please check and make sure all parts are in good condition before installation. Any questions, please do NOT return to
dealer, but email us
(info@payandpack.com)
and contact us on
PayandPack.com
immediately, we will provide solutions
shortly. Thank you.
Includings: 1. Remote transmitter T1001; 2. Remote control receiver box RR11 with two signal wires; 3. USB
power cord + adapter; 4. Installation Instructions.
TRANSMITTER
The transmitter requires two AAA-size 1.5V batteries (excluded). New (fully charged) batteries are preferred for proper
functionality of the system. Insert batteries into the transmitter battery compartment on the back, positioning the (+) and (-)
ends of the batteries as indicated on the casing. (Fig. 1)
The LED signal light on transmitter should illuminate when either the ON or OFF button is pressed. If the signal light does
not illuminate, check the position of the transmitter's battery, and if it is fully charged. Or go to "LEARN" section.
ON button: Turn ON controlled device, such as Millivolt gas valve or electronic module.
OFF button: Turn OFF controlled device.
REMOTE RECEIVER BOX
Power Source: Input 100-240VAC (universal voltage). USB power cord + adapter with US 2-prong plug.
The
remote control receiver box equips with two 18 gauge signal wires (Temperature resistance 200℃ Max.)
The remote receiver box has a 3-position slide switch (ON / REMOTE / OFF) & a LEARN button on the side panel
(Fig. 1 & 2).
Fig. 1
(side view)
Fig. 2
(top view)
