- Page 1 User’s manual – A S Bench drill 500W REBO Bench drill 500 W AR-HE-TBM13 Please follow all security measures in this user’s manual to ensure a secure use. Thank you for trusting AREBOS.
-
Page 2: Table Of Contents
User’s manual – A S Bench drill 500W REBO List of contents 1. Safety instructions ............3 1.1 Explanation of the symbols ............3 1.2 Safety rules ................. 4 1.3 Safety work area ................. 4 1.4 Precautions against accident hazards ......... 6 1.5 Residual risks ................ -
Page 3: Safety Instructions
User’s manual – A S Bench drill 500W REBO Thank you for purchasing our product. Please read the operating instructions carefully before using the product for the first time. If you give the product to a third party, this manual must be handed over with it. -
Page 4: Safety Rules
User’s manual – A S Bench drill 500W REBO Do not wear gloves. Do not wear long hair loose. Use a hair net. Attention! Laser beam! Do not look into the beam! 1.2 Safety rules • Keep all safety information and instructions for the future. The term "power tool" used in the safety instructions refers to mains operated power tools (with mains cable) and battery- operated power tools (without mains cable). - Page 5 User’s manual – A S Bench drill 500W REBO • Connect it to a vacuum cleaner. If there are connections for dust extraction and collection, make sure that they are connected and used correctly. • Do not use the cable for purposes for which it is not intended. Do not use the cable to disconnect the plug from the outlet.
-
Page 6: Precautions Against Accident Hazards
User’s manual – A S Bench drill 500W REBO • Break long drilling chips by interrupting the drilling process by briefly turning back the turning wheel. There is a risk of injury due to long drilling chips. • Keep handles dry, clean and free of oil and grease. Greasy, oily handles are slippery and lead to loss of control. -
Page 7: Technical Data
Keep your hands away from the working area when the machine is in operation. Before carrying out any adjustment or maintenance work, switch off the machine and unplug it from the power supply. 2. Technical Data Model AR-HE-TBM13 Rated input voltage 230 V~/50 Hz Nominal power 500 W (S2 15 min) -
Page 8: Scope Of Delivery
User’s manual – A S Bench drill 500W REBO 3. Scope of delivery... -
Page 9: Construction
User’s manual – A S Bench drill 500W REBO 4. Construction 4.1 Unpacking • Open the packaging and carefully remove the device. • Remove the packaging material and any packaging and transport locks (if present). • Check that the scope of delivery is complete. •... - Page 10 User’s manual – A S Bench drill 500W REBO...
- Page 11 User’s manual – A S Bench drill 500W REBO...
-
Page 12: Clamping The Drill Bit
User’s manual – A S Bench drill 500W REBO 4.3 Clamping the drill bit 4.4 Spindle speed To adjust the speed of the drill, set the belt drive to the respective "height". Open the belt box (see 2. Technical data; picture no.6) by loosening the cross screw. Between the motor and the switch for the laser, loosen the wing screw by hand so that the belt relaxes. -
Page 13: Clamping The Workpiece
User’s manual – A S Bench drill 500W REBO Tension the belt so that it can be twisted by approx. 90°. The belt box must be closed again with the cross screw. 4.5 Clamping the workpiece... -
Page 14: Test Run
User’s manual – A S Bench drill 500W REBO 4.6 Test run... - Page 15 User’s manual – A S Bench drill 500W REBO...
-
Page 16: Maintenance
User’s manual – A S Bench drill 500W REBO 4.7 Maintenance 5. Intended Use • The machine may only be used in a technically perfect condition and in compliance with all safety instructions. • This device may only be used as intended. The manufacturer cannot be held responsible for any damage resulting from non-compliance with the provisions of the generally applicable regulations as well as the provisions of these instructions. -
Page 17: Putting Into Service
User’s manual – A S Bench drill 500W REBO • Even with proper use and compliance with all safety regulations, residual risks may still exist: Noise emission Dust emission Hand-arm vibrations Risk of burns Tool and workpiece heat up during operation Risk of injury Sharp tools and workpiece edges 6. -
Page 18: Inspection And Maintenance Plan
User’s manual – A S Bench drill 500W REBO 7. Inspection and maintenance plan Regular maintenance period Before each commissioning After each commissioning If necessary Check safety equipment. ✓ Check V-belt and tighten if ✓ necessary. Lubricate the column and ✓... -
Page 19: Storage
User’s manual – A S Bench drill 500W REBO • Wear parts: Carbon brushes; V-belts, batteries, drills 8.4 Storage • Store the device and its accessories in a dark, dry and frost-free place that is inaccessible to children. The optimum storage temperature is between 5 and 30˚C. •... -
Page 20: Environmentally Friendly Disposal
You can obtain the addresses from your city or local government. You can find out about other return options created by us on our website www.arebos.de. The separate collection of Waste electrical or electronic equipment is intended... -
Page 21: Eu Declaration Of Conformity
Authorised representative for the technical documentation: Korhan Canbolat Office address: Canbolat Vertriebs GmbH Gneisenaustraße 10-11 D-97074 Würzburg Return address can be found in the imprint: https://www.arebos.de/impressum/ VAT identification number: DE 263752326 Court of the Commercial Register is Würzburg, HRB 10082 WEEE Reg.-No. DE 61617071...
