- Page 2 SERIES AMPLIFIERS Dash Mount Remote Gain Control Some people like the “bling”, some like the stealthy approach… And some like to be different. For those who strive to be different, the new 2009 TRAX amplifiers will fill your craving. The new heatsink has huge, wide, aggressive fins for extreme cooling, requirement for the monster 7000 watt model.
- Page 3 • Bridged Synchronization (strap amps together for double power!) • 200mV-6V Low Level Inputs • Pre-Amp Outputs • Variable 12dB 40-200Hz LPF RMS @ 4Ω RMS @ 2Ω (watts) (watts) TRAX1-1800D 1 x 550 1 x 820 TRAX1-4000D 1 x 1200 1 x 1700 TRAX1-5500D 1 x 1700...
- Page 4 PHAnATIK SERIES Yes it a play on words! But the meaning is the same “Intense Uncritical Devotion” you won’t believe your eyes and ears when you power this bad boy up! The stunning good looks with Diamond Cut heat sink and Ebony color will bring you back to the trunk time and again! AMPLIFIERS Dash Mount Remote Gain Control...
- Page 5 New Hyper Bass boost 2/4 Channel Common Features • Sloping End Caps • MOSFET Power Supply Transistors • Pulse Width Modulation Circutry • The-way Protection Circuitry • 2-ohm Stereo, 4-ohm Bridged Stable • Tri-Mode Capable • Selectable Crossovers (HPF/Full/LPF) • 200mV-8V Low Level Inputs •...
- Page 6 SUBWOOFERS What's cool? The Kole Audio KMX subwoofers. A revolutionary design in a direct-coupled aluminum dust cap increases thermal transfer from the voice coil by 50%. At the same time, the newly designed dust cap lowers the resonant frequency of the subwoofer, thereby extending the low-end. Our acoustical engineers achieved their goal in making these woofers handle 56% more power over conventional designs without sacrificing sensitivity.
-
Page 7: Common Features
SERIES SUBWOOFERS MAX Power RMS Power Magnet Subwoofers (watts) (watts) Weight (oz) (Hz) KW2-10M 1100 450 100 43.10 5.226 0.753 16.40 0.725 0.636 KW2-12M 1200 500 100 37.60 5.453 1.649 16.40 1.093 0.911 KW2-15M 1300 550 110 26.40 6.237 5.311 16.40 1.605 1.276 SUBWOOFERS KW1 MAX Power RMS Power Magnet... - Page 8 TWEETERS KB-1 2-Way Mount Tweeter 200 W • Niobium Rare Earth Ferroelectric Transducer Magnet • Polypropylene Diaphragm • 100 Watts R.M.S. • Freq. Resp. 5KHz-25KHz • Imp. 4 Ohm • Surface/Angle Mount • SPL 97dB • Built in Crossover KB-4 4-way Mount Tweeter 250W •...
- Page 9 SERIES SPEAKERS Common Features: • Poly Propylene Injection Molded Cone • Butyl Rubber Surround • Flush Rubber Magnet Trim • Stamped Steel Frame KPS-694N 6x9” 4 Way Speakers 380 Watts • 40 oz Magnet KPS-653N 6.5” 3 Way Speakers 220 Watts KPS-462N 4x6”...
- Page 10 CAPCELL TO CAP OR TO CELL… THAT IS THE QUESTION! Often called a “power cap” or “stiffening cap”, some people prefer caps over secondary batteries. A second battery is great for high power systems, but should be accompanied by an upgraded alternator that can efficiently charge both batteries. This gets expensive. A cap stores power too, but can charge and discharge in a fraction of a second, depending on size.
- Page 11 CAPACITORS • Current Sensing Circuitry for Auto on/off • 24 Volt DC MAX Output • Digital Voltage Display • Chrome Finish • Ring Terminal Connection Post • Dimension: 3.625”h x 5.5”w x 9.5”L C-4D C-6D 6 Farad Power Capacitor C-20D High Power 20 Farad Capacitor C1.6R 1.6 Farad Power Capacitor...
