- Page 1 FH-DW30 Chipper www. Betstco.com 541-895-3083 M-F 7am-4pm PST 83371 Melton Rd, Creswell OR 97426...
-
Page 2: Warranty
The distributer's liability under warranty is limited to repair of the product and/or replacement of parts and is given to the purchaser in lieu of all other remedies including incidental and consequential charges. There are no warranties, expressed or implied other than those specified herein. For the nearest Authorized Service Centre call the manufacturer. FH-DW30... - Page 3 ........FH-DW30...
- Page 4 Safety, Operation, Maintenance and Trouble Shooting information contained within the Operator's Manual. This manual covers the FHM 3 Point Hitch Wood Chipper DW30. Use the Table of Contents or Index as a guide to locate required information.
-
Page 5: Safety Alert Symbol
It may also be used to alert against unsafe practices. If you have any questions not answered in this manual or require additional copies or the manual is damaged, please contact your dealer or FHM. FH-DW30... -
Page 6: General Safety
1. Read and understand the Op- YOU are responsible for the SAFE operation and erator’s Manual and all safety maintenance of your FHM 3 Point Hitch signs before using, maintain- Wood Chipper. YOU must ensure that you and ing, adjusting or cleaning the anyone else who is going to use, maintain or work 3 Point Hitch Wood Chipper. -
Page 7: Equipment Safety Guidelines
If the elderly are assisting with work, their physical limitations need to be recognized and accommodated. FH-DW30... -
Page 8: Safety Training
An untrained operator exposes himself and bystanders to possible serious in- jury or death. If the elderly are assisting with the work, their physical limitations need to be recognized and accommodated. FH-DW30... -
Page 9: Maintenance Safety
10. When completing a maintenance or service function, make sure all safety shields and devices are installed before placing unit in service. FH-DW30... - Page 10 9. Do not run machine inside a closed building to prevent asphyxiation from engine exhaust. FH-DW30...
-
Page 11: Storage Safety
6. Do not drink and drive. 7. Be a safe and courteous driver. Always yield to oncoming traffic in all situations, including narrow bridges, intersections, etc. Watch for traffic when operating near or crossing road- ways. 8. Never allow riders on the machine. FH-DW30... -
Page 12: Safety Sign Locations
The types of safety signs and locations on the equipment are shown in the illustrations that follow. Good safety requires that you familiarize yourself with the various safety signs, the type of warning and the area, or particular function related to that area, that requires your SAFETY AWARENESS. • Think SAFETY! Work SAFELY! FH-DW30... - Page 13 FH-DW30...
- Page 14 FH-DW30...
- Page 15 REMEMBER - If safety signs have been damaged, removed, become illegible or parts replaced without safety signs, new signs must be applied. New safety signs are available from your authorized dealer. FH-DW30...
- Page 16 7. Or alternatively attach a lifting device to the lifting bracket on top of the frame. 8. Remove pallet and place machine on the ground. 9. Release feed hopper transport latch and lower hopper into the working position. Stow anchor latch. FH-DW30...
- Page 17 Be sure the yoke with the shear pin is attached to the machine shaft. d. Lower the guard to cover the input shaft. 12. Depress handle on discharge chute latch and turn assembly to its desired position. Turn until latch seats in its detent. FH-DW30...
-
Page 18: Operation
Inspect machine for damaged or loose parts before resuming work. TO THE NEW OPERATOR OR OWNER Follow all safety instructions exactly. Safety The FHM 3 Point Hitch Wood Chippers is everyone's business. By following recom- are designed to chip or chop scrap lumber, small mended procedures, a safe working environ- trees, brush, limbs and other wood debris. -
Page 19: Machine Components
PTO shaft on the front of the frame . A Self Feed Hopper B Rotor Housing C 3 Point Hitch D Rotor Blade E Rotor F Paddle G Discharge Hood H Hood Deflector I Stationary Blade FH-DW30... -
Page 20: Machine Break-In
MACHINE BREAK-IN PRE-OPERATION CHECKLIST Although there are no operational restrictions on Efficient and safe operation of the FHM the Wood Chipper when used for the first time, it is 3 Point Hitch Wood Chipper requires that each recommended that the following mechanical items... -
Page 21: Driveline Dimension
Assemble the 2 ends of the shaft. Make sure the shaft can telescope freely. If it does not, separate the 2 parts and inspect for burrs or cuttings on the shaft ends. Be sure it telescopes freely before installing. FH-DW30... - Page 22 RPM. Disen- gage the PTO control slowly at low RPM allow the machine to slow and stop before engaging the PTO brake. Remember PTO drives the rotor. When the PTO is engaged the rotor will also start to turn. FH-DW30...
-
Page 23: Transport Safety
6. Do not drink and drive. 7. Raise and secure the feed hopper before transporting. 8. Turn the discharge hood and point toward the rotor to reduce the width of the machine. TRANSPORT CONFIGURATION FH-DW30... -
Page 24: Service And Maintenance
• When completing a maintenance or service function, make sure all safety shields and de- vices are installed before placing unit in serv- ice. FH-DW30... - Page 25 8 Hours or Daily 1. Grease PTO driveline. 40 Hours or Weekly 1. Grease the telescoping section of the PTO shaft. 2. Check sharpness of blades: a. Rotor b. Stationary Remove, sharpen or switch edge as required. FH-DW30...
- Page 26 100 Hours 1. Grease rotor bearings. IMPORTANT Do not over grease. Annually 1. Clean machine. FH-DW30...
-
Page 27: Driveline Maintenance
12. Check that each guard turns freely on the shaft. 13. Assemble the driveline. Disassembled DRIVELINE COMPONENTS 14. Check that the driveline telescopes easily. 15. Replace any components that are damaged or worn. 16. Install the driveline on the machine. FH-DW30... -
Page 28: Troubleshooting
TROUBLE SHOOTING The FHM 3 Point Hitch Wood Chipper is designed with blades on a rotor to cut, shear and chip wooden material. It is a simple and reliable system that requires minimal maintenance. In the following section, we have listed many of the problems, causes and solutions to the problems that you may encounter. -
Page 29: Specifications
Direct drive, pto w/shearbolt ' ' 6 x ' ' ' ' 9 e f i ' ' 0 L ' ' ' ' 8 x ' ' ' ' 4 c t i Hopper Discharge Rotation ' ' 1 FH-DW30... -
Page 30: Bolt Torque
Torque figures indicated above are valid for non-greased or non-oiled threads and heads unless otherwise specified. Therefore, do not grease or oil bolts or capscrews unless otherwise specified in this manual. When using locking elements, increase torque values by 5%. * Torque value for bolts and capscrews are identified by their head markings. FH-DW30... - Page 31 DW30 Wood Chipper FH-DW30...
- Page 32 FH-DW30...
- Page 33 FH-DW30...
- Page 34 QB/T 3874-1999 HINGE UES GB/T56-88 COLLAR NUT M16 GB/T93-1987 Spring washer 16 DW30.114 KNIFE DW30.017 CUTTING DRUM DW30.018 NUT PLATE GB T7810-1995 UCFU208 Bearing UCFU208 CP5.20.104 Belt ptlley, in REACH 04 35X60 JB/T7934Z3 Swellable sleeve 35X60 XPA860 GB/T11544-97 Strap XPA860 FH-DW30...
- Page 35 DW30.109 LINKAGE DW30.110 LOWER LINK BOLT-ON PIN M16*50 GB/T5783-2000 Bolt M16*50 GB/T889.1-2000 Locking Nut M16 M14*65 GB/T5783-2000 Bolt M14*65 GB/T6170-2000 Nut M14 DW30.116 ADJUSTABLE BRACKET M16*40 GB/T5783-2000 Bolt M16*40 DW30.115 ANVIL GB/T889.1-2000 Locking Nut M12 DW30.020 FEEDING UNIT AXLE FH-DW30...
- Page 36 Farmer Helper Machinery Brand LIMITED WARRANTY Gasoline or diesel engines used to powered FARMER HELPER MACHINERY CO. LTD. products are covered by the warranty of the appropriate engine manufacture and Purchaser must look to the engine manufacture for all issues relating to engine operation.
- Page 37 FARMER HELPER MACHINERY REGISTRATION...
