Kodak EasyShare EX1011 Setup Manual

Kodak easyshare ex1011: setup guide
Hide thumbs Also See for EasyShare EX1011:

Advertisement

Quick Links

See also: User Manual
1
Your wireless setup guide
Perform each of these step-by-step procedures to set up your wireless Kodak digital
picture frame. Then view and share pictures and videos from your computer - on your
frame - wirelessly!
If you have problems with your wireless setup or connection, see
Troubleshooting starting on
www.kodak.com/go/digitalframesupport
page
25.
page 2
page 10
page 13
page 17
page 21
1

Advertisement

loading

Related Manuals for Kodak EasyShare EX1011

Summary of Contents for Kodak EasyShare EX1011

  • Page 1: Table Of Contents

    Your wireless setup guide Perform each of these step-by-step procedures to set up your wireless Kodak digital picture frame. Then view and share pictures and videos from your computer – on your frame – wirelessly! 1. Install and set up Windows Media player 11 2.
  • Page 2 1 Insert the EasyShare software CD. 2 Go to page 2 to install Windows Media player 11. Go to page 8 to set up media sharing (if you already have Windows Media player 11). www.kodak.com/go/easysharecenter page 8 to set up media NEXT...
  • Page 3 Go to page 8 1 Select Let me install Windows Media player now. 2 Click Your browser opens and you are automatically connected to the Microsoft Windows Media player download page. www.kodak.com/go/digitalframesupport to set up media sharing. Install the software...
  • Page 4 Do not close the Windows Media player installer window during the installation. TIP—if an error screen appears, click OK on the error screen, then click Cancel on the Digital Picture Frame Installer screen. Restart the installation by ejecting the CD and reloading it. www.kodak.com/go/easysharecenter...
  • Page 5 The download usually takes less than a minute with high-speed Internet access. Dial-up connections take longer. A progress screen appears as the installation files are downloaded to your computer. TIP—if the progress screen does not appear, click Click here if your download did not begin. www.kodak.com/go/digitalframesupport Install the software...
  • Page 6 Windows Media player 11. The installation begins. A progress screen appears and monitors the installation. The Windows Media player 11 Welcome screen opens. NEXT: Set up Windows Media player 11 to confirm that you to accept the supplemental license for www.kodak.com/go/easysharecenter NEXT...
  • Page 7 (up to an hour). 5 Click A progress screen monitors the setup. When the setup is complete, Windows Media player 11 opens and displays available media files. NEXT: Share media in Windows Media player 11 www.kodak.com/go/digitalframesupport Install the software NEXT...
  • Page 8 2 - Library button 2 Click the button in the top menu bar. 3 Select Media Sharing from the drop-down menu. 4 In the Media Sharing screen, select Share my media. 5 Click www.kodak.com/go/easysharecenter...
  • Page 9 Windows Media player 11 setup is complete! 7 Close Windows Media player by clicking then close your browser window. 8 Click to start the Kodak EasyShare software Install Wizard. NEXT: Install and set up EasyShare software www.kodak.com/go/digitalframesupport Install the software We’ll return to this screen...

  • Page 10: Install And Set Up Easyshare Software

    Install the software Install and set up EasyShare software The CD that was packaged with your frame contains a special version of Kodak EasyShare software that lets you copy pictures between your computer and your frame. Install EasyShare software now. Even if you already have EasyShare software on your computer, follow these installation instructions to upgrade to this special software version.

  • Page 11: Install And Set Up Windows Media Player

    When prompted, take a few minutes to electronically register your frame and software. To register later, visit www.kodak.com/go/register. IMPORTANT: For Windows XP operating systems, you must restart your computer to compete the installation. 3 Select Yes, restart computer now. 4 Click Your computer shuts down.
  • Page 12 When the setup is complete, EasyShare software opens and your pictures are displayed in My Collection. 2 Close EasyShare software by clicking NEXT: Set up your wireless frame NOTE: It may take several seconds for the first screen to open. in the top-right corner of the screen. www.kodak.com/go/easysharecenter NEXT...

  • Page 13: Set Up Your Wireless Frame

    Set up your wireless frame back menu Turn on the frame and select your language www.kodak.com/go/digitalframesupport In this section, all buttons and controls, unless otherwise specified, are on the remote control that was included with your frame. 1 Press the power switch to On.
  • Page 14 2 Press OK. The frame scans for available wireless networks. 3 Press to highlight your network, then press OK. NOTE: If the scan finds multiple networks, your network is usually the first one listed, with the highest %. www.kodak.com/go/easysharecenter page...
  • Page 15 The person who set up your network can provide you with this information. 5 Highlight Done on the keyboard, then press OK on the remote control. The Connecting screen appears, then acknowledges that you are connected! www.kodak.com/go/digitalframesupport Set up your wireless frame go to step 6.
  • Page 16 Set up your wireless frame The Scanning screen appears as the frame scans your network and then lists available computers. 6 Press to highlight your computer, then press OK. Congratulations, you’ve completed your network setup! NEXT: Share your media with your frame www.kodak.com/go/easysharecenter NEXT...

  • Page 17: Share Your Media With Your Frame

    You’ll select your frame as a device with which your computer can share media files (pictures, videos, music). 1 Open Windows Media player 11. Select Start > Windows Media Player. www.kodak.com/go/digitalframesupport Set up your wireless frame 2 Click “Library.” 3 Select “Media Sharing.”...
  • Page 18 NEXT: Add shared folders on your computer (optional) NEXT: Set up your gallery account, page 21 4 Select your frame. 5 Select “Allow.” 6 Click “OK” to finish and close. www.kodak.com/go/easysharecenter NEXT...
  • Page 19 1 On your computer, open Windows Media player 11. 2 Click in the top menu bar. 3 Select Add to Library from the drop-down menu. www.kodak.com/go/digitalframesupport Set up your wireless frame 4 Select “My personal folders.” 5 Click “Advanced Options>>.”...
  • Page 20 The contents of the shared folder are added to the Windows Media player Library. They are now accessible to your frame. Repeat these steps to share other folders. 6 Click “Add.” 7 Navigate to the folder you wish to share (“Image Data” in this example). 8 Click “OK.” 9 Click “Close.” www.kodak.com/go/easysharecenter...

  • Page 21: Set Up Your Gallery Account (Us, Canada, And Europe Only)

    Display pictures directly from the Kodak gallery via the Internet (this feature is currently limited to customers in the US, Canada, and Europe). Perform this one-time setup on your frame to connect it to your existing Kodak gallery account. Don’t have a Kodak gallery account yet? Visit www.kodakgallery.com.
  • Page 22 8 Highlight Password, then press OK. 9 Enter your gallery password. Press OK after each character. Highlight Done, then press OK. 10 Press on the remote control. Kodak Gallery Home screen. Congratulations, you have completed your gallery setup! NEXT: View pictures over your wireless network...
  • Page 23 1 Make sure your computer and your picture frame are powered on. back menu 2 Press the Home button. It may take up to 10 seconds for your Network Computer screen. 3 Press to highlight Network Computer www.kodak.com/go/digitalframesupport Home screen to appear on the Home , then press OK.
  • Page 24 The categories are established by Windows Media player 11. 6 Pictures are displayed as thumbnails. Press the remote control) to play a slide show. See the Getting Started Guide for more information about using your frame and viewing your pictures. www.kodak.com/go/easysharecenter...

  • Page 25: Frequently Asked Questions

    Help > About Windows Media Player.) If your version is earlier than 11, upgrade to version 11. See page I already have Kodak EasyShare software on my computer. Do I have to install it again? The CD that was packaged with your frame contains a special version of EasyShare software that lets your computer share pictures with your frame.
  • Page 26 1 Press Home on the remote control, then select Settings > Network > Manual > Enable/disable connections > Enable. 2 Press the Back button. 3 Select Network > Scan for wireless networks. 4 Continue with step page www.kodak.com/go/easysharecenter page page 2F6599_en...
