Kodak easyshare z1485: user guide

Advertisement

Installing the software

Before connecting any cables, install the software that was
included with your camera. Follow the on-screen instructions.

Loading the batteries

Kodak Li-Ion rechargeable
digital camera battery
KLIC-8000 (rechargeable)
See the Extended user guide
www.kodak.com/go/z1485support
After installing the software, return to this
user guide.
Kodak lithium digital camera
battery CRV3 (non-rechargeable)
www.kodak.com/go/z1485support
2 AA lithium batteries
(non-rechargeable) Alkaline
batteries are NOT compatible.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EasyShare Z1485 and is the answer not in the manual?

Questions and answers

Summary of Contents for Kodak EasyShare Z1485

  • Page 1: Installing The Software

    Before connecting any cables, install the software that was included with your camera. Follow the on-screen instructions. Loading the batteries Kodak Li-Ion rechargeable Kodak lithium digital camera digital camera battery battery CRV3 (non-rechargeable) KLIC-8000 (rechargeable) See the Extended user guide www.kodak.com/go/z1485support...
  • Page 2: Turning On The Camera

    Turning on the camera Setting the language, date/time See the Extended user guide Language: to change. to accept. Date/Time: to change. for previous/next field. to accept. www.kodak.com/go/z1485support www.kodak.com/go/easysharecenter...
  • Page 3: Taking A Picture/Video

    Press the Shutter button halfway to focus. When the Ready light turns green, press the Shutter button completely down. NOTE: For more about Smart Capture mode, see See the Extended user guide www.kodak.com/go/z1485support Smart Capture mode Press the Shutter button completely down and release.
  • Page 4: Transferring Pictures/Videos

    Videos: Play Pause/resume Adjust the volume 2X, 4X forward 2X, 4X reverse Kodak EasyShare printer dock or camera dock (May be sold separately.) For dock compatibility, visit Connect USB cable. www.kodak.com/go/dockcompatibility Turn on camera. To purchase accessories, visit www.kodak.com/go/z1485accessories...
  • Page 5: Getting Help From Your Camera

    If you learn nothing else about your camera, learn how to use on-camera Help. Because the more you know your camera, the more confident you become! Menu See the Extended user guide www.kodak.com/go/z1485support Press the Menu button, then highlight a menu choice. Press...
  • Page 6 • taken pictures • transferred pictures to your computer Keep learning! Finish reading this book, so you can take and share your best pictures! Visit www.kodak.com/go/z1485support and www.kodak.com/go/easysharecenter for: • the Extended user guide • interactive troubleshooting and repairs • interactive tutorials •...
  • Page 7: Front View

    Front view Mode dial Shutter button Self-timer/Video light On/Off button Flash button www.kodak.com/go/z1485support Self-timer/Burst button Flash Speaker Microphone 10 Lens...
  • Page 8: Back View

    Wide angle (W) button Telephoto (T) button Slot for optional SD or SDHC card 16 Dock connector USB, A/V Out 10 DC-In, for optional 3V AC adapter 11 Share button 12 Menu button 13 Review button 14 Battery compartment 15 Tripod socket www.kodak.com/go/easysharecenter...
  • Page 9: Doing More With Your Camera

    Faces are detected. ■ The scene is analyzed for other content and for lighting. ■ Kodak Perfect Touch technology is applied, for better pictures. Smart You can choose the best picture size and aspect ratio for your needs—just Capture press the Menu button and choose Picture Size.
  • Page 10: Using Optical Zoom

    1 Use the LCD to frame your subject. 2 Press Telephoto (T) or Wide Angle (W) to zoom in/out. 3 Take the picture. Remember: ■ Use the auto focus framing marks, ■ As you zoom in, move further from your subject. www.kodak.com/go/easysharecenter page...
  • Page 11: Using The Flash

    A preflash does not fire; the camera corrects red eye. Flash-to-subject distance in Smart Capture mode Wide angle 19 ft (5.8 m) Telephoto 10.2 ft (3.1 m) www.kodak.com/go/z1485support Doing more with your camera Press the button repeatedly to scroll through flash modes. (See flash modes below.)
  • Page 12: Using The Self-Timer

    Press the Shutter button completely down. NOTE: The video stops when no storage space remains. Only the 2- and 10-second options are available in video mode. Compose the scene. Press the Shutter button halfway, then completely down. The picture is taken after the delay. www.kodak.com/go/easysharecenter...
  • Page 13: Understanding The Picture-Taking Icons

    Status icons indicate mode, feature, and camera status. Picture size Flash Camera mode Tag name Framing marks Histogram Framing grid Aperture Shutter speed www.kodak.com/go/z1485support Doing more with your camera Self-timer/Burst Date stamp Pictures/time remaining Storage location Zoom indicator Auto focus control White balance Exposure metering Focus zone...
  • Page 14: Working With Pictures/Videos

    If you accidentally delete a picture/video, use Undo Delete to retrieve it. This feature is available only immediately after you delete a picture/video in Review mode (when the Undo Delete option appears). 1 Press to highlight Undo Delete. 2 Press OK. The deleted picture/video appears. 3 Select Exit to exit the Delete menu. www.kodak.com/go/easysharecenter...
  • Page 15: Using The Menu Button In Review

    1 Press the Review button, then the Menu button. 2 Press to highlight a tab: ■ Review to view pictures/videos Edit to edit pictures/videos ■ Setup for other camera settings ■ 3 Highlight a setting, then press OK. Choose an option, then press OK. www.kodak.com/go/z1485support Working with pictures/videos...
  • Page 16: Adding Sound Tags

    Edit tab. 1 Press the Review button, then picture. 2 Press to play the sound tag. 3 Press to adjust the volume. 4 Press the OK button to stop playback. www.kodak.com/go/easysharecenter to find a tagged...
  • Page 17: Searching Pictures By Date, Favorites, Or Other Tag

    Telephoto (T) button to view the picture full-screen. Press the Wide Angle (W) button to return to multi-up view. ■ Press the Review button to exit Review. See the Extended user guide www.kodak.com/go/z1485support Working with pictures/videos to select a folder. to view them. Press the www.kodak.com/go/z1485support...
  • Page 18: Understanding The Review Icons

    Selected picture Scroll arrows Email tag Protected Favorite tag Review mode Selected video Scroll arrows Perfect Touch tech. Picture number Image storage location Relative picture location Low battery Video length Video number Image storage location Relative video location Low battery www.kodak.com/go/easysharecenter...
  • Page 19: Using The Advanced Features

    Capture for the most common picture-taking settings. Capture + for other picture-taking settings. ■ Setup for other camera settings. ■ 3 Highlight a setting, then press OK. Choose an option, then press OK. See the Extended user guide www.kodak.com/go/z1485support for information about camera www.kodak.com/go/z1485support...
  • Page 20: P And M Modes

    The settings, including Flash, are maintained for P and M modes—even when you change modes or turn off the camera. Press Exposure compensation (how much light enters the camera), ISO speed, and focus mode. For definitions, page Aperture, shutter speed, ISO speed, and focus mode. For definitions, page www.kodak.com/go/easysharecenter to control...
  • Page 21 Aperture—(also known as f-stop) control the size of the lens opening, which determines the depth of field. ■ Smaller f-stop numbers indicate a larger lens opening; good for portraits and low-light conditions. www.kodak.com/go/z1485support Using the advanced features P and M Options White—selectable Grey—non-selectable Red highlight—changeable value...
  • Page 22 Distant subjects. Auto-focus framing marks are unavailable. Infinity Focus is at center position. When MF icon appears, press OK to display Manual focus indicator. Press appears on the screen when adjusting focus position. to adjust the setting. A magnified image www.kodak.com/go/easysharecenter...
  • Page 23: Solving Camera Problems

    Memory card full. ■ Transfer pictures to the computer camera www.kodak.com/go/z1485support page www.kodak.com/go/z1485support (page www.kodak.com/go/z1485support (page (page (page 14), or insert a card with available memory...
  • Page 24 If the LCD breaks, do not touch the glass or liquid. Contact Kodak customer support. ■ The use of an accessory that is not recommended by Kodak may cause fire, electric shock, or injury. For approved accessories, visit www.kodak.com/go/accessories. ■...
  • Page 25 If Kodak is unable to repair or replace a Product, Kodak will, at its option, refund the purchase price paid for the Product provided the Product has been returned to Kodak along with proof of the purchase price paid. Repair, replacement, or refund of the purchase price are the sole remedies under the warranty.
  • Page 26: Regulatory Compliance

    In countries other than the United States and Canada, the terms and conditions of this warranty may be different. Unless a specific Kodak warranty is communicated to the purchaser in writing by a Kodak company, no warranty or liability exists beyond any minimum requirements imposed by law, even though defect, damage, or loss may be by negligence or other act.
  • Page 27: Australian C-Tick

    For more information, see your retailer, local authority, or www.kodak.com/go/recycle. (Product weight: 164 g.) Canadian DOC statement DOC Class B Compliance—This Class B digital apparatus complies with Canadian ICES-003.
  • Page 28: Russian Gost-R

    VCCI Class B ITE MPEG-4 Use of this product in any manner that complies with the MPEG-4 visual standard is prohibited, except for use by a consumer engaging in personal and non-commercial activities. Russian GOST-R Eastman Kodak Company Rochester, NY 14650 AIO-40 www.kodak.com/go/easysharecenter...
  • Page 29: China Rohs

    Appendix China RoHS Eastman Kodak Company Rochester, New York 14650 © Eastman Kodak Company, 2008 Kodak, EasyShare, and Perfect Touch are trademarks of Eastman Kodak Company. 4F8396_en www.kodak.com/go/z1485support...
