Summary of Contents for Leader Like Me
- Page 2 Important Safety Instructions Important-Please read these instruction fully before starting assembly When using an electrical appliance, basic safety precautions should always be followed, including the following. Read all instructions before using this sewing machine. DANGER- To reduce the risk of electric shock: 1.
-
Page 3: Table Of Contents
Contents Know Your Machine Name of parts..........................2 Accessories..........................2 Preparing To Sew Connecting machine to power supply ..................3 Reverse sewing lever.........................3 Sewing table ..........................4 Presser foot arm ........................4 Changing the presser foot ......................5 Changing the needle........................6 Thread and needle chart......................7 Stitch selector and indicator......................7 Bobbin winding..........................8 Threading the upper thread......................9 Threading the bobbin case......................10... -
Page 4: Know Your Machine
Know Your Machine Connecting the machine to Name of parts power supply Reverse sewing lever Power switch Machine socket Handwheel Bobbin winder stopper Bobbin winder spindle Spool pins Carry handle Stitch length adjustor Thread guide Bobbin winding thread guide Thread take-up lever Thread tension dial Face plate Sewing table &... -
Page 5: Preparing To Sew
PreparingToSew Connecting the machine to power supply Wall socket - Please read the important safety instructions before use. - Before connecting to the mains make sure that the rated voltage show on the rear panel matches your mains voltage supply. a:TurnoffthePowerSwitch. b: Insert the Machine Plug into... -
Page 6: Sewing Table
PreparingToSew Sewing table Auxiliary function The Sewing Table provides added sewing surface and can be easily removed for free arm sewing. Free-arm sewing is used when sewing tubular and hard-to-reach areas on a garment such as the hem of pant legs or sleeves. -
Page 7: Changing The Presser Foot
PreparingToSew Changing the presser foot Ensure the Power Switch turned off when changing the presser foot. Needle Presser foot Groove a:To remove Turn the Hand Wheel toward you to raise the Needle to its highest position. Raise the Presser foot arm Press the Press Foot Holder the back of the foot holder. -
Page 8: Changing The Needle
Preparing To Sew Changing the needle Ensure the Power Switch turned off when changing the needle. Needle clamp screw Needle clamp Flat side a:Rasie the Needle to highest position by turning the Hand Wheel counterclockwise, toward you, and lowering the Presser Foot Loosen the Needle Clamp Screw by turning it counterclockwise. -
Page 9: Thread And Needle Chart
PreparingToSew Thread and needle chart Needle Thread Fabric Size 80 to 100 fine silk thread silk, voile, lawn, 9(65) Never use a bent or dull needle. 80 to 100 fine cotton thread thin organdie, georgette, 80 to 100 fine synthetic fabric warp fabric 11(75) -
Page 10: Bobbin Winding
PreparingToSew Bobbin winding a: Spool Pin is used for holding the spool of thread in order to feed the thread to the machine. To use, pull the spool pin out and place the spool of thread over it, To store, remove the spool of thread and push back. -
Page 11: Threading The Upper Thread
Preparing To Sew Threading the upper thread We recommend you remove from the mains power before completing all these procedures. Tension area Check spring holder Thread guide Normal position a: Raise the Thread Take-up Lever to its highest position by turning the Hand Wheel towards you. -
Page 12: Threading The Bobbin Case
PreparingToSew Threading the bobbin case Ensure the Power Switch turned off when removing or inserting the bobbin case. Shuttle cover Bobbin case Latch Tension spring a: Remove the sewing table from the machine by pulling it to the left. Open the Shuttle Cove pulling down the tab on the left of the cover. -
Page 13: Drawing Up The Bobbin Thread
PreparingToSew Drawing up the bobbin thread Note: -Make sure you have correctly completed step 9 before staring this step. -Must rotate the hand wheel anticlockwise, toward you. Otherwise you can not draw the bobbin thread. Needle thread Bobbin thread a: Raise the presser foot. Hold the Needle thread lightly with your left hand and rotate the... -
Page 14: Thread Tension
PreparingToSew Thread tension Note: The bobbin thread tension has been adjusted at the factory and readjustment is not usually required. In order to obtain better zigzag stitches, the upper thread tension should be sightly weaker than the bobbin thread tesion. That means, the upper thread should appear slightly on the reverse side of the fabric, but the bobbin thread cannot... -
Page 15: Basic Sewing
Basic Sewing Note: needle in its The dial can not repeat rotating highest 360°, position Please reverse rotate from the arrow position arrow. Turn the Hand Wheel anti- clockwise to ensure the needle is higher than needle plate and fabric (keep the needle in its highest position) before rotating the stitch calibration tail... -
Page 16: Changing Sewing Directions
Basic Sewing Note: needle in its The dial can not repeat rotating highest 360°, position Please reverse rotate from the arrow position arrow. Turn the Hand Wheel anti- clockwise to ensure the needle is higher than needle plate and fabric (keep the needle in its highest position) before rotating the stitch selector or after sewing. -
Page 17: Basic Z-Stitch
Basic Sewing Note: needle in its The dial can not repeat rotating highest 360°, position Please reverse rotate from the arrow position arrow. Turn the Hand Wheel anti- clockwise to ensure the needle is higher than needle plate and fabric (keep the needle in its highest calibration tail calibration tail... -
Page 18: Finish Sewing
Basic Sewing Note: needle in its The dial can not repeat rotating highest 360°, position Please reverse rotate from the arrow position arrow. Turn the Hand Wheel anti- clockwise to ensure the needle is higher than needle plate and fabric (keep the needle in its highest position) before rotating the stitch selector or after sewing. -
Page 19: Utility Sewing
Utility Sewing Note: needle in its The dial can not repeat rotating highest 360°, position Please reverse rotate from the arrow position arrow. Turn the Hand Wheel anti- clockwise to ensure the needle is higher than needle plate and fabric (keep the needle in its highest calibration tail position) before rotating the stitch... -
Page 20: Three-Point Z-Seam
Utility Sewing Note: needle in its The dial can not repeat rotating highest 360°, position Please reverse rotate from the arrow position arrow. Turn the Hand Wheel anti- clockwise to ensure the needle is higher than needle plate and fabric (keep the needle in its highest calibration tail position) before rotating the stitch... -
Page 21: Blind Seam
Utility Sewing Note: needle in its The dial can not repeat rotating highest 360°, position Please reverse rotate from the arrow position arrow. Turn the Hand Wheel anti- clockwise to ensure the needle is higher than needle plate and fabric (keep the needle in its highest calibration tail calibration tail... -
Page 22: Decorative Stitch
Utility Sewing Note: needle in its The dial can not repeat rotating highest 360°, position Please reverse rotate from the arrow position arrow. Turn the Hand Wheel anti- clockwise to ensure the needle is higher than needle plate and fabric (keep the needle in its highest calibration tail calibration tail... -
Page 23: Sewing Buttonholes
Utility Sewing Note: needle in its The dial can not repeat rotating highest 360°, position Please reverse rotate from the arrow position arrow. Turn the Hand Wheel anti- clockwise to ensure the needle is higher than needle plate and fabric (keep the needle in its highest position) before rotating the stitch selector or after sewing. - Page 24 Utility Sewing Note: calibration tail The dial can not repeat rotating 360°, Please reverse rotate from the Step 1 arrow position arrow. Turn the Hand Wheel anti- clockwise to ensure the needle is higher than needle plate and fabric (keep the needle in its highest position) before rotating the stitch selector or after sewing.
- Page 25 Utility Sewing Note: The dial can not repeat rotating 360°, Please reverse rotate from the arrow position arrow. Turn the Hand Wheel anti- clockwise to ensure the needle is higher than needle plate and fabric (keep the needle in its highest position) before rotating the stitch selector or after sewing.
-
Page 26: Care Of Your Machine
Care Of Your Machine Cleaning shuttle race Turn off the power switch and unplug the machine before cleaning. Do not dismantle the machine other than as explained in this section. Shuttle race cover holder Shuttle race cover Shuttle Shuttle race To dismantle the hook race a: Raise the needle to its highest position and open the Shuttle cover... -
Page 27: Cleaning The Feed Dogs
Care Of Your Machine Cleaning shuttle race Turn off the power switch and unplug the machine before cleaning. Do not dismantle the machine other than as explained in this section. To assemble the shuttle race h: Hold the Shuttle by the center pin and fit it carefully back into the Shuttle Race , forming a... -
Page 28: Oiling The Machine
Care Of Your Machine Oiling the machine Turn off the power switch and unplug the machine before cleaning. Do not dismantle the machine other than as explained in this section. Face cover screw a: Remove the Face cover Loosen the Face Cover Screw and remove the Face Cover to left side. -
Page 29: Troubleshooting
Troubleshooting Trouble Causes Soulution 1.Improper top threading. 1.Threading the top thread again. (Refer to 2.Excessively tight top tension. page 9.) 3.Blunt or bend needle. 2.Adjust the top tension. (Refer to page 12.) 4.Improper fixing of needle. Top thread 3.Replace the needle. (Refer to page 6.) broken 5.At start of sewing, top thread and bottom 4.Reinstall the needle. -
Page 30: Specification
Specifications Specifications RedCat Model: Sewing Speed: 650±50 rpm Needle Size: 14# (90#) 70W(motor) + 1W (led lamp) Power: Voltage: AC 220~240V; 50Hz Press Foot Height: 5.7±0.2 mm Stitch Width: 4.5 mm Stitch Length: 3.6 mm Weight: G.W. 6kg / N.W. 5 kg Machine Size: 345 x 145 x270 mm Package Size:... - Page 32 ВАЖНЫЕ ПРАВИЛЫ ТЕХНИКИ БЕЗОПАСНОСТИ При использовании швейной машины следует всегда соблюдать основные правила техники безопасности, включая следующие: Прочтите все инструкции перед началом использования данной швейной машины. ОПАСНОСТЬ – Для снижения риска электрического удара: 1. Швейную машину никогда нельзя оставлять без надлежащего присмотра во включенном состоянии. 2.
- Page 37 (19), (26)
- Page 61 Брутто 6 кг/Нетто 5 кг мм ПРОИЗВОДИТЕЛЬ ZHEJIANG HENGQIANG SEWING MACHINE GROUP CO., LTD. CHINA ЧЖУНЬЦЗЯН ХЭНГКВИАНГ СЬЮИНГ МАШИН ГРУП КО., ЛТД. КИТАЙ ИМПОРТЁР В РОССИИ: АО ПКФ «ВЕЛЛЕС» 123308, Москва, проспект Маршала Жукова, д. 2, э. 3, пом. 1, к. 19, оф. А1К ИМПОРТЁР...
