Nos 25973NOS Installation And Operation Manual

MINI 2-STAGE PROGRESSIVE NITROUS CONTROLLER
25973NOS & 25974NOS
INSTALLATION AND OPERATION QUICK START GUIDE
FEATURES:
The NOS Mini 2-Stage Progressive Nitrous Controller is a fully
featured progressive nitrous controller offering control of up to 2
individual stages and can be fully programmed via a handheld LCD
touch screen display. An SD (Secure Digital) memory card reader is
built-in on the handheld controller to store and upload tunes and is
used for updates.
Solenoid operation can be controlled based on time, RPM, and/or
TPS input and can shut nitrous off at a programmed RPM ceiling.
The configurable nitrous and fuel ramps can be programmed in any
curve shape or with the built-in ramp builder app.
The controller housing is designed and constructed in a manner to
endure the typical harsh conditions found in a racing environment.
The controller can be mounted in the engine or passenger's
compartment. It is advisable to keep the controller away from direct
heat and severe vibration. Although not required, it is beneficial to
use rubber isolators when mounting the controller on applications
that may see severe tire shake, etc.
1
