SERIES CAFE MULTI-VOLTAGE
ELECTRIC ACTUATORS
Installation, operation, & maintenance instructions
Damage caused by non-compliance to these instructions will not be covered by our warranty. Read these instructions
BEFORE installing or connecting the actuator. Electric actuators operate with the use of live electricity. It is recommended
that only qualified electricians or people instructed in accordance with electrical engineering, and familiar with local
electrical, health and safety directives, be involved in the connection of these actuators. It is strongly recommended
that each actuator has its own independent fused system to protect it against the influence of other electrical devices
connected to the system. Follow instructions carefully. This unit is designed to be connected to equipment which can be
hazardous to persons and property if used incorrectly. Remove power to unit before wiring connections. Do not use unit if
plastic enclosure is cracked or broken.
