Klipsch CS-500 Specifications

2.1 Home Theater with DVD
Sleek, simple and small, the CS-500 home
theater system puts the ultimate cinema
experience right into your living room with
fewer wires and components. By applying
Dolby Virtual Speaker technology, this amaz-
®
ing little setup delivers the effect of a large, 5.1
home theater system with just two compact
speakers, a subwoofer, and an A/V center.
Each magnetically shielded (so it won't inter-
fere with your TV) speaker employs dual 2.5"
high-output woofers and a 0.75" horn-loaded
tweeter. Our Tractrix Horn technology is
®
what allows this system to deliver genuine,
lifelike sound as well as produce more output
using less energy.
The down-firing subwoofer utilizes a power-
ful 6.5" woofer. Due to its compact size, this
heavy-hitter can easily be hidden away while
still delivering dramatic low-end effects.
The A/V center features a built-in Class D
amplifier that distributes 35 watts of power
to each speaker and 100 watts of power to
the subwoofer. It also includes a progressive
scan DVD/CD player, AM/FM tuner, and three
auxiliary inputs. The CS-500 even has the
ability to pass high-definition signals through
a component output and can simplify all of
the auxiliary input connections into a single
convenient output to the TV. A universal IR
remote control directs all system functions as
well as those of the TV and other entertain-
ment devices.
Not only is it easier than buying separate audio
components, the CS-500 can be up and run-
ning in as little as 10 minutes. All you have to
do is connect the speakers, subwoofer and TV
to the A/V center using the color-coded wiring
and then plug in one power cord—it's that
simple. Available in a black finish, the CS-500
also has a clean, modern design that fits
comfortably into any living environment.
CS-500
• Dolby Virtual Speaker technology simulates 5-channel sound
®
• Progressive scan DVD/CD player, AM/FM tuner
• Three auxiliary inputs for games, MP3 players and other devices
• Universal IR remote controls entire system
• Speakers are wall mountable using ¼ - 20 inserts (not included)
• Compact, wired subwoofer delivers dramatic low-end effects
S p e c i f i c a t i o n S
frequency response
amplifier power Subwoofer: 100W continuous <=10% THD+N
Speakers: FTC rated 35 W/channel continuous,
crossover frequency
maximum acoustic output
high frequency horn
midrange
subwoofer
audio inputs
weight
Front Dimensions (HxWxD)
Subwoofer Dimensions (HxWxD)
Component Dimensions (HxWxD)
accessories
features
finishes
voltage
export voltage
All specifications are subject to change without notice. ©2008
41Hz to 20kHz ± 3dB
2 channels driven, <=1% THD+N
175Hz, 24dB/Octave
110dB
MicroTractrix Horn
2.5" paper cone
6.5" downward firing
Digital: coax, optical
Analog: line level
37 lbs (16.78kg)
8.6"x 4"x 5.5" (14.2 x 10.2 x 14cm)
15" x 11"x 18" (38 x 27.9 x 45.7cm)
3.5" x 15.5"W x 9.5" (8.9 x 39.4 x 24.1cm)
Included: controller, setup guide,
owner's manual, remote, batteries,
composite cable, audio cable, FM
antenna, AM antenna, two 15'
speaker cables, subwoofer cable,
rubber pads, white gloves
USB, JPEG, MP3, Dolby Digital, DTS,
FM/AM, Xvid, RDS
Controller: black plastic
Satellites: high-gloss piano
black plastic
Subwoofer: black medium density
fiberboard
120V
230V
