Summary of Contents for Global Fire Equipment IO-ISO
Page 1
Global Fire Equipment // g lobalfire.pt pm_io3ioplusmainsio_01_010003_en_200103 IO-ISO 3 I/O PLUS MAINS I/O PROGRAMMING MANUAL INTRODUCTION This manual explains in detail how to use and program the following modules: 3 I/O PLUS a ll variants IO-ISO MAINS I/O...
Page 2
Global Fire Equipment // g lobalfire.pt pm_io3ioplusmainsio_01_010003_en_200103 OUTPUT CONFIGURATION Output will activate when the programmed delay has elapsed. Alternatively an activation period can be programmed during which the output will be active. The output relay will revert to the OFF position once the time has elapsed.
Page 3
Global Fire Equipment // g lobalfire.pt pm_io3ioplusmainsio_01_010003_en_200103 Step by step OUTPUT configuration example OUTPUT MODE FUNCTION Let's assume that the desired OUTPUT MODE FUNCTION configuration is a delayed output. To obtain this configuration the following steps need to be taken: STEP 1: ...
Page 4
Global Fire Equipment // g lobalfire.pt pm_io3ioplusmainsio_01_010003_en_200103 INPUT CONFIGURATION There is a D elayed Input Activation Mode available. If this configuration is programmed, the Input will only report an Alarm after the input delay time has elapsed. Besides the delay, the Input can also be programmed to: 4K7 CLOSE TO ALARM: ...
Page 5
Global Fire Equipment // g lobalfire.pt pm_io3ioplusmainsio_01_010003_en_200103 The table below shows the available functions and correspondent values, as well as the DIL Switch configuration needed to obtain the desired output configuration. FUNCTION VALUE DIL SWITCH DIL SWITCH 4K7 CLOSE TO ALARM...
Page 6
Global Fire Equipment // g lobalfire.pt pm_io3ioplusmainsio_01_010003_en_200103 Step by step INPUT configuration example INPUT ACTIVATION MODE Let's assume that the desired INPUT ACTIVATION MODE configuration is SHORT CIRCUIT TO ALARM. To obtain this configuration the following steps need to be taken: STEP 1: ...
Page 7
Global Fire Equipment // g lobalfire.pt pm_io3ioplusmainsio_01_010003_en_200103 The Table below shows the DIL Switch values in order to configure the ONE ADDRESS MODE configuration. FUNCTION VALUE DIL SWITCH DIL SWITCH ONE ADDRESS MODE Step by step INPUT configuration example INPUT ACTIVATION MODE Let's assume that the desired ONE ADDRESS MODE configuration is ON.
