MANUAL 220909
ZMU
QUAD-ZMU 1Z/2Z/3Z/4Z
MADE IN PORTUGAL - EU
GLOBAL FIRE EQUIPMENT S.A.
Sítio dos Barrabés, Armazém Nave Y, Caixa Postal 908-Z, 8150-016 São Brás de Alportel - PORTUGAL | Tel: +351 289 896 560
Email: info@globalfire-equipment.com | Technical Support: techs@globalfire-equipment.com | www.globalfire-equipment.com
PROGRAMMING MANUAL
INTRODUCTION
This manual explains in detail how to use and program the following modules:
ZMU
QUAD-ZMU all variants
1
ZMU & QUAD-ZMU / Programming Manual / © GFE 220909
Advertisement
Table of Contents
Related Manuals for Global Fire Equipment ZMU
Summary of Contents for Global Fire Equipment ZMU
- Page 1 Sítio dos Barrabés, Armazém Nave Y, Caixa Postal 908-Z, 8150-016 São Brás de Alportel - PORTUGAL | Tel: +351 289 896 560 Email: info@globalfire-equipment.com | Technical Support: techs@globalfire-equipment.com | www.globalfire-equipment.com PROGRAMMING MANUAL INTRODUCTION This manual explains in detail how to use and program the following modules: QUAD-ZMU all variants ZMU & QUAD-ZMU / Programming Manual / © GFE 220909...
- Page 2 ON position. When Switch 8 goes from ON to the OFF position the settings indicated on Switches 1 through 7 will be recorded on the non-volatile memory of the module. If a new parameter has been accepted, the ZMU Green LED or QUAD-ZMU Yellow LED (Zone 1), will flash 4 times.
- Page 3 STEP 5: Set the desired device type using SW5 to SW7 (refer to table above). STEP 6: To save the new settings, set the Switch 8 to OFF position. If the new setting are valid, the ZMU Green LED or the QUAD-ZMU Yellow LED will flash 4 times.
