Klipsch CDT-2650-C Specifications

6.5" Two-Way Pivoting In-Ceiling Loudspeaker
With integrated whole-house audio systems
becoming more popular than ever, Klipsch
designed the CDT-2650-C to meet the
market's demand for a high-performance in-
ceiling loudspeaker that easily challenges the
inherent limitations of fixed locations.
Thanks to a new patent-pending gimbal
mechanism, known as
Dispersion Technology™ (CDT), both the
high and low frequencies of the CDT-2650-
C can be directed towards the listening area.
Because the tweeter is independently
adjustable from the woofer, this speaker
offers even more precise localization.
The CDT-2650-C features a 1-inch silk
tweeter mated to a swiveling 100-degree
Tractrix® Horn. This swiveling horn design
dramatically increases efficiency by enabling
the speaker to produce more output using
less energy. Additionally, a horn-loaded
tweeter works well in instances where you
want to point the sound to a specific location
because it has more controlled directivity
than a conventional dome tweeter.
The speaker's 6.5-inch polymer woofer also
has great positioning capabilities. It can
rotate a full 360 degrees and then shift 15
degrees in any direction. This flexibility
combined with the swiveling tweeter puts
you in complete control of where the sound
will go.
Available in a white finish, the paintable
CDT-2650-C can be paired with a Klipsch
IK-650-C installation kit (sold separately).
CDT-2650-C
This revolutionary kit design incorporates a mud ring, breakaway wire
tie and color-coded brackets for easy speaker size identification. It also
includes perforated metal wings that easily fasten to the studs via screws,
staples or nails. Painted white for easy marking and placement, these metal
wings can be folded around the edge of the studs if necessary.
Good sensitivity and power handling
I
Rugged ABS frame
Controlled
I
Paintable to match ceiling
I
S P E C I F I C A T I O N S
FREQUENCY RESPONSE
SENSITIVITY
NOMINAL IMPEDANCE
CROSSOVER FREQUENCY
POWER HANDLING
ENCLOSURE/MATERIAL TYPE
DRIVE COMPONENTS
WIRE GAUGE ACCOMMODATED
WEIGHT
DIAMETER
MOUNTING DEPTH
CUT OUT DIMENSIONS
INSTALLATION KIT
FIRE RATED ENCLOSURE
77Hz-20kHz ± 3dB
91dB @ 1 watt/1 meter
8 ohms
3070Hz
50 watts (200 watts peak)
ABS/Infinite Baffle, front flush
Two-way system using one 1"(2.5cm)
silk dome tweeter with a swiveling 100˚
Tractrix Horn and one 6.5" (16.5cm) pivoting
poly woofer
12
6.6 lbs. (3kg)
9.5" (24.1cm)
4.5" (11.4cm)
8.3" (21cm)
IK-650-C (sold separately)
ME-650-C (sold separately)
www.klipsch.com
1-800-KLIPSCH
All specifications are subject to change without notice. ©2004
