Vicon CE-IPS Series Installation And Operation Manual

Important Safety warning:
Read and keep these directions
Heed all warnings
Follow all instructions
Do not use this apparatus near water
Clean only with a dry cloth
Install in accordance with the
manufacturer's instructions
This installation should be made by a
qualified service person and should conform
to all local codes
See further safety instructions on page 5
INSTALLATION AND OPERATION MANUAL
CE-(X)IPS
HIgH-PowEr PoE MId-SPan InjECtor
The CE-8IPS and CE-16IPS are 8 and 16 port high power PoE midspans. They are
compatible with 10/100/1000 BaseT Ethernet networks.
They meet IEEE 802.3af and IEEE 802.3at standards and deliver up to 37 W per port
simultaneously on all ports without requiring power management. The PoE function can
be set up with Windows® GUI or use the default plug and play option. No IP settings
or configurations are required and they are completely transparent to the Ethernet
network and higher layer protocols.
LED indicators are provided for rapidly ascertaining the operating status of the device.
See Figures 3 and 4 on page 3 for LED explanations.
The CE-8IPS and CE-16IPS models are 1 RU high and can be easily installed in 19"
racks. See Figure A on page 4 for mounting instructions.
See Figures 1 – 5 for complete installation details.
