- Page 1 ED308 Smart employee card User manual_V2.0.0 ED308 LoRaWAN Smart Badge User Manual V2.0.0 Document Revision Record Version Time Description Remark V1.0.0 2020-03-28 Preliminary version Jack V2.0.0 2021-01-08 Optimize function Jack - 1 -...
- Page 2 ED308 Smart employee card User manual_V2.0.0 1. Description ED308 is an intelligent GPS tracker based on LORAWAN network transmission. It supports GPS and GLONASS dual-mode outdoor positioning and Bluetooth 4.0 indoor positioning. The positioning accuracy is 10 meters outdoor and 3~5 meters indoor. Through the intelligent tracker, beacons, LoRaWAN gateway and platform, it can realize the real-time positioning of staff and visitors.
-
Page 3: Led Indicator
ED308 Smart employee card User manual_V2.0.0 3. Interface 3.1 LED indicator Description Remark Status Lights up for 5 seconds after turn on, accompanied by a startup ringtone Lights up for 5 seconds when turned off, accompanied by a shutdown ringtone... - Page 4 ED308 Smart employee card User manual_V2.0.0 3.2 Buttons Description Remark Button/interface Press and hold 3S, immediately report location and alarm information When the platform downlink a message, motor vibrate, press 500ms SOS button to read Short press 3 times in succession (400ms once), broadcast signal strength of device Press and hold 5S to turn on the machine;...
-
Page 5: Specification
ED308 Smart employee card User manual_V2.0.0 4. Specification Parameter Spec Communication Build in LoRa module，Frequency： CN470MHz/EU868Mhz Bluetooth Building in Bluetooth Positioning Outdoor GPS positioning and indoor Bluetooth positioning Positioning accuracy 10~20 meters (outdoor) 3-5 meters (indoor) Gyro Build in Gyro, Supports power saving mode in non-motion state... - Page 6 ED308 Smart employee card User manual_V2.0.0 5. Operation guide（Platform Example） 5.1 User platform Each company has a dedicated administrator account, and employee accounts are limited to their own use. 5.2 Staff management The company administrator account can add, delete, and modify staff info according to the requirements.
- Page 7 ED308 Smart employee card User manual_V2.0.0 5.4 Automatic attendance setting You can check the data of the staff's on duty /off duty time, working time, and whether the work content is up to the standards, achieve intelligent attendance and performance evaluation.
- Page 8 ED308 Smart employee card User manual_V2.0.0 5.7 Positioning Map The administrator can set the company’s geographic location on the map and upload an indoor map. 5.8 Safety inspection The administrator sets the inspection site and the inspection task. When the employee with the corresponding devices starts the inspection.
- Page 9 ED308 Smart employee card User manual_V2.0.0 6. Device Operation guide 6.1 Power on Press and hold the power button 5S to turn on the device; RGB RED LED will be on for 5 seconds, and accompanied by a startup ringtone.
- Page 10 ED308 Smart employee card User manual_V2.0.0 positioning information and GPS positioning information). After successfully sending the alarm information, the motor vibrates. 6.8 Broadcast time Press the M button 3 times in succession (400ms once) to broadcast the current time. 6.9 Reset Short press reset button 1s to reset the device.
