- Page 1 TODD ENGLISH PRO-SMART™ OVEN Owner’s Manual Model: 20902 / 20901 / 20906 / 20905 Engineered by Questions or Concerns? Toll Free: 1-877-689-2838 • help@nuwavenow.com (Mon-Fri 7:30am-4:30pm CST)
- Page 2 PRODUCT REGISTRATION Thank you for purchasing the Todd English Pro-Smart Oven and welcome to the Todd English Cooking Family! Chef Todd English WELCOME REGISTER YOUR PURCHASE Congratulations on getting your new Todd Visit nuwavenow.com/QR English Pro-Smart Oven! I am incredibly...
-
Page 3: Table Of Contents
Power-Supply Cords........ 6 Meet Todd English Parts & Accessories ......7 Ordering Parts ......... 7 Todd English began his cooking career Assembly Guide ........8-9 at the young age of 15 when he first Before First Use........8 entered the doors of a professional Accessories .......... -
Page 4: Safeguards & Information
READ ALL INSTRUCTIONS and WARNINGS The failure to follow any of the import- ant safeguards, warnings, or instructions for safe use is a misuse of the Todd English Pro-Smart Oven that can void your warranty and create the risk of serious injury. When using the Pro-Smart Oven, only use the appliance as intended and for no other use, and always follow basic safety precautions. - Page 5 SAFEGUARDS & INFORMATION ALWAYS KEEP THIS MANUAL HANDY FOR FUTURE REFERENCE. 20. During use, steam may be released from the air outlet vents. Keep your hands and face away from these vents. Be careful of hot steam escaping when opening the Pro- Smart Oven.
-
Page 6: Power-Supply Cords
SAFEGUARDS & INFORMATION Power-Supply Cords A short power-supply cord (or detachable power-supply cord) is provided to reduce the risk of becoming entangled in, or tripping over, a longer cord. Longer detachable pow- er-supply cords or extension cords are available and may be used if care is exercised in their use. -
Page 7: Parts & Accessories
Part #: BEP2 ORDERING PARTS Over the lifetime of your Todd English Pro-Smart Oven, you may find yourself needing a new part or accessory, and if you do, NuWave has you covered. Ordering new parts and accessories is quick and easy. Simply take down the name and number for the part you want, then contact Customer Service. -
Page 8: Assembly Guide
ASSEMBLY GUIDE Before First Use Remove and discard any packaging material from the unit. Remove all accessories from their packaging and wash them in warm, soapy water or in the dishwasher, top rack only, except for the Probe. NEVER submerge the main unit in water. -
Page 9: Rack Positions
ASSEMBLY GUIDE Rack Positions The Todd English Pro-Smart Oven has 4 rack positions, with Position 1 at the bottom and Position 4 at the top, where most of your accessories can slide into the unit. When you select a cooking function, the appropriate rack number(s) will illuminate on the control panel. -
Page 10: Connectivity
CONNECTIVITY With the NuWave Connect App, you can operate your Todd English Pro-Smart Oven with your Smart Device using your home Wi-Fi network. WiFi Activation NuWave Connect App Downloading the NuWave Connect App Once the NuWave Connect App is down-... -
Page 11: Extending Control
CONNECTIVITY Extending Control A New Level of Cooking Remote control Controlling the Pro-Smart Oven with your using WiFi smart device is both easy and convenient with the NuWave Connect App. Make sure that the NuWave Connect App is installed on your smart device. Make sure the Pro-Smart Oven Wi-Fi is active and connected with your Wi- Fi 2.4GHz network. -
Page 12: Getting Started
GETTING STARTED The easy-to-use functionality of the Pro-Smart Oven is divided into Basic and Advanced functions, with the former offering the full cooking functionality of the unit and the latter giving you control over fan and heat strength and allowing you to program different cook- ing stages, features you will primarily use to create your own cooking Presets. -
Page 13: Helpful Tips
GETTING STARTED The LED Function Indicators—Preheat, Ready, Stage, Probe, Fan, Carryover, Sear, Rear, Top, Bottom, Menu, Shade and Slice—will light when that function is selected. Wi-Fi: Operate your NuWave Pro-Smart Oven with your Rack Smart Device. Level Air Fry Toast Preheat Ready Stage... -
Page 14: Primary Controls
GETTING STARTED Primary Controls Control Function Power The Power button turns the Pro-Smart Oven on and off. Heat: Press Heat/FAN until the heater to be changed appears, then adjust the rear, top, and/or bottom heat using the Select dial. The odd percentage of Top/Bottom heat defaults to the Heat/FAN bottom. -
Page 15: Basic Key Functions
GETTING STARTED Control Function Provides access to the unit’s Cooking Presets. Press Menu once for Presets 1–100, or twice for Presets 101–150. Once Menu the Preset is selected press START/PAUSE to begin cooking. Refer to the 100 Presets on the back of the Quick Start Guide. You can save 50 of your own. -
Page 16: Using The Accessories
GETTING STARTED Using the Accessories Grill/Griddle Air Fry Function Grill/Griddle Wire Rack Rack Basket Air Fry Grill Bake* Broil* Air Roast Toast Pizza* Proof Dehydrate Cookie* Defrost* D.I.Y. Oven Poach* Rawtarian* Reheat* Sanitize* Slow Cook* Slow Roast* Warm* Whole Roast* *Use an oven-safe baking/cooking pan when using the Wire Rack. -
Page 17: Quick Start
GETTING STARTED Quick Start Adjusting Default Temp & Time Formats Press the Power button to turn the Pro- Smart Oven on or off. • Each function will flash in turn Default Temperature Format before defaulting to Air Fry. To change the default temperature format •... -
Page 18: Basic Functions
With its numerous Cooking Presets and fea- tures, the Pro-Smart Oven’s suite of Basic Functions offers you all you need to make The Todd English Pro-Smart Oven has three delicious, healthy meals quickly and easily. heat sources, Top, Bottom, and Rear. The Rear heater is part of the large rear fan assembly. -
Page 19: Cooking Functions
BASIC FUNCTIONS Cooking Functions The Pro-Smart Oven has 20 Cooking Functions to help take the guesswork out of cooking. Air Fry is the default function, but to access the remaining 11, begin by pressing Function. The highlighted function will change from “Air Fry” to “Grill”. Now, turn the Select dial or continue to press Function until you reach the Cooking Function you want. - Page 20 BASIC FUNCTIONS #7. Pizza Flattened dough with a combination of toppings that is baked. Defaults Heat Rack Position Temp: 400°F Top: Bottom: 1 or 2 Time: 15 min. Rear: #8. Proof Resting raw, kneaded dough to allow it to rise before baking. Defaults Heat Rack Position...
- Page 21 BASIC FUNCTIONS #13. Oven Poach To cook with a small amount of liquid. Defaults Heat Rack Position Temp: 300°F Top: Bottom: 2 or 3 Time: 20 min. Rear: #14. Rawtarian To cook foods at temperatures between 104F–118F. Defaults Heat Rack Position Temp: 115°F Top:...
-
Page 22: The Menu Function
BASIC FUNCTIONS The Menu Function The Menu button allows you to save and save it. “SAVE” and the Preset number recall pre-programmed cooking sequenc- will be displayed. Press START/PAUSE and the Pro- es called Presets. They are stored with a unique number, which you can access by Smart Oven will begin cooking. -
Page 23: The Preheat Function
BASIC FUNCTIONS Modifying Previously Saved • If you choose to save a Preset in a Presets While Cooking slot that is already taken by another Press Menu twice and select the user-saved Preset, the new Preset will saved Preset from 101–150. overwrite the old one. -
Page 24: The Probe Function
BASIC FUNCTIONS • When the Pro-Smart Oven has finished To set the Probe target temperature, cooking, the screen will show “END” and press and hold Probe. The screen will the Pro-Smart Oven will beep three (3) show “Probe”, and “165°F”. Turn the Select dial to adjust the Probe target times. - Page 25 BASIC FUNCTIONS Probe Temperature Guide Med. Med. Meats Temp Rare Med. Well Rare Well Chicken, breast Turkey, breast 360°F 165°F Duck, breast Chicken, whole Turkey, whole 360°F 165°F Duck, whole Chicken, thigh Turkey, thigh 360°F 165°F Duck, thigh Steak, 1-inch thick* 450°F 120°F 130°F...
-
Page 26: The Mute Feature
BASIC FUNCTIONS The Mute Feature The Lock Feature To mute or unmute the Pro-Smart Oven’s The Lock Feature is used to disable the Pro- alert sounds, press Sear + STAGE. To Smart Oven’s keypad, preventing mute or unmute the door alarm sounds, it from responding to most actions until press and hold Function. -
Page 27: Advanced Functions
ADVANCED FUNCTIONS Stage with Probe The Todd English Pro-Smart Oven’s Ad- Each stage can have a different Probe tar- vanced Features are primarily for expe- get temperature and cooking temperature. rienced cooks who are trying to achieve Set the Probe target temperature for... -
Page 28: The Slow Cook Function
ADVANCED FUNCTIONS The Sear Function uses the Top and Bottom Cooking Cycle Begins heaters to seal in flavor and juices. You can • Sear 1 / Toast sear your meat before, after, or both before • Function / Menu / Probe / Stage 1–5 and after, the regular cooking stages. - Page 29 ADVANCED FUNCTIONS You may set the Slow Cook Function to • The Slow Cook cooking tempera- cook for a set amount of time AFTER reach- ture shall be at least 10°F higher ing the Slow Cook Probe target tempera- than the Probe target temperature. ture: If the Probe target temperature Press and hold Probe.
-
Page 30: Care & Maintenance
CARE AND MAINTENANCE Before First Use Remove all the packaging When the glass window is completely materials. cool, spray glass cleaner on a clean Remove the tape and labels on cloth towel. Clean both the inside and the appliance. outside of the window. Use a damp Clean the Wire Rack, Grill/Griddle cloth to rinse the window then dry it Rack, Grill/Griddle, Air Fry Basket,... -
Page 31: Replacing The Lightbulb
CARE & MAINTENANCE Replacing the Lightbulb Allow the interior of the oven to fully cool before replacing the oven’s halogen- light bulb. Failure to do so could result in burns or damage to the glass cover or the light bulb itself. Always wear rubber Unscrewing the Retaining Bolt gloves when changing the lightbulb and be... -
Page 32: Troubleshooting
TROUBLESHOOTING The Pro-Smart Oven is engineered with an automatic shut-off feature to prevent overheat- ing during use. If the Pro-Smart Oven shuts off to cool itself down, an odor may be detect- ed. Unplug the Pro-Smart Oven and wait for it to completely cool down. To prevent the Pro-Smart Oven from overheating, do not cook foods at higher temperatures or for longer times than recommended. -
Page 33: Limited Warranty
LIMITED WARRANTY THE MANUFACTURER WARRANTS NuWave, LLC warrants that Pro-Smart Oven will be free from manufacturer defects for 1 year from the date of purchase, under normal household use, and when operated in accordance with the Manufac- turer’s written instructions. The Limited Warranty covers the Original Purchaser only. The Manufacturer will provide the neces¬sary parts and labor to repair the product at the NuWave LLC Service Depart- ment. - Page 34 LIMITED WARRANTY DISPUTE RESOLUTION PROCEDURE For disputes relating to use of the website or use or purchase of a NuWave product or service (collec- tively “Disputes”), you agree to first contact NuWave LLC at (877) 689-2838, or legal@nuwavenow. com. If we cannot resolve your dispute informally, any and all disputes shall be submitted to final and binding arbitration.
- Page 35 NOTES nuwavenow.com | 35...
- Page 36 TODD ENGLISH FOR HOUSEHOLD USE ONLY 120VAC, 60Hz, 1800 Watts Model: 20902 / 20901 / 20906 / 20905 Para la versión en español de este manual, visita www.nuwavenow.com. For patent information please go to: www.nuwavenow.com/legal/patent Designed in France & Developed in USA NuWave LLC 560 Bunker Ct.
