- Page 1 Wiegand Controller Art. No.: 460116 User manual Wiegand_usermanual_ENGjun15 Conlan ApS • Speditorvej 2A • DK-9000 Aalborg • Tel: +45 72 40 60 03 • Fax: +45 96 32 00 22 www.conlan.eu • info@conlan.eu...
- Page 2 Two way - One door controller Specifikations: • Controller for one door, 2 readers • Space for 511 user codes/tags + 1 Master code/tag • 3584 off-line events with date and time stamp • Real time clock • Backup battery for clock, EEProm memory • Dual-processor • Fully stand alone or networkable •...
- Page 3 Note: 1. In case that you are using just one reader let the other inputs unconnected 2. In case that you are not using door contact input, short circuit with a wire between COM and CM. By default door contact input is NC. Jumper configuration: J1 - Alarm relay NO or NC J2 - Locking device relay NO or NC J3 - Communication port , RS232 or RS485 Programming: By default, the following parameters are set: • Master code defined (4711) • No user codes/tags defined • Door unlock time = 5 seconds •...
- Page 4 “Delete first tag enrolled after (as position) presented tag”. Again, it is very important to note all positions of tags enrolled or deleted. Stand alone reset and Master code/tag programming. The Master code/tag can be programmed in the following steps: 1. Power off 2. Disconnect the CM input 3. Short circuit a wire between LED output and CM input 4. Power on 5. Wait approx. 3 seconds of LED flashing, the system goes into “Program code/tag” phase, as shown by LED/ buzzer 6. Key in/present the code/tag that you want to become Master code/tag 7. At exit of programming user phase power off the system 8. Remove the wire between CM and LED 9. Reconnect the CM wire from the magnetic contact 10. Power on For security reasons, all users will be deleted before keying/enrolling Master code/tag. The system goes in “Pro- gram code/tag” and since all users are deleted, the first code/tag programmed in position 0 becomes Master code/tag. Thank you for choosing Conlan’s products. For further assistance, please contact Our support service.
