Conlan Wiegand CT 1200 Family Manual

Art. No. Short name Description
460110 CT 1200
Art. No. Short name Description
460111 PR 1200
Art. No. Short name Description
460194 BioTag Office
Art. No. Short name Description
460116 Wiegand Con Controller 5000 for Wiegand installations. 26 bits:
Keypad for Wiegand installations:
Format 26/8/4
26 bits for whole code. 8/4 bits for each digit. Set up
on site by short cut wires and power up.
External controlling of the LED´s and the buzzer.
IP 67, 12 VDC
2,5 m cable 8 cores
Works together with the Conlan 5000 Wiegand
controller for up to 512 users.
Prox Reader for Wiegand Installations:
Format 26 bits
External controlling of the LED´s and the buzzer.
IP 67, 12 VDC
2,5 m cable 8 cores
The reader can be delivered in a smaller unit.
Works together with the Conlan 5000 Wiegand
controller for up to 512 users.
Fingerprint reader for Wiegand installations:
Format 26 bits
Stand Alone.
External controlling of the LED´s and the buzzer.
2,5 m cable, 12 cores, IP 67, 12 VDC
Works together with the Conlan 5000 Wiegand
controller for up to 512 users.
For 1 door. In and out Reader. Door contact. REX
contact. Relays (2 pcs) for door and alarm. Output for
LED/Buzzer in Readers. 232 communication to PC and
485 for networking. Log in the controller for 3500 logs.
Incl Windows quick setup program. Stand alone
Programming of cards/transponders or by computer.
Enrolling, deleting all cards, mastercard, single cards,
missed cards etc.
Wiegand
CT 1200 Family
Wiegandv.2 Man. ENGjun12
