- Page 1 FORMAT NO- IE/DD/15(1) REV. DATE- 22.02.19 INITIATIVE REV. NO.- OPERATION MAINTENANCE MANUAL MEGA...
-
Page 2: Scope Of Supply
Features • Backlit LCD Display • User-friendly knob linked with digital display for adjusting dosing frequency with facility of password lock • Built-in ARV with separate discharge point to prevent chemical spill on hands • Diaphragm made of solid PTFE to ensure maximum life •... - Page 3 Installation (Dosing Pump) Installation (Dosing Pump) Always wear protective clothing, face shield, safety glasses gloves when working on near your metering pump. Additional precautions should taken depending solution being pumped. Pump protected from sun and rain. outdoor installation unavoidable, provide a canopy...
- Page 4 Typical mounting set up schematic Startup Switch on the mains power supply to the pump. Press the ON/OFF key to start the pump. Turn the frequency knob fully clockwise so that the display shows 099 (This is the maximum frequency setting of the pump).
- Page 5 Technical Specifications Dosing Turn Down Ratio 10:1 Maximum Dosing Capacity 11.36 Minimum Dosing Capacity Maximum Operating Kg/cm² Pressure Maximum Stroke strokes/min. Frequency Mechanical Stroke Volume Data Accuracy of ±2 Repeatability Maximum Suction Lift During meter Operation Min. / Max. Liquid ⁰...
- Page 6 GA Drawing...
- Page 7 Product Drawing Edose Dosing Head Exploded View...
-
Page 8: Part List
Part List NRV BALL HOUSING DOSING HEAD ‘O’ RING (O 76X3.5 VT) -
Page 9: Troubleshooting
Trouble Shoot Problem P ossible Causes Trouble Shooting Excessive Pump Syphoning Move injection point Output pressurized point Make sure Little or pressure injection injection check valve point Excessive strokes minute installed properly Consult factory Pump will Pump turned plugged Turn pump/plug prime/loss priming demand... - Page 10 Essential Safety Requirement Install the pump in any shaded place away from direct sunlight. The pump can not be used fin sub-merged condition. Before starting work on the pump, the pump must be disconnected from the power supply. The system must be pressure less! ...
