quanergy QPU-L7 Quick Start Card

QPU-L7 with
Server Quick Start Card
Thank you for purchasing the Quanergy Processing Unit-L7 (QPU-L7™) host computer for Q
(formerly Q-Guard™) server software. This card summarizes how to use this system with Quanergy LiDAR
sensors, including M8™-Core, -Plus, and -Ultra models (Rev D and up) and M8 PoE+ (Rev A and up).
Overview
The QPU-L7 is a Linux®-based computer with Q
operation, data collection, and surveillance. The QPU-L7 can accept inputs from up to six M8 sensors.
The QPU-L7's Ethernet network capacity is sufficient to support the raw data stream from sensors.
Q DTC is a LiDAR-based 3D perception and volumetric sensing solution that enables the detection,
ORTEX
tracking, and classification (DTC) of human objects for security, people movement, and analytics.
The Q DTC server receives input from the M8 sensors and publishes output to the user's network
ORTEX
infrastructure. That output is consumed by a Q
The Quanergy-installed server on the QPU-L7 is ready to run as soon as you turn it on and activate a
license. (On the same network, the client is user-installed on a separate Linux machine as explained in
the Q DTC 1.x User Guide, and M8 sensors are installed as explained in the M8 Sensor User Guide or M8 PoE+
ORTEX
Sensor User Guide. Referenced documents are listed below.)
Specifications
Hardware Central Processing Unit
Random Access Memory
Storage Memory
Display Port
Serial Port
USB Port
Ethernet Network Port
Software Operating System
Documents
For important details, refer to https://quanergy.desk.com/customer/portal/articles/2923379 and:
• Cincoze DS-1100 Series User's Manual — http://www.cincoze.com/data/files/201708/Manual_DS-1100_R1.3_20161107004.pdf
• M8 Sensor User Guide — https://quanergy.desk.com/customer/portal/articles/2687038
• M8 Sensor Quick Start Card — https://quanergy.desk.com/customer/portal/articles/2687032
• M8 PoE+ Sensor User Guide — https://quanergy.desk.com/customer/portal/articles/2959430
• M8 PoE+ Sensor Quick Start Card — https://quanergy.desk.com/customer/portal/articles/2959431
• Q DTC 1.x User Guide — https://quanergy.desk.com/customer/portal/articles/2755121
ORTEX
• Q DTC 1.x Quick Start Card — https://quanergy.desk.com/customer/portal/articles/2755133
ORTEX
• QPU-L7 with Q DTC Server Quick Start Card — https://quanergy.desk.com/customer/portal/articles/2920478
ORTEX
• Q-View User Guide — https://quanergy.desk.com/customer/portal/articles/2717074
• Q-View Quick Start Card — https://quanergy.desk.com/customer/portal/articles/2748632
DTC
DTC server software pre-installed for sensor
ORTEX
DTC client and/or third-party application.
ORTEX
Intel® i7-6700TE up to 3.4 GHz 4-core processor
16 GB RAM DDR4-2133
Primary drive: 64 GB for OS and applications
Secondary drive external bay
Video, standard Intel chip set capability
RS232 or RS422 (2x)
USB 3.0 (2x) for high speed devices such as extra memory
USB 2.0 (2x) for user input devices
LAN 10/100/1000 RJ45 (x2)
Linux 16.04
DTC™
ORTEX
