- Page 1 Fiber Meter Series Specification & User Manual Optical Power Meter Bluetooth Version 850nm/1310nm/1550nm Document Number SGD-0220-001-01 Part Number AFT-G-FM-3DG-BT-SM-MM Issued By: Engineering Dept. Reviewed By: MP Approved By: AB Date: 12/02/2020 www.senko.com...
-
Page 2: Table Of Contents
Document Number: SGD-0220-001-01 Table of Contents 1. Disclaimer ......................3 2. Range of Limitations ..................3 3. Description ......................3 4. Dimension and Materials................3-4 5. Specifications ....................4-5 6. Features ......................5 7. Guide ……………………………………………………………………………...….6-7 8. Operating Instructions………………………………………………….……………7 9. Maintenance…………………………………………………………………..………..8 10. Software Interface…………………………………………………………………..8-9 11. Shipping Information…………………………………….………………………..….9 12. -
Page 3: Disclaimer
FM-3DG-BT-SM-MM. Description SENKO Bluetooth Power Meter is mainly used for checking the signal output power of the optical communication equipment in the fiber optic networks. The device measures the average power of a continuous light beam emitted from the source. Operating wavelengths 850nm/1310nm/1550nm. -
Page 4: Specifications
Document Number: SGD-0220-001-01 Specifications Wavelength (Multimode) 850nm Optical Power Range (Multimode) -40 dBm - +5 dBm Wavelength (Singlemode) 1310 nm / 1550 nm Optical Power Range (Singlemode) -40 dBm - +5 dBm Batteries 2 x AAA (1.5V) Resolution 0.1 dB Accuracy <+/- 0.3 dBm Fiber Connector... -
Page 5: Features
Document Number: SGD-0220-001-01 Storage Temperature 0℃~ 70℃ Weight 0.06 kg Dimension 132mm x 32mm x 19mm Features LED digital display. Universal 2.5mm/1.25mm adaptor for SC / ST / FC to LC/MU. Mobile App for Android / iOS / Windows Platforms. ... -
Page 6: Guide
Document Number: SGD-0220-001-01 Guide Remove Battery Lit to Change Slide Battery Lid Backward Batteries. 1. Dust Cap: to prevent dirt contaminating the PD. 2. Switch: Modify wavelength by sliding the switch. 3. LED: Figures show various readings you may encounter. 4. -
Page 7: Operating Instructions
Document Number: SGD-0220-001-01 5. Pen Clip: to fasten the tool. 6. Battery Lid: open to change batteries. 7. Linchpin: lock the battery lid. Operating Instructions The Fiber Meter is powered by two 1.5v AAA batteries. INITIAL CALIBRATION: Keep the Dust Cap closed and then turn on the Fiber Meter by pressing the Button. -
Page 8: Maintenance
Document Number: SGD-0220-001-01 Maintenance This tool requires no maintenance other than periodic battery charges. Like any other electronic equipment, this tool should be kept away from water, high damp, dust, electricity, and environments of extreme temperature. Do not drop this tool on hard surface. -
Page 9: Shipping Information
All items are packed in a secure fashion so as to prevent any damage during transit. Warranty SENKO warrants this product to be free of defects in workmanship and materials for a period of 1 year after purchase. This warranty (excluding batteries) is solely limited to the repair and replacement of original parts, which are defective in workmanship of materials. -
Page 10: Ordering Information
Document Number: SGD-0220-001-01 does not cover any defects, damage, and deterioration due to misuse, alteration, or negligence. Ordering Information Part Number Product Type Wavelength (nm) Range (dBM) +5dBm – 40dBm AFT-G-FM-3DG-BT-SM- 3 Digits SM/MM 850/1310//1550 AFT-G-CAM 2.5mm to 1.25mm adapter Contact Information 10 | P a g e...
