TIME LED 780930 Installation And Operating Instructions

Elements Range: 22W LED Single NCF (4ft)

Package includes:

1 x Elements 22W LED Single NCF (4ft)

1 x Manual

• Equipped with rubber protection gland and nylon cover protector

• Wiring specification: only use H07RN-3 x 1.0mm2 (WARNING: Do Not Use PVC Cable)

• Degree of protection: IP65

• Suitable for ceiling mount or suspension

• Operating voltage: AC 220-240 Volts / 50/60 Hz

• LED Lamp

• Class I Luminaire.

Safety:

• Electrical work, including installation and repair, must always be completed by a qualified technician.

• Disconnect the lamp from the mains supply, and let the product cool down before you replace the light source.

• Never touch the light source when the lamp is turned on.

• In case of product failure, disconnect the lamp from the mains supply.

• The product is not suitable for connecting through to multiple units.

TIME LED is part of Pitacs Limited. For customer support contact:

Bradbourne Point, Bradbourne Drive, Tilbrook, Milton Keynes, Buckinghamshire MK7 8AT

T: +44 (0)1908 271155 F: +44 (0)1908 640017 E: info@timeled.co.uk W: www.timeled.co.uk

Installation and Operating Instructions

22W

=176W

Read and follow instructions before operating your light.

Save this manual for future reference.

015

INS-780930-V1

Table of Contents

Do you have a question about the 780930 and is the answer not in the manual?

Page 1 • The product is not suitable for connecting through to multiple units. INS-780930-V1 TIME LED is part of Pitacs Limited. For customer support contact: Bradbourne Point, Bradbourne Drive, Tilbrook, Milton Keynes, Buckinghamshire MK7 8AT T: +44 (0)1908 271155 F: +44 (0)1908 640017 E: info@timeled.co.uk W: www.timeled.co.uk...
Page 2 Product Code 780930 Colour Temp 4000K Cool White Size (mm) 1270x68x70 Material Lamp Dimmable Watts Class Class I Equivalent Watts 176W Voltage/Hertz 220-240V 50/60Hz Lumens 2300±5% Warranty 3 Years Lifespan 25000 hours Energy Rating Beam Angle 120° IP Rating IP65...
Page 3 Installation: Note: When installing the suspension bolt or chain, ensure all apertures are fully sealed to maintain IP integrity. 1. Open locking buckle Buckle 2. Install locking buckle 3) The cable gland should be fitted tightly after installing the power cord. The length of the main cable fed into the lamp through the gland should be no less than 17.5cm.
Page 4 • This product is warranted to be free of defects in materials, design and workmanship for 3 years from the date of purchase (conditions apply, please see TIME LED website for further details). If a suspected fault should develop in this time, please contact us via the address on the front.
