KitchenAid KORU06RSSS Dimensional Drawing

PRODUCT MODEL NUMBERS

KORU06RS KRCA06XR
Electrical: A 115 Volt, 60 Hz., AC only 15– or
20–amp fused, grounded electrical supply is
required. It is recommended that a separate
circuit serving only your refrigerator be
provided. Use an outlet that cannot be turned
off by a switch. Do not use an extension cord.
Because Whirlpool Corporation policy includes a continuous commitment to improve
our products, we reserve the right to change materials and specifications without notice.
®
Refrigerator

OVERALL DIMENSIONS

Dimensions with Casters Installed

26 "
(66.4 cm)
31"
(78.7 cm)

Dimensions with Leveling Legs Installed

26 "
(66.4 cm)
31"
(78.7 cm)
Dimensions are for planning purposes only. For complete details, see Installation
Instructions packed with product. Specifications subject to change without notice.
23 "
(60.3 cm)
24"
(61.0 cm)
37"
(94.2 cm)
34 "
(87.6 cm)
23 "
(60.3 cm)
24"
(61.0 cm)
35 "
(89.2 cm)
34 "
(87.6 cm)
Ref. 2311008
04-13-07
