Model KGCC566 (36 in. [91.4 cm] shown)
Model KGCC505 (30 in. [76.2 cm] not shown)
4
3
2
1
1. Left Front Burner Control Knob
2. Control Knob Off Position
5
4
3
2
1
1. 14,000 BTU Burner
2. Surface Burner Cap
3. Left Surface Burner Grate
4. Model and Serial Number Plate
(under cooktop)
3. Left Rear Burner Control Knob
4. Center Rear Burner Control Knob
(on 36" models only)
5. 6,000 BTU Burner (9,100 BTU Burner on 30"
models)
6. 9,100 BTU Burner
(on 36" models only)
7. Center Grate
5
6
5. Right Rear Burner Control Knob
6. Right Front Burner Control Knob
8. 12,500 BTU Burner
9. Right Surface Burner Grate
10. 6,000 BTU Burner
11. Control Panel
6
7
8
9
10
11
5
