- Page 1 INSTALLATION & MAINTENANCE GUIDE Low Voltage Landscape Lighting ® ONE RGBW HydraPro™ Single Source LED In-Grade Light (Dimmable) ® AWL-5010IR-B-BZ Help Hotline: 1-813-978-3900 • Mon-Fri 9am-6pm (EST) w w w. a m p l i g h t i n g . c o m...
-
Page 2: Important Safety Instructions
INSTALLATION & MAINTENANCE GUIDE ONE RGBW HydraPro™ Single Source LED In-Grade Light (Dimmable) ® AWL-5010IR-B-BZ Important: Please Read Before Installation This fixture is intended for installation in accordance with local codes and the National Electric Code (NEC). Failure to adhere to these codes and instructions may result in serious injury, property damage and void the warranty. - Page 3 Package Contents A. (1) Fixture body Parts Required (sold separately) A. Mounting Accessory Product Dimensions 4” 2” customersupport@amplighting.com • 813.978.3900 –3–...
- Page 4 INSTALLATION & MAINTENANCE GUIDE ONE RGBW HydraPro™ Single Source LED In-Grade Light (Dimmable) ® AWL-5010IR-B-BZ Install Stake Determine the desired location for mounting the fixture. Ham- Board mer the stake into the ground until flange of stake is flush to grade.
- Page 5 Wire Connections Pigtail Wire Connectors Main Supply Cable Strip both leads from the luminaire pigtail. Using two wire connectors (sold seperately), connect the leads from the luminaire to the main supply cable. Install/Replace Glare Guard Remove Faceplate Loosen the screws and remove the Screw faceplate from the fixture.
- Page 6 INSTALLATION & MAINTENANCE GUIDE ONE RGBW HydraPro™ Single Source LED In-Grade Light (Dimmable) ® AWL-5010IR-B-BZ Install Glare Guard Attach the glare guard onto the fixture and secure it with the screws previously removed. Screw Glare Guard Now you can power on the system, the light is 2700K and the optic is 60 degrees as Fixture...
-
Page 7: Ir Remote (Optional)
Replace Optic Loosen the screws and remove the optic from the fixture. Screw Install the new optic in the Optic fixture. Make sure that you have the optic properly aligned over the LED board before tightening down. Improper alignment when fixture tightening the screws can cause the optic to break. - Page 8 INSTALLATION & MAINTENANCE GUIDE ONE RGBW HydraPro™ Single Source LED In-Grade Light (Dimmable) ® AWL-5010IR-B-BZ Install Two AAA Batteries AAA Battery Battery Place two AAA batteries into the Compartment battery compartment properly. IR Remote Backing Install the Battery Compartment Cover Place the battery compartment cover back onto the IR Remote.
-
Page 9: Ir Remote Functions
IR Remote Functions 1. On 2. Off 3. Brightness Control 4. 16 color selections 5. Flash A. Mode 1: Repeats Red, Green, Blue + color cycle for 1 second duration of each of the seven colors within this FLASH mode. STROBE A. - Page 10 INSTALLATION & MAINTENANCE GUIDE ONE RGBW HydraPro™ Single Source LED In-Grade Light (Dimmable) ® AWL-5010IR-B-BZ w w w. a m p l i g h t i n g . c o m –10– –10–...
- Page 11 customersupport@amplighting.com • 813.978.3900 –11–...
- Page 12 Help Hotline: 1-813-978-3900 • Mon-Fri 9am-6pm (EST) Specifications and product details subject to change without notice. © Copyright 2022, AMP Lighting, Lutz FL USA 33549 • All rights reserved. ® customersupport@amplighting.com • 813.978.3900 w w w. a m p l i g h t i n g . c o m...
