Metria HC-520 Operation Manual

Operation Manual for IN/OUT Temp. & Humidity Meter

1 General Description:

HC-520 IN/OUT Temperature & Humidity Meter is characterized as:
* multi-function
* low power consumption
* high stability & accuracy
* memory of last measuring value

2 Features:

* INDOOR and OUTDOOR temperature measuring
* display temperature and humidity simultaneously
* MIN and MAX value recording
* Comfortable degree symbol
* ℃/℉ unit selectable
* Desk-top placing or Wall Hanging

3 Specification:

* Temperature range:
* humidity range: 20%~99%RH
* resolution:
* accuracy:
* power supply: 1.5V (AAA size) x 1
* product dimension: 78 x 98 x 17 mm
* weight: Approx. 95g
storage condition: -20℃~60℃, 20~80%RH
*
HC-520
Model No.
IN side temperature: -10~+50℃（+14~+122℉）
OUT side temperature: -50~+70℃（-58~+158℉）
temperature: 0.1℃ (0.1F)
humidity: 1% RH
temperature: ±1℃（-20~60℃），±2℃（other）
humidity: ±5%RH (20%~99%，at 25℃）
