VS 1200 FL
Full opening discharge valve
Suitable for use as a drain valve in high pressure systems.
CONSTRUCTION MATERIAL
Nominal temperature (1)
Nominal diameter
Part nr.
Rated pressure
bar MPa
60.3000.00 1000 100
(1)
The valve has been designed for a continuous use at a water temperature of 60°C. It can resist for short
periods at a maximum temperature of 90°C
Web: http://www.pa-etl.it – E-mail: info@pa-etl.it
•
60.3000.00
- Full opening in case of dangerous overpressure
that could damage the system.
- Deactivation of the trigger only through the
system shutdown for maximum safety.
- Ball valve for better sealing.
- High trigger accuracy.
- Tested to ensure maximum reliability.
- Seal seat available as a spare.
- Fixing studs.

TECHNICAL SPECIFICATIONS

Permissible Minimum ad-
pressure justable pres-
sure
bar MPa bar MPa
1200 120 200 20
Technical manual: MPA0015EN
BRASS BODY AND INTERNAL PARTS IN SST
90°C
DN10
Minimum flow Maximum
rate flow rate
l/min l/min
9 40
Ultimo Aggiornamento: 08/10/20
G3/8" F
Weight Inlet
outlet
BYPASS
g
G 3/8" F
2220
