Go Power DOMETIC GP-AGM-224-6V Quick Start Manual

BATTERY SPECIFICATIONS

SPECIFICATIONS
Technology AGM, VRLA deep cycle battery
Nominal Voltage 6 V
Rated Capacity
224 Ah/11.2A; 194 Ah/19.4A; 179 Ah/
77°F (25 ±5 °C)
35.9A
104°F (40°C) 103%
Capacity Correction for
77°F (25°C) 100%
Temperature Variations
32°F (0°C) 86%
Maximum Discharge
2000 A (5s)
Current
Specific Energy Density 44.07 Wh/kg
Volumetric Energy Density 116.27 Wh/L
Approx. 1.4mΩ
Internal Resistance
T11
Terminals
Torque: 11 ~ 14.7 Nm (97.28 - 130 in*lbs)
100% Depth of Discharge ~ 250 cycles
Cycle Life
50% Depth of Discharge ~ 1100 cycles
77°F (25°C)
30% Depth of Discharge ~ 2250 cycles
Certifications UL; CE; IEC60896-21 & 22
Charge:
Temperature Range
Discharge: -15~50°C (5~122°F)
Storage:
Initial Charging Current less than 30.0 A
Cycle Use Voltage: 7.2 V~7.4 V at 77°F (25°C)
Temp. Coefficient -30mV/°C
Cold Cranking Amps (CCA) 900
No limit on Initial Charging Current
Standby Use Voltage: 6.8 V~6.9 V at 77°F (25°C)
Temp. Coefficient -20mV/°C
Batteries can be stored for up to 6 months
before a freshening charge is required.
Self Discharge
*Batteries stored at temperatures
greater than 77°F (25°C) will require a
recharge sooner.
0~40°C (32~104°F)
-15~40°C (5~104°F)

WARNINGS

- Risk of fire if battery not installed correctly.
- Use caution with metallic objects near battery terminals.
- Keep terminals protected to prevent accidental shorting.
- Disconnect immediately if battery excessively hot or making hissing sounds.
- Replace any battery that has signs of damage to the terminals, case or cover.
- Do not overcharge or overdischarge battery.
Length
Width
Height
BCI Group #
Weight
Carrying
Find tech tips, manuals and support at gpelectric.com
GP-AGM-224-6V
AGM BATTERY
Quick Start Guide
10.24 in / 260 mm
7.09 in / 180 mm
9.72 in / 247 mm
27
67.25 lbs / 30.5 kg
Nylon Strap
