Go Power GP-LiFePO4-100 Quick Start Manual

Battery Speci cations
SPECIFICATIONS
Technology Lithium Iron Phosphate
Nominal Voltage 12.8 V
100 Ah @ 20A (5hr run time); 92 Ah @ 50A
Rated Capacity
(1hr 54 min run time; 92 Ah @ 100A (55 min
77°F (25 ±5 °C)
run time)
Capacity Correction for
-4 °F (-20°C) 60%
Temperature Variations 131°F (55°C) 95%
100A (continuous)
Maximum Discharge
120A (30 minutes)
Current
150A (5 seconds)
Speci c Energy Density
121.9 Wh/kg
Volumetric Energy Density 96.1 Wh/L
Internal Resistance ≤ 7.5 m
M8 insert
Terminals
Torque: 10.8 - 12.7 Nm (95.59 - 112.40 lbs)
≤1500 @ 100% Depth of Discharge; ≥3000
Cycle Life - 77°F (25°C)
@ 80%; ≥4500 @ 30%
Charge Voltage 14.6V
Maximum Charge Current 100A
UN 38.3; CE
Charge Cut-off Voltage 14.6V
Discharge Cut-off Voltage 8.4V
Charge: 32°F (0°C) to 131°F (55°C
Operating Temperature
Discharge: -4°F (-20°C) to 131°F (55°C)
1 Week: -4°F (-20°C) to 122°F (50°C)
Storage Temperature
1 month: -4°F (-20°C) to 113°F (45°C)
6 months
Operating: 5% to 90 % RH
Humidity
Storage: 45% to 85% RH
BMS Leakage Current 3mA
1 Max storage time before recharge is 6 month.
: -4°F (-20°C) to 104°F (40°C)
1
Only wire 4 batteries maximum in parallel
Do not wire in series
Do not get wet
Only suitable for 12-volt applications
Length 12.9 in / 328 mm
Width 7 in / 178 mm
Height 9.2 in / 233.7 mm
BCI Group # 31
Weight 36 lbs / 16.33 kg
Carrying Nylon Strap
Find tech tips, manuals and support at gpelectric.com
GP-LiFePO -100
4
Lithium Battery
Quick Start Guide
