2 TRANSPORT AND INSTALLATION

2.1 General Unit Check

Unit Has been placed
securely and on solid
ground
Electrical plug Is free of damages
Vacuum hose and Is free of damages
suction cup
Pressure Function check
Regulator
2.2 Technical Data
Unit Type C 200
Measurement 40 x 50 x 26 cm 40 x 50 x 26 cm
(l x w x h)
Weight 10 kg (22lbs) 10 kg (22lbs)
Energy 2 A
Voltage 230 Volt
Frequency 50 Hz
Rated Currency 2 A
Rated Capacity 460 W
4 | C-ITRONE 200/300
2.3 Transport / Storage
The unit should only be stored at a temper-ature
range from -25°C (-13°F) to +55°C (+131°F)
Damage to the unit can be caused by incor-rect
transport, set-up, or deconstruction.
Unit should always be set and secured on level,
solid ground. The unit must always be operated
in closed rooms, in a safe and controlled
environment.
C 300

2.4 Set-up/Start-up

2 A
230 Volt
50 Hz
2 A
Damage to the unit can be caused by in-correct
460 W transport, set-up, or deconstruc-tion.

2.5 Electrical Plug/ Electrical Fuses

The electrical fuses for this unit are locat-ed directly below
the 3-prong power plug on the unit casing. Be aware that
re-placement of worn out fuses may be nec-essary. In this
case, only use 2A replace-ment fuses, which can be found
at almost any local electrical parts store. One (1) 2A equals
one (1) fuse.

2.6 Suction Hose Attachment

The suction hose is attached to the unit through an easy
''click-system''. Simply push the front ring back, attach the
suction hose to the unit, and pull the front ring for-ward
again, insuring that the hose is sitting tight in the correct
position..
