sauder.com

BEFORE MAKING ANY RETURNS TO THE STORE.

BEFORE MAKING ANY RETURNS TO THE RETAILER.

sauder.com/service

Visit

Prefer the phone? Give us a ring at

Customer Service is available Monday-Friday - 9 a.m. to 5:30 p.m. EST (except holidays)

Lateral File

Englewood Collection | Model 426908

Sauder.com

Share your journey!

to order replacement parts, view video assembly tips, or chat with a live rep.

1-800-523-3987

Congratulations. You

are now an adult.

NOTE: THIS INSTRUCTION

BOOKLET CONTAINS IMPORTANT

SAFETY INFORMATION.

PLEASE READ AND KEEP FOR

FUTURE REFERENCE.

English pg 1-29

Français pg 30-34

Español pg 35-39

Lot # 543714

Purchased: __________________

06/18/20

Need help?

Do you have a question about the Englewood 426908 and is the answer not in the manual?

Questions and answers

Summary of Contents for Sauder Englewood 426908

Page 1 CONTACT US FIRST CONTACT US FIRST sauder.com sauder.com sauder.com BEFORE MAKING ANY RETURNS TO THE STORE. BEFORE MAKING ANY RETURNS TO THE RETAILER. sauder.com/service Visit to order replacement parts, view video assembly tips, or chat with a live rep. 1-800-523-3987 Prefer the phone? Give us a ring at Customer Service is available Monday-Friday - 9 a.m.
Page 2 Table of Contents Assembly Tools Required Part Identification No. 2 Phillips Screwdriver Tip Shown Actual Size Hardware Identification Assembly Steps 6-29 Hammer Français 30-34 Not actual size Español 35-39 Safety 40-42 Adjustable Wrench Warranty Page 2 426908 www.sauder.com/service...
Page 3 TOP (1) D985 DRAWER BOTTOM (2) BALLAST (1) BOTTOM (1) LARGE BASE (2) SMALL DRAWER FRONT (1) D550 RIGHT DRAWER SIDE (2) SMALL BASE (2) M67 DRAWER BRACE (2) D550 D552 D985 D551 D550 D552 D985 D551 www.sauder.com/service 426908 Page 3...
Page 4 31G CORNER BRACKET - 4 34G INTERLOCK MECHANISM - 1 ACTUATOR - 2 BRACKET - 2 76G L - LOCK BRACKET - 1 77G Z - LOCK BRACKET - 1 LOCK PACK - 1 189K PULL - 2 Page 4 426908 www.sauder.com/service...
Page 5 BROWN 7/16" LARGE HEAD SCREW - 4 BLACK 1-1/8" PAN HEAD SCREW - 4 BLACK 1/2" FLAT HEAD SCREW - 6 30S BLACK 1-9/16" FLAT HEAD SCREW - 10 BLACK 9/16" PAN HEAD SCREW - 3 www.sauder.com/service 426908 Page 5...
Page 6 Tighten Risk of damage or Arrow injury. HIDDEN CAMS must be completely Arrow Maximum tightened. HIDDEN 210 degrees CAMS that are not completely tightened may loosen, and parts may separate. To Minimum completely tighten: 190 degrees Page 6 426908 www.sauder.com/service...
Page 7 Some assembly å To begin assembly, push four SAUDER TWIST-LOCK® (and snacks) required. FASTENERS (36F) into the large holes in the ENDS (A and B). Do not tighten the TWIST-LOCK® FASTENERS in this step.
Page 8 NOTE: The EXTENSION SLIDES (35MC) will be used later for the DRAWERS. 35MC 35MA Push the black lever in and pull the SLIDE from the RAIL. Open end Open end GOLD 5/16" FLAT HEAD SCREW (8 used for the RAILS) Page 8 426908 www.sauder.com/service...
Page 9 Fasten the L - LOCK BRACKET (76G) to the RIGHT END (A). Use two BLACK 9/16" LARGE HEAD SCREWS (1S). BLACK 9/16" PAN HEAD SCREW (3 used in this step) BLACK 9/16" LARGE HEAD SCREW (2 used in this step) www.sauder.com/service 426908 Page 9...
Page 10 Step 4 å To begin assembly, push eight SAUDER TWIST-LOCK® FASTENERS (36F) into the large holes in the BACKS (G). Do not tighten the TWIST-LOCK® FASTENERS in this step. Page 10 426908 www.sauder.com/service...
Page 11 Step 5 å Fasten the RIGHT END (A) to the BACKS (G). Tighten four TWIST-LOCK® FASTENERS. Open end Unfinished edge Unfinished edge www.sauder.com/service 426908 Page 11...
Page 12 Push four HIDDEN CAMS (1F) into the BOTTOM (D). Then, insert the metal end of a CAM DOWEL (2F) into each HIDDEN CAM. Arrow Metal end Do not tighten the HIDDEN CAMS in this step. Arrow Metal end Page 12 426908 www.sauder.com/service...
Page 13 Step 7 å Fasten the BOTTOM (D) to the RIGHT END (A). Tighten two HIDDEN CAMS. D E N H I D i t h f a c S u r These edges must be even. www.sauder.com/service 426908 Page 13...
Page 14 Step 8 å Fasten the LEFT END (B) to the BOTTOM (D) and BACKS (G). Tighten two HIDDEN CAMS and tighten four TWIST-LOCK® FASTENERS. Open end Page 14 426908 www.sauder.com/service...
Page 15 Insert four WOOD DOWELS (15F) into the ENDS (A and B). å Fasten the TOP (C) to the ENDS (A and B). Tighten four TWIST-LOCK® FASTENERS. å NOTE: Be sure the WOOD DOWELS in the ENDS insert into the TOP. www.sauder.com/service 426908 Page 15...
Page 16 å Carefully turn your unit onto its top. å Fasten the CORNER BRACKETS (31G) to the BOTTOM (D). Use eight BLACK 9/16" LARGE HEAD SCREWS (1S). BLACK 9/16" LARGE HEAD SCREW (8 used in this step) Page 16 426908 www.sauder.com/service...
Page 17 BASES (E and F). Use six BLACK 9/16" LARGE HEAD SCREWS (1S). å NOTE: Be sure the BRACKETS are even with the edges of the BASES. BLACK 9/16" LARGE HEAD SCREW (6 used in this step) www.sauder.com/service 426908 Page 17...
Page 18 SMALL BASES. å Fasten the BOTTOM (D) to the METAL BRACKETS on the SMALL BASES (F). Use two BLACK 9/16" LARGE HEAD SCREWS (1S). BLACK 9/16" LARGE HEAD SCREW (10 used in this step) Page 18 426908 www.sauder.com/service...
Page 19 LARGE BASES. your drink. å Fasten the BOTTOM (D) to the METAL BRACKETS on the LARGE BASES (E). Use four BLACK 9/16" LARGE HEAD SCREWS (1S). BLACK 9/16" LARGE HEAD SCREW (12 used in this step) www.sauder.com/service 426908 Page 19...
Page 20 Step 14 å Fasten the BALLAST (J) to the BOTTOM (D). Use four BLACK 1-1/8" PAN HEAD SCREWS (9S). BLACK 1-1/8" PAN HEAD SCREW (4 used in this step) Page 20 426908 www.sauder.com/service...
Page 21 Step 15 å Fasten the Z - LOCK BRACKET (77G) to the SMALL DRAWER FRONT (K). Use two BLACK 9/16" LARGE HEAD SCREWS (1S). BLACK 9/16" LARGE HEAD SCREW (2 used in this step) www.sauder.com/service 426908 Page 21...
Page 22 CAM DOWEL (2F) into the HIDDEN CAM. Use five BLACK 1-9/16" FLAT HEAD SCREWS (30S). å Fasten the DRAWER BRACE (M67) to the SMALL å Repeat this step for the LARGE DRAWER FRONT (H). DRAWER FRONT (K). Tighten one HIDDEN CAM. Page 22 426908 www.sauder.com/service...
Page 23 Fasten the SMALL FILE BRACKET (11B) to the DRAWER BACK (D552). Use two BROWN 7/16" LARGE HEAD SCREWS (6S). å Repeat this step for the remaining drawer. BROWN 7/16" LARGE HEAD SCREW (4 used in this step) BLACK 9/16" LARGE HEAD SCREW (4 used in this step) D552 www.sauder.com/service 426908 Page 23...
Page 24 Screw head - turn CAM to line up holes in the SLIDES with holes in DRAWER SIDES D551 Open end D550 Drawer Slide GOLD 5/16" FLAT HEAD SCREW (4 used for the SLIDES) Center the screw in the oval hole. Page 24 426908 www.sauder.com/service...
Page 25 Fasten the PULLS (189K) to the DRAWER FRONTS (H and K). Use four BLACK 9/16" LARGE HEAD SCREWS (1S). BLACK 9/16" LARGE HEAD SCREW (4 used in this step) 189K D550 D550 BLACK 1/2" FLAT HEAD SCREW (6 used in this step) www.sauder.com/service 426908 Page 25...
Page 26 å Slide another FILE GLIDE (6B) onto the other ends of the FILE RODS (9B), then press this FILE GLIDE over the LEFT DRAWER SIDE (D551). å Repeat this step for the remaining drawer. D551 D550 Page 26 426908 www.sauder.com/service...
Page 27 å NOTE: Turn the KEY clockwise to lock. The prongs must press into the LARGE DRAWER FRONT as you tighten the NUT with an adjustable wrench. WASHER SCREW LOCK KEYS www.sauder.com/service 426908 Page 27...
Page 28 4. Push the drawer in until it is fully inserted. Pull the lower wing forward until it clicks into place. The Lower Drawer ACTUATOR must be here. Pull the upper wing forward until it clicks into place. l b s . Page 28 426908 www.sauder.com/service...
Page 29 å This completes assembly. Clean with a damp cloth. Wipe dry. And to celebrate, why not share your success story at sauder.com or Loosen screw #3 a 1/4 turn, turn the cam a 1/4 turn maximum in both the clockwise and counter-clockwise directions to make adjustments, and then tighten screw #3.
Page 30 REFERENCE DESCRIPTION QUANTITÉ REFERENCE DESCRIPTION QUANTITÉ conserver le livret pour future référence. Pour contacter Sauder en EXTRÉMITÉ DROITE ..........1 PETIT SUPPORT DE DOSSIER......2 ce qui concerne cet EXTRÉMITÉ GAUCHE ..........1 14B TRINGLE POUR DOSSIERS ........4 élément, faire référence DESSUS ................1 EXCENTRIQUE ESCAMOTABLE .....6...
Page 31 2. Bien serrer la FIXATION à l'aide d'un tournevis Phillips. Pour commencer l'assemblage, enfoncer huit FIXATIONS TWIST- UTILISATION DE LA EXCENTRIQUE ESCAMOTABLE ET DE LA LOCK® SAUDER (36F) dans les gros trous dans les ARRIÈRES (G). CHEVILLE D'EXCENTRIQUE 1. Enfoncer un EXCENTRIQUE ESCAMOTABLE dans la partie. La ÉTAPE 5...
Page 32 EXTRÉMITÉS dans le DESSUS. EN CORNIÈRE situés sur le DESSOUS, et dans les trous des PETITS SOCLES. Fixer le DESSOUS (D) aux CONSOLES EN MÉTAL sur les PETITS SOCLES (F). Utiliser deux VIS TÊTE LARGE 14 mm NOIRES (1S). Page 32 426908 www.sauder.com/service...
Page 33 DORÉES (3S) à travers les trous nº 1 et nº 3. REMARQUE : La tête de vis dans l'EXCENTRIQUE doit être visible à travers le trou fendu dans la COULISSE. Répéter cette étape pour l'autre tiroir. www.sauder.com/service 426908 Page 33...
Page 34 Resserrer les VIS après d'avoir ajusté. montre pour verrouiller. REMARQUE : Prière de lire les informations importantes sur la sécurité figurant sur les pages arrière du manuel d’instructions. Ceci complète l'assemblage. Nettoyer avec un tissu humide. Essuyer. Page 34 426908 www.sauder.com/service...
Page 35 EXTREMO DERECHO ..........1 EXCÉNTRICO ESCONDIDO .......6 su referencia futura. Si necesita ponerse en EXTREMO IZQUIERDO ..........1 PASADOR DE EXCÉNTRICO ......6 contacto con Sauder en PANEL SUPERIOR ............1 15F PASADOR DE MADERA .........4 cuanto a esta unidad, FONDO .................1 36F SUJETADOR TWIST-LOCK®......12 refiérase al número...
Page 36 Phillips (cruz). Para comenzar el ensamblaje, empuje ocho SUJETADORES CÓMO UTILIZAR EL EXCÉNTRICO ESCONDIDO Y TWIST-LOCK® SAUDER (36F) dentro de los agujeros grandes de EL PASADOR DE EXCÉNTRICO los DORSOS (G). 1. Empuje un EXCÉNTRICO ESCONDIDO dentro de la parte. La flecha en el EXCÉNTRICO ESCONDIDO debe apuntar hacia el...
Page 37 MÉNSULAS DE ESQUINA situadas al FONDO y en los agujeros de las BASES PEQUEÑAS. Fije el FONDO (D) a los SOPORTES DE METAL sujetados a las BASES PEQUEÑAS (F). Utilice dos TORNILLOS NEGROS DE CABEZA GRANDE de 14 mm (1S). www.sauder.com/service 426908 Page 37...
Page 38 CABEZA PERDIDA de 8 mm (3S) a través de los agujeros No. 1 y No. 3. NOTA: La cabeza de tornillo del EXCÉNTRICO debe ser visible a través del agujero alargado de la CORREDERA. Repita este paso para el otro cajón. Page 38 426908 www.sauder.com/service...
Page 39 Esto completa el ensamblaje. Limpiar con un trapo húmedo. que la LEVA esté apuntando hacia la dirección correspondiente tal Seque con un paño. como se indica. NOTA: Gire la LLAVE en dirección de las manecillas del reloj. www.sauder.com/service 426908 Page 39...
Page 40 • This product is not designed to support a designed to support a television is heavy. Plus the weight and location of the television. hazardous. picture tube tends to make TVs unbalanced and prone to tipping forward. Page 40 426908 www.sauder.com/service...
Page 41 Les téléviseurs peuvent être très un téléviseur. téléviseur. lourds. De plus, le poids et l’emplacement du tube image ont tendance à rendre les téléviseurs instables et enclins à tomber vers l’ a vant. www.sauder.com/service 426908 Page 41...
Page 42 Además, soportar un televisor. diseñadas para soportar un televisor. el peso y la ubicación del tubo de imagen tienden a causar la inestabilidad de televisores y son propensos a inclinarse hacia adelante. Page 42 426908 www.sauder.com/service...
Page 43 à compter de la date d'achat la première fois et qui sont signalés à Sauder dans les limites de couverture de la contre tout défaut de matériaux ou de fabrication des composantes de mobilier Sauder.
Page 44 BEFORE MAKING ANY RETURNS TO THE RETAILER. So, how did it go? Dear Valued Customer: Thanks so much for choosing Sauder® furniture. I hope the Set a world record for speed? purchase and assembly process was a positive experience Feeling good about yourself? and you feel good about the furniture you just built.
