GR Painting Robot Series
Electrical Operation and Maintenance Manual
Version No.：ZL-GR6150-003-V1
Issue Date: January, 2020
The copyright is reserved for CMA (WUHU) Robotics Company Limited
For customer use only and any unauthorized use of this manual is strictly prohibited
CMA (WUHU) Robotics Company Limited
No.96, East Wanchun Road, Jiujiang Economic Development District, Wuhu, Anhui Province
TEL：400-052-8877
CMA
CMA (WUHU) Robotics Company Limited
Supplier of Intelligent Painting Robots
