Key Digital Digital Blaster KD-SDI1080P Specification Sheet

KD-SDI1080P
KD-SDI1080P is a Digital Video Processor with capability of scaling and deinterlacing
1 SDI (HD/SD) source/input. It outputs to RGBHV or DVID/HDMI/HDCP cable with
a resolution up to 1080p
General:
SDI 270 Mb/s (SD) or 1.49 Gb/s (HD)
›
Built-in SDI HD/SD input cable equalizer, accepts the 500-
›
foot cable runs (SDTV) or 200-foot cable runs (HDTV)
DVI-D (HDCP) output, compatible with HDMI (HDCP) video
›
using Key Digital HDMI / DVI-D adapter cables
™
Select VGA (RGBHV) or Component Video output
›
Inputs
SDI 270 Mb/s (SD) or 1.49 Gb/s (HD)
›
Supports the following input resolutions: 720x480i,
›
1280x720p, 1920x1080i, or 1920x1080p/24 Hz
BNC female input connector
›
Built-in SDI HD/SD input cable equalizer, accepts the
›
following cable runs:
up to 200 feet for HD
›
up to 500 feet for SD inputs
›
for long cable runs you must be sure to use good quality
›
BNC-BNC cable, 75 Ohms
Scaling and Processing
Scaling SDTV and HDTV to popular native resolutions
›
Scaler equipped with advanced, motion-assisted de-
›
interlacing algorithm Clear Matrix Pro
Aspect Ratios in and out: 16:9 and 4:3
›
Vertical and Horizontal Letterbox Zoom feature, to prevent
›
monitor burn-in for Letterbox or Pillar-box images
Key Digital
521 East 3rd Street, Mount Vernon, NY 10553
:: ::
Phone 914.667.9700 Fax 914.668.8666
::
Web www.keydigital.com
Outputs
DVI (DVI-D connector)
›
RGBHV (D sub connector)
›
Supports the following output resolutions at 60 Hz refresh
›
rates: 720x480p, 800x600p, 1280x720p, 1024x768p,
1280x768p, 1280x1024p, 1920x1080i, 1920x1080p, or
1920x1200p
HDCP On/Off, switch-selectable
›
Control
All controls are available via the front-panel pushbuttons and
›
LCD, as well as RS232
Selectable output resolution
›
HDCP On/Off switch
›
SDI Equalizer
›
Aspect Ratio select
›
Vertical or horizontal Zoom select
›
Horizontal Position and Size control
›
Vertical Position and Size control
›
Horizontal and Vertical input offset control
›
Two-dimensional Edge Enhancement
›
Select RGB or YPbPr output mode
›
Exclusive Technologies
®
Specification Sheet
Digital Blaster
Mechanical
No fan noise
›
Size: 8.5" x 4" x 1.75"
›
Weight: 2 lbs.
›
Power
External power supply provided
›
110-240V AC
›
50-60 Hz
›
0.9 A
›
Supported Technologies
™
