Key Digital Digital Blaster KD-SDI1080P Specifications

Video/Audio Processors
KD-SDI1080P
KD-SDI100P is a Digital Video Processor with capability of scaling and deinterlacing
1 SDI (HD/SD) source/input. It outputs to RGBHV or DVID/HDMI/HDCP cable with
a resolution up to 100p
Key Benefits
4
Up-converts or down-converts any resolutions of
HD (1080i) or SD (480i) SDI Video inputs to single
DVID/HDMI/HDCP or to a single RGBHV output
4
Horizontal and Vertical Position and Size control with
Horizontal and Vertical letter-box zoom or pillar-box images
4
SDI 270 Mb/s (SD) or 1.49 Gb/s (HD)
Key Solutions
Converts SDI (digital) to RGBHV (analog) or DVI/HDMI/HDCP
›
Can be used with long SDI cable runs (up to 300 ft.), in the digital domain,
›
without any degradation
Converts HD SDI and SD SDI to DVI/HDMI/HDCP or RGBHV
›
Provides one cable solution to the display
›
Maximizes picture quality
›
Supports 3rd party control systems via RS232 and IR
›
16
Digital Blaster
4
Individual customization for any video input for all key video
parameters: Aspect Ratio, Brightness, Contrast, Hue, Edge
Enhancement, Image position
4
Incorporates 9 Key Digital ™ Exclusive Technologies
4
RS 232, Front Panel Controls with LCD, Discrete Codes
General Info
Power: 100VAC to 240VAC,
›
50Hz and 60Hz, NTSC, PAL
Rack Mount: No
›
Remote Control: Included
›
Enclosure Type: Metal
›
Dimensions:
›
8.5" x 5" x 1.75"
Shipping Carton Dimensions:
›
14" x 8" x 4"
Product Weight: 4 lbs
›
Shipping Weight: 7 lbs
›
™
Hospital Operating Room Application
Model: KD-SDI100P
g
a l o
A n
1
n e
Z o
Digital
Imaging
Station OR
Endoscope
Key Digital Exclusive Technologies
®
D i g
i t a
Z o
l
n e
1
Display
Plasma
KD-SDI1080P
RS232 Control
*To connect HDMI Video use
HDMI < > DVI adapter cables
Supported Technologies
1 7
