- Page 1 Owner’s Manual & Safety Instructions Save This Manual Keep this manual for the safety warnings and precautions, assembly, operating, inspection, maintenance and cleaning procedures. Write the product’s serial number in the back of the manual near the assembly diagram (or month and year of purchase if product has no number). Keep this manual and the receipt in a safe and dry place for future reference.
- Page 2 WARNING SYMBOLS AND DEFINITIONS This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death. Indicates a hazardous situation which, if not avoided, will result in death or serious injury.
- Page 3 Operating Instructions Read the ENTIRE IMPORTANT SAFETY INFORMATION section at the beginning of this document including all text under subheadings therein before set up or use of this product. Note: This add-on kit is used with MA10-1 Note: Read vehicle service manual to determine how Ball Joint Service Kit (63610 sold separately).
- Page 4 Removing/Installing Ball Joint Note: The following instructions are intended to illustrate the process in general terms, and NOT to be specific to any one make/model vehicle. A combination of Receiving Tubes (parts 1-6, 8),Receiving Cup (9), and Installers (7, 10) will be necessary for different vehicles. 1.
- Page 5 Application Chart Adapter Application Chart Description Image Dimensions GM Receiving Tube 1 (1) 2-3/4" x 3" x 2-1/4" GM Receiving Tube 2 (2) 2-7/16" x 2-3/4" x 2-1/4" Ford Receiving Tube 1 (3) 2-1/4" x 2-1/2" x 2-3/4" Ford Receiving Tube 2 (4) 2-5/8"...
- Page 6 Cleaning, Maintenance, and Lubrication Do not perform any inspection, maintenance or cleaning procedures when the Ball Joint Kit is under a load. 1. BEFORE EACH USE, inspect the general condition 2. PERIODICALLY, use a premium quality of the Ball Joint Kit. Check for misalignment or and light weight machine oil to lubricate binding of moving parts, cracked or broken parts, the threads of the Jackscrew.
- Page 7 Parts List & Diagram Part Description Part Description GM Receiving Tube 1 Dodge/Chrylser/Jeep Installing Tube GM Receiving Tube 2 Ford Receiving Tube Ford Receiving Tube 1 Dodge/Chrylser/Jeep Receiving Cup Ford Receiving Tube 2 Dodge/Chrylser/Jeep Remover/Installer Dodge/Chrylser/Jeep Receiving Tube Dodge/Chrylser/Jeep/Ford Plug Bolt Dodge/Chrylser/Ford Receiving Tube Carry Case Item 58785...
- Page 8 Limited 90 Day Warranty Harbor Freight Tools Co. makes every effort to assure that its products meet high quality and durability standards, and warrants to the original purchaser that this product is free from defects in materials and workmanship for the period of 90 days from the date of purchase. This warranty does not apply to damage due directly or indirectly, to misuse, abuse, negligence or accidents, repairs or alterations outside our facilities, criminal activity, improper installation, normal wear and tear, or to lack of maintenance.
