- Page 1 STM Series 15.6” Wide LCD Touchscreen Monitor Model “G” Model “H” Instruction Manual Model: TMG-156FH01-01 TMH-156FH01-01 Seedsware Corporation http: //www.seedsware.co.jp/global STM Series Instruction Manual 23A4A4-00006E-1...
- Page 2 Please note, specifications described in this manual are subject to change without prior notice. Copyrights and Trademarks ■ The copyright of this instruction manual is rightfully owned by Seedsware Corporation. ■ Reproduction and/or duplication of the product and/or this manual, in any form is strictly prohibited.
- Page 3 Before installing the power cable, make sure power is not being supplied from the power source. Failure to do so may cause electrical shocks. Do not use power voltage other than what is specified. Failure to do so may cause fires and/or electric shocks. STM Series Instruction Manual...
- Page 4 5) When displaying a same image for a long period of time, it may cause afterimages. Please note that this is a basic characteristic of the LCD and not a malfunction. In order to avoid afterimages, change the display image periodically and avoid displaying the same image for a long period of time. STM Series Instruction Manual...
- Page 5 5) Due to the structure of the touchscreen, sealing material may be visible at the edge (upper right corner when viewed from the front) of the touchscreen. Please refer to the Shipping Standards for details. (Please contact our sales representatives.) STM Series Instruction Manual...
-
Page 6: Table Of Contents
Setting ............................22 Calibration ............................27 Maintenance ......................30 Maintenance ..........................31 Troubleshooting ..................... 32 Display ............................33 About the Touchscreen ........................34 Others ........................35 Warranty and Repair ........................36 Production Discontinuance ......................37 Inquiries ............................38 STM Series Instruction Manual... -
Page 7: Features
Features Features Chapter Contents Features ....................2 Line-Up ...................... 3 STM Series Instruction Manual... -
Page 8: Features
■ Mounting angle of the VESA Box can be changed (variable angle: 90degress) / Improved routing flexibility of the interface cable. ■ Adoption of VESA mounting standard (100 x 100mm). ■ Can stand alone with the optional self-standing stand. ■ “Anti-virus + Antibacterial film” is also available as option. STM Series Instruction Manual... -
Page 9: Line-Up
※ The analog resistive type touchscreen used in the STM enable light touch operations compared to the analog resistive type in our other products. It also supports gestures such as flick, pinch in/out, and rotate. (Two-point touch operation is not available) STM Series Instruction Manual... -
Page 10: Product Configuration
Product Configuration Product Configuration Chapter Contents Names and Functions of Each Parts ............5 Options ...................... 6 Installing the STM ..................8 Wiring ...................... 10 STM Series Instruction Manual... -
Page 11: Names And Functions Of Each Parts
Name Function ① USB Interface USB3.0 Standard Type-B Connector Power Input Input power. (12VDC±10%) ② Image Input (Digital) HDMI connector ③ ④ FG Terminal Connects to Field GND. ⑤ VESA Box Can be rotated by customer STM Series Instruction Manual... -
Page 12: Options
Note: Warranty coverage: The AC adaptor is covered by the AC adaptor manufacturer’s warranty. Please prepare an AC power cord that conforms to the standards specified for the country or region in which it will be used. STM Series Instruction Manual... - Page 13 ・VESA mounting screw 4pcs ・List of items included 1copy 2.2.3.2. Assembly Instruction 1) Remove the screw attached to the arm. 2) Put together the arm and the base. 3) Screw together with the screw removed at 1). Complete STM Series Instruction Manual...
-
Page 14: Installing The Stm
Tightening torque is 0.7 to 0.8N-m. Angle adjustment range is +90° to -5°. If installed to our option stand “SWST-01-001”, the angle can be adjusted for easy viewing. Installation Stand adjustment range Diagram of when installed to SWST-01-001 STM Series Instruction Manual... - Page 15 VESA established SVGA standards and VL bus standards and standardized below 2 types of LCD monitor installing dimensions as below. ●75mm×75mm pitch ●100mm×100mm pitch Our STM complies with the VESA standard 100mm×100mm. STM Series Instruction Manual...
-
Page 16: Wiring
If ground wire becomes long, use a thick insulation wire when setting. (4) The STM will be FG grounded if the VESA arm is grounded to FG because the VESA arm surface is conductive. STM Series Instruction Manual... - Page 17 Calibration” and perform calibration. (7) Resetting of the touch coordinate (rotation) of the touchscreen is not necessary. However, if the touch coordinates are rotated, please refer to “4.3.4 Touch Coordinate Rotation” and rotate the touch coordinates. STM Series Instruction Manual...
- Page 18 [Caution] Please be careful not to drop the screw to avoid it from getting inside the main unit or getting lost. Gently lift the VESA box about 1 to 2 cm. Unit side Box side Position mark Position mark [Caution] Lifting up the VESA box too high may cause disconnection or damage. STM Series Instruction Manual...
- Page 19 [Caution] To return the interface of the VESA box from landscape direction to the shipping state (downward), be sure to rotate counterclockwise direction the VESA box 90 degrees. Rotating more the 90degrees may cause disconnection or damage to the wires. STM Series Instruction Manual...
-
Page 20: Osd
OSD (On Screen Display) is the default setting at shipment. OSD changes cannot be made by the customer. Chapter Contents OSD Menu (Factory Default Setting) ............15 STM Series Instruction Manual... -
Page 21: Osd Menu (Factory Default Setting)
Gamma value adjustment 5800K 6500K 7500K Color temperature adjustment Color Temp 6500K 9300K sRGB User R/G/B Each adjustment range: 0～255 Standard Dynamic Movie Color effect adjustment Color Effect Standard Photo Vivid User R/Y/G/C/B/M Each adjustment range:0～100 STM Series Instruction Manual... -
Page 22: Touchscreen Setting Tool
Installation ....................18 Setting ..................... 22 Calibration ....................27 * “Touchscreen Setting Tool (DMT-DD)” V2.14 or later version is recommended. * For detailed instruction of “Touchscreen Setting Tool (DMT-DD)”, please refer to the document included in the “DMT-DD”. STM Series Instruction Manual... -
Page 23: System Requirements
Signature Algorithm The OS must support SHA-2 signature algorithm. 4.1.3 Remarks - “Touch support (restrictions may apply)” may be displayed in the system property. - For use with other OS other than those supported, please contact us. STM Series Instruction Manual... -
Page 24: Installation
*Do not connect STM to a computer via USB before installation. (2) Double-click "DMT-DDSetup.msi" or "DMT-DDSetup_ms.msi" inside the folder. (3) The setup wizard will start. Click [Next] to begin the installation. (4) Review the license terms and select "I agree," and click [Next]. STM Series Instruction Manual... - Page 25 Touchscreen Setting Tool (5) Click [Next] at “Confirm installation”. (6) The following dialog may appear multiple times during installation. Click [Install] (7) Click [Close] to complete the installation. STM Series Instruction Manual...
- Page 26 The following dialog may appear depending on your UAC (User Account Control). Click [YES] to start. (3) When startup is complete, [Add Device] will appear. Select [USB Port] from [Touchscreen Device] and click [Install]. (4) Installation confirmation window will be shown. Click [Yes] STM Series Instruction Manual...
- Page 27 (6) The following window will appear after a while. Click [OK] and reboot your computer. (7) Start the “DMT-DD” after rebooting the computer. If the “USB Port” is changed to “TP Driver”, the driver installation is complete. STM Series Instruction Manual...
-
Page 28: Setting
(4) The following screen will be displayed from the monitor on the leftmost (5) Press [Enter] until the above screen appears on the monitor with touchscreen. (6) When the above screen appears on the touchscreen monitor, touch the touchscreen on the monitor twice. STM Series Instruction Manual... - Page 29 (8) Enter [Enter] on the last monitor and the setup is complete. If you wish to cancel during the process, press the “ESC” key. (9) The monitor associated with the selected driver will become active and the driver ID is displayed. STM Series Instruction Manual...
- Page 30 (5) When the message is displayed on the monitor to be equipped with the touch panel, tap the screen as instructed. (6) If there are multiple monitors to equip with the touch panel, perform the above process (5) to all the touchscreen monitors. STM Series Instruction Manual...
- Page 31 The Setup file is not registered by default. It is set as “touch output” when unregistered. When using single-touch, change to “Mouse output” by the following procedure. (1) Start [Touchscreen Setting Tool] (2) Open [Setting File] via [Basic Settings] Select [Mouse.mfd] and click [Register] STM Series Instruction Manual...
- Page 32 (1) Start [Touchscreen Setting Tool] (2) Open [Setting File] via [Basic Settings] (3) Select [Touch.mfd] and click [Register] 4.3.6 Rotating Touch Coordinates The XY coordinates output by touch operation can be rotated 0, 90, 180 and 270 degrees. STM Series Instruction Manual...
-
Page 33: Calibration
(3) Hardware calibration is complete when [Dev.0] [DONE] [0x00] turns green. Maintenance Tool Screen (Example) *[Setup Tool] cannot be operated while the [Maintenance Tool] is running. *Please do not touch the touchscreen when calibration is being performed. *This tool will automatically terminate. STM Series Instruction Manual... - Page 34 (5) Touch the center of the marker displayed on the screen. Another marker will be displayed one after another. Do the same for all. (6) After all markers have been touched, adjustment is complete and the following screen will be displayed. (7) Click [OK] and finish the adjustment. STM Series Instruction Manual...
- Page 35 When gesture operation is not responding smoothly, it may improve with [Gesture Correction]. [Gesture Correction] is performed at factory shipment and does not need to be performed. If [Gesture Correction] is performed, touch operation may not operate normally. STM Series Instruction Manual...
-
Page 36: Maintenance
Maintenance Maintenance Chapter Contents Maintenance .................... 31 STM Series Instruction Manual... -
Page 37: Maintenance
(3) Operating pressure is within specified range (800～1114hpa). □Electrical Specification Check (1) Voltage is within the permissible range (DC12V±10%) □Installation Condition Check (1) Connectors of the cables are fully and securely inserted. (2) VESA mounting fixtures are securely installed and are not loose. STM Series Instruction Manual... -
Page 38: Troubleshooting
Troubleshooting Troubleshooting If symptoms persist even after taking corrective actions, consult your distributor or contact us (refer to ”7.3 Inquires“). Chapter Contents Display Display ..................33 About the Touchscreen ................34 STM Series Instruction Manual... -
Page 39: Display
・Red, green, blue, and/or white ・This is a characteristic of the LCD panel and not a malfunction. dots remain on the display。 ・A defective dot (does not light up) is on the display. STM Series Instruction Manual... -
Page 40: About The Touchscreen
・Make sure the touchscreen driver is properly installed. ・No touch sound. ・Touch sound may not be output depending on the computers configuration. ・Please choose whether to make touch sounds or not by using the touchscreen driver. STM Series Instruction Manual... -
Page 41: Others
Others Others Chapter Contents Warranty and Repair ................36 Production Discontinuance ..............37 Inquiries ....................38 STM Series Instruction Manual... -
Page 42: Warranty And Repair
(2) Repairs will be done only to product sent back and in our workshop. All shipping fees will be charged. (3) Ownership of the exchanged parts at repair shall belong to Seedsware. (4) Please note that failure analysis cannot be performed for LCDs and touchscreens due to the structures of the products. -
Page 43: Production Discontinuance
Others Production Discontinuance In the event of production discontinuance, an announcement will be made on our website six months prior to the last possible order reception date. STM Series Instruction Manual... -
Page 44: Inquiries
Business hours: 9:00a.m. to 5:45p.m. (Central Time) http://uscoamerica.com/ This document is protected by copyright law. Photocopying, duplicating, reproducing, and modifying of this product or document in part or by whole is prohibited. Copyright (C) 2021 Seedsware Corporation. All Rights Reserved STM Series Instruction Manual...
