Page 1: Instruction Manual
InfoSOSA™ Series Touchscreen Display Model “7” Instruction Manual Seedsware Corporation http://www.seedsware.co.jp/global/ - 1 - 14A4A4-00090E-3... - Page 2 Table of Contents Table of Contents ............................2 Introduction............................4 Notes ..............................4 Precautions for Safe Use ........................4 3-1 Warnings ................................5 3-2 Cautions ................................6 3-3 Handling of LCD Panels ............................ 7 3-4 Handling of Batteries ............................7 3-5 Handling of Image Files.............................
- Page 3 10-2 Regular Inspections ............................35 11. Warranty and Repairs ......................... 36 11-1 Repairs ................................. 36 11-2 Warranty ............................... 36 11-3 Production Discontinuance ..........................36 11-4 Repair Warranty ............................36 12. Others ..............................37 Appendix Outline Diagrams - 3 - 14A4A4-00090E-3...
-
Page 4: Introduction
■ Seedsware shall not be held liable in any way for damages or losses, nor be held responsible for any claims by a third party as a result of using this product. -
Page 5: Warnings
3-1 Warnings WARNING Warnings for Design Designing switches that might cause human injuries and/or property damage on the touch screen is strictly prohibited. Unintentional output signals due to malfunction of the main body, units, and/or cables, etc. can cause serious injuries. Design the system so that switches with major functions are equipped on other devices. -
Page 6: Cautions
Warnings for Wiring For wiring and installation, please refer to the manual and specifications in order to conduct it correctly. It may cause fires and/or electric shocks. Before installing the power cable, make sure power is not being supplied from power source. It may cause electrical shock. -
Page 7: Handling Of Lcd Panels
3-3 Handling of LCD Panels (1) The LCD display contains skin-irritating materials. If liquid materials flow out due to damage and comes in contact with skin, wash the area under running water for at least 15 minutes. If it gets into the eyes, wash under running water and consult a doctor. (2) The LCD display might have uneven brightness according to the contents being displayed. -
Page 8: Model "7" Products
4. Model “7” Products 4-1 General Specification Model Specification Distinction* 3.5” IS701-3SSN2-001 QVGA(320 x 240) 4,096colors Open Frame 1 language 4.3” IS711-4SSN3-001 WQVGA(480 x 272) 4,096 colors Open Frame 1 language 5.7” IS701-5SSN1-001 QVGA(320 x 240) 65,536 colors Open Frame 1 language 5.7”... -
Page 9: Packaged Contents
5. Packaged Contents Below items are included in the package. Please make sure there no missing items before use. Although all efforts have been made to assure the quality and packaging before shipment, if you notice any damages or missing items, please notify us before use. 5-1 Standard Specification ■... -
Page 10: Introduction Sample Kit
5-2 Introduction Sample Kit ■ 3.5” Open Frame Main Unit 1pc Accessory List 1pc Communication Cable for SIO1 （ISCBL-S02-001）1pc Power Cable（ISCBL-S01-001） 1pc AC Adapter 1pc Power Cable (for AC Adapter) 1pc CD (Below files are include in the CD) 2pcs Product Specification Instruction Manual InfoSOSA Installation Guide... - Page 11 ■ 4.3” Open Frame Main Unit 1pc Accessory List 1pc Communication Cable for SIO 1（ISCBL-S02-001）1pc Power Cable（ISCBL-S01-001） 1pc AC Adapter 1pc Power Cable (for AC Adapter) 1pc CD (Below files are include in the CD) 2 pcs Product Specification Instruction Manual InfoSOSA Installation Guide InfoSOSA Builder Installer InfoSOSA Builder Operation Manual...
- Page 12 ■ 5.7” Open Frame Main Unit 1pc Accessory List 1pc Communication Cable for SIO 1 (ISCBL-S02-001） 1 pc Power Cable（ISCBL-S01-001） 1 pc AC Adapter 1pc Power Cable (for AC Adapter) 1 pc Battery Board (IS-BT-01) 1pc Battery (CR2032) ＋ Battery Cable (ISCBL-S04-001) 1 pc CD (Below files are include in the CD) 2pcs Product Specification...
-
Page 13: Part Names And Their Functions
6. Part Names and Their Functions 6-1 Main Unit ■ 3.5” Open Frame ■Front Side Frame -Use when mounting to Display/ Touch Screen devices. Display screen images, input by -Connected to GND (Signal touchscreen. GND) inside the unit. ■Back Side Adjustment connector (Internal use) Serial No. - Page 14 ■ 4.3” Open Frame ■Front Side Angle -Use when mounting to devices. -Tighten screws on sides to install and adjust height -Connected to GND (Signal Display/ Touch Screen GND) inside the unit. Display screen images, input by touchscreen. ■Back Side DIP SW Set at shipment.
- Page 15 ■ 5.7” QVGA Open Frame ■Front Side Angle -Use when mounting to devices. -Tighten screws on sides to install and adjust height Display/ Touch Screen -Connected to GND (Signal GND) Display screen images, input by inside the unit. touchscreen. ■Back side Adjustment connector (Internal use) -Internal use only.
- Page 16 ■ 5.7” VGA Open Frame ■Front Side Angle -Use when mounting to devices. Display/ Touch Screen -Tighten screws on sides to install -Display screen images, input by and adjust height touchscreen. -Connected to GND (Signal GND) -Touchscreen for touchscreen inside the unit. compliant models only.
-
Page 17: Battery Board (Is-Bt-01)
6-2 Battery Board (IS-BT-01) ■ 5.7” *1pc included in the Introduction Sample Kit. Battery Holder Interface for connecting to unit Insert batteries Connects to unit 6-3 Power Cable (ISCBL-S01-001) ■ 3.5” / 4.3” / 5.7” *1pc included in the Introduction Sample Kit. 1Pin (Red) Housing Connects to 5VDC... -
Page 18: Communication Cable For Sio1 (Iscbl-S02-001)
6-5 Communication Cable for SIO1 (ISCBL-S02-001) ■ 3.5” / 4.3” / 5.7” *1pc included in the Introduction Sample Kit. Housing Dsub Connects to RS232 port of Connects to main unit serial port the host (PC) 6-6 Battery Cable (ISCBL-S04-001) ■ 5.7” *1pc included in the Introduction Sample Kit. -
Page 19: Installation And Wiring
7. Installation and Wiring 7-1 Installation ■ 3.5” / 4.3” / 5.7” • Make sure that power is not applied when installing and/or wiring. • Refer to the panel opening example and the attached outline diagrams when designing the chassis. •... - Page 20 ■ 4.3” Open Frame Below is the panel opening dimension example for when applying sheets and etc. to the surface by opening the entire touch screen surface. Design the chassis accordingly to the actual installing method. *Diagram from the front side of panel (panel thickness: 1.6mm or less). 4-M3×10 Stud bolts (Convex backside) Burrs prohibited on welded surface Center of Display...
- Page 21 ■ 5.7” QVGA Open Frame Below is the panel opening dimension example for when applying sheets and etc. to the surface by opening the entire touch screen surface. Design the chassis accordingly to the actual installing method. *Diagram from the front side of panel (panel thickness: 1.6mm or less). 4-M3×10 Stud bolts (Convex backside) Burrs prohibited on welded surface Center of Display...
- Page 22 ■ 5.7” VGA Open Frame Below is the panel opening dimension example for when applying sheets and etc. to the surface by opening the entire touch screen surface. Design the chassis accordingly to the actual installing method. *Diagram from the front side of panel (panel thickness: 1.2mm or less). 4-M3×10 Stud bolts (Convex backside) Burrs prohibited on welded surface Center of Display...
-
Page 23: Open Frametype Panel Mounting Procedures
2) Open FrameType Panel Mounting Procedures ■ 4.3” Open Frame / 5.7” Open Frame ① Align the hole of the unit angle with the stud bolts of the panel in 4 locations and tighten the nuts. *Angles are options for 3.5” products. Nuts Stud Bolts ②... -
Page 24: Open Frametype Angle Installation Diagram
■If only the display area (touchscreen key area) is opened: Adjust so that there is a 0.5mm gap between the inside of the panel and the upper electrode of the touch screen. Refer to “6-6 Precautions for Bezel Installation”. 3) Open FrameType Angle Installation Diagram Angles can be installed according to the application. - Page 25 ■ 5.7” VGA Open Frame (1) Pattern 1 Front side (2) Pattern 2 (without Angles) Front side - 25 - 14A4A4-00090E-3...
-
Page 26: Wiring Procedure
7-3 Wiring Procedure Please follow the Instructions of each number when wiring. Apply power after all wirings are done; do not attempt to do the wiring with the power on. All wirings do not need to be connected; connect only the ones necessary for the application to be used. - Page 27 ■ 5.7” QVGA Open Frame To 5V DC Power (1) Power Cable (4) Battery Connecting Cable To Host To Battery Board SIO1 (2) RS232 Communication Cable SIO2 Design Sheet Key Tail Design Sheet Key Tail (For switch) (For LED) ■ 5.7” VGA Open Frame To 5V DC Power (1) Power Cable...
-
Page 28: Connecting Unit To Power
1) Connecting Unit to Power ■ 3.5” / 4.3” / 5.7” ■Connecting to 5V DC Power Use a Power Cable to connect to 5V DC. Power Cable Unit 5V DC Power 《Power Specification》 ■5VDC±5% 《Power Cable Specification》 Power Cable (ISCBL-S01-001), included as accessory, can be used for the Introduction Sample Kit. ■Compatible connector housing: PAP-02V-S (Japan Solderless Terminal) Contact pin: SPHD-001T-P0.5、SPHD-002T-P0.5 ■Pin Assignment... -
Page 29: Connecting To Communication Cable
2) Connecting to Communication Cable ■ 3.5” / 4.3” / 5.7” Connect to RS232 port of the host (Single board computer, computer, etc.). Connect to a PC if downloading. * Communication cable for SIO 1 included as accessory can be used for the Introduction Sample Kit. For use other than the KIT, please purchase a different communication cable. - Page 30 《SIO2 Specification》 ■ 3.5” / 4.3” / 5.7” VGA ■Compatible connector housing: PHR-3(Japan Solderless Terminal) Contact pin: SPH-002T-P0.5S ■Pin Assignment Pin No Signal Direction InfoSOSA → Host (RXD) InfoSOSA ← Host (TXD) *5.7” QVGA will have a different spec then above. ■...
-
Page 31: Connecting Design Sheet Key Tail
3) Connecting Design Sheet Key Tail ■ 4.3” Open Frame / 5.7” Open Frame Connect the Design sheet key tail to the connector by below procedure. (1) Open the holding lid by sliding to the direction as below by hand. (Side view) (2) Hold the tail so the conductive side of the tail is placed downwards and the reinforcement plates are upwards. -
Page 32: Connecting With Battery Board
4) Connecting with Battery Board ■ 5.7” Open Frame Connect if battery backup of RTC is necessary. *It can also be used without batteries 《Connecting Procedure》 (1) Connect the unit and the battery board by battery cable. (2) Place the coin type battery with the positive side facing up into the battery board. *Battery with cable can be directly connected also. -
Page 33: Mounting Conditions
7-4 Mounting Conditions ■ 3.5” / 4.3” / 5.7” • When mounting, be sure to have enough room between the unit, structure and part and also consider the operation temperature. • Be sure that the ambient operating temperature and the ambient humidity are within their designated ranges. -
Page 34: Starting The Infososa
8. Starting the InfoSOSA ■ 3.5” / 4.3” / 5.7” Make sure all the wirings are complete and turn ON the 5V DC power. A starting beep will sound. Download the screen data to the unit. For downloading instructions, please refer to the “Download” chapter of the “InfoSOSA Builder Operation Manual”. 9. -
Page 35: Display Maintenance
10. Maintenance 10-1 Display Maintenance ■ 3.5” / 4.3” / 5.7” If the surface of the display or the frame becomes dirty, wipe clean with a soft cloth dampened with thinned neutral detergent and wrung dry. Use of thinner, organic solvents and strong acidic solvents are prohibited. 10-2 Regular Inspections ■... -
Page 36: Warranty And Repairs
Any replacement of consumables. If the product is repaired, remodeled, modified, or disassembled by a party other than Seedsware. This warranty covers only the product itself. And damages driven by the failure of our product and repairs and/or replacements done on-site will not be covered. -
Page 37: Others
*Product, specification and/or anything noted are subject to change for improvement without prior notice. By Phone +1-630-832-0438 (Business Hours: 9:00a.m. ~5:45p.m. CT) By E-mail sales@uscoamerica.com www.seedsware.co.jp/global/support/faq/ Edition August, 2016 USCO America Inc. 136 W. Valletts Street, Elmhurst, IL 60126 USA Phone: 630-832-0438/510-931-9046 E-mail: sales@uscoamerica.com... - Page 38 寸法許容差 改訂日 改 訂 内 容 ページ 担当 TOLERANCE DATE DESCRIPTION PAGE DESIGNED 呼び寸法 Nominal Dimensions 2014,08,04 新規図面登録 － M.Mitani L≦3 ±0.4 英語併記 2016,08,18 S.Yoshimoto ±0.48 *ｺﾈｸﾀ挿抜のため40mm以上確保願います。 － 3＜L≦6 English added ±0.58 Be sure to have 40mm or more space to be able to 6＜L≦10 10＜L≦18 ±0.7...
- Page 39 寸法許容差 改訂日 改 訂 内 容 ページ 担当 TOLERANCE DATE DESCRIPTION PAGE DESIGNED 呼び寸法 Nominal Dimensions 2013,06,20 新規図面登録 － M.Mitani L≦3 ±0.4 2015,03,16 NOTES 一部削除、寸法削除 － M.Mitani ±0.48 3＜L≦6 英語併記 2016,08,18 － S.Yoshimoto ±0.58 6＜L≦10 English added 10＜L≦18 ±0.7 18＜L≦30 ±0.84 ±1.0 30＜L≦50...
- Page 40 寸法許容差 改訂日 改 訂 内 容 ページ 担当 TOLERANCE DATE DESCRIPTION PAGE DESIGNED 呼び寸法 Nominal Dimensions 2013,05,08 新規図面登録 － S.Yoshimoto L≦3 ±0.4 英語併記 2016,08,18 S.Yoshimoto ±0.48 － 3＜L≦6 English added ±0.58 6＜L≦10 10＜L≦18 ±0.7 18＜L≦30 ±0.84 ±1.0 30＜L≦50 50＜L≦80 ±1.2 80＜L≦120 ±1.4 120＜L≦180...
- Page 41 寸法許容差 改訂日 改 訂 内 容 ページ 担当 TOLERANCE DATE DESCRIPTION PAGE DESIGNED 呼び寸法 Nominal Dimensions 2013,05,08 新規図面登録 － M.Mitani L≦3 ±0.4 2015,05,25 NOTES 一部削除、寸法削除 － M.Mitani ±0.48 3＜L≦6 英語併記 2016,08,18 － S.Yoshimoto ±0.58 6＜L≦10 English added 10＜L≦18 ±0.7 18＜L≦30 ±0.84 ±1.0 30＜L≦50...
