- Page 1 Operating Instructions „Easy Quick T2“ Towline Release Verified version: 27.02.2021 Version: 27.02.2021...
-
Page 2: Table Of Contents
2. Technical Data ............................3 3. Scope ................................3 4. Harness attachment ........................... 4 4.1. Attaching the Easy Quick T2 to the harness carabiners ............... 4 5. Towline attachment ............................ 5 6. Pre-flight check ............................7 7. Towline release............................7 8. -
Page 3: Technical Data
1. Manufacturer Dietmar Mathes Pfirsichweg 37a D-86169 Augsburg Tel: +49 (0) 821-54371145 Mobil: +49 (0) 176- 45698513 Webseite: www.schleppklinke.de Mail: dietmar.mathes@web.de 2. Technical Data Type: single-stage, two part harness towing release for paragliders Activation: sliding sleeve (clamping sleeve) max. towing capacity: 2000 N 1500 N –... -
Page 4: Harness Attachment
4.1. Attaching the Easy Quick T2 to the harness carabiners For safety reasons, the “Easy Quick T2“ towline release device can only be attached to the harness in the manner described in this document. For this purpose, the loops of each half of the towline release harness are looped through onto the carabiner (right riser shown in Fig 4.1) -
Page 5: Towline Attachment
Easy Quick towline release as part of a pre-flight check (On ground release check)! 5. Towline attachment The “Easy Quick T2” system can be connected quickly and easily to the towline. By pulling back the sliding sleeve the attachment lug is exposed. After threading the Easy Quick T2towline release line through the towline end fitting, hang the release line loop over the lug. -
Page 6: Pulled Back Sliding Sleeve
pulled back sliding sleeve attachment lug Figue 5.1: Pulled back sliding sleeve Figure 5.2: Release line attachment Version: 27.02.2021... -
Page 7: Pre-Flight Check
3. Easy Quick T2 sliding sleeve is accessible without any obstruction. 7. Towline release. The “Easy Quick T2” system is designed in such a way that it can be released on or off load. To do so, the sliding sleeve must be pulled back... -
Page 8: Care And Maintenance
The Easy Quick T2 towline release loop clears the lug and releases the towline (see chapter 5). Note: In order to keep the frictional forces low on Easy Quick towline release, recommended to tow only with a leader line that is equipped with a ring or metal link. -
Page 9: Safety Instructions And Liability
It is recommended to wear a full-face helmet to be protected from the towline recoil in case of a towline break. The use of the Easy Quick T2 towline release is at your own risk. The manufacturer refuses any liability for direct or indirect damages including consequential damages which could arise from using the towline release. -
Page 10: Aviation Equipment And The Environment
Paragliding is a nature sport - protect and conserve the resources of our planet. 10.2 Disposal "Easy Quick" includes the entire life cycle in its products, at the end of which is environmentally sound recycling. The materials used in a product require proper disposal. -
Page 11: Sample Test Certificate
Sample test certificate Version: 27.02.2021...
