- Page 1 MODEL TT-10/15 (T2) ELECTRON BEAM SOURCE POWER SUPPLY INSTRUCTION MANUAL Part Number 108-0100-2 Copyright © TELEMARK, 1990-1999 - All rights reserved November, 2000 www.telemrk.com Brand or product names are trademarks or registered trademarks of their respective companies...
- Page 2 Telemark TT-10/15 Power Supplies SAFETY WARNING HIGH (POTENTIALLY LETHAL) VOLTAGES ARE PRESENT WITHIN THESE MODULES. GREAT CARE MUST BE EXERCISED WHEN PERFORMING MAINTENANCE. HUMAN CONTACT WITH THE VOLTAGES CAN BE FATAL. Make sure that the input power is turned off before removing covers. Short all capacitors with a grounding hook.
- Page 3 Telemark representative, or if damage occurs through abuse, misuse, negligence, or accident. No charge will be made for repairs made at a Telemark service facility during the warranty period. Simply return the malfunctioning module, freight prepaid.
-
Page 4: Table Of Contents
Telemark TT-10/15 Power Supplies TABLE OF CONTENTS SAFETY WARNING WARRANTY USER RESPONSIBILITY LIST OF ILLUSTRATIONS GENERAL DESCRIPTION Functional Description ....1-1 System Components ....1-2 SPECIFICATIONS Control Module . - Page 5 Telemark TT-10/15 Power Supplies CONTROLS AND INDICATORS Control Module ..... . 4-1 HV/Power Cabinet ..... 4-4 Standard Sweep Control Module Chassis.
- Page 6 Telemark TT-10/15 Power Supplies LIST OF ILLUSTRATIONS Fig. Title Page Control General View ......1-2 Cabinet General View ......1-3 Single Source Vacuum Tank Grounding Installation.
-
Page 7: General Description
The High Voltage/Power Cabinet is produced to accommodate one, two or three sources. The number of Source Filament Control modules determines the number of sources that can be driven. There are two versions of the TT-10/15 control modules: Source 1 Control and source 2/3 Control. The Source 1 Control contains: High Voltage Control and digital indicators(There is only one HV control for the main Power supply.) -
Page 8: System Components
Telemark TT-10/15 Power Supplies System Components The TT-10/15 Electron Beam Power Supply consists of the following: HV Control / Source 1 Control Module Source 2 Control Module - 2 and 3 source systems only Source 3 Control Module - three source systems only... - Page 9 Telemark TT-10/15 Power Supplies Figure 1-B Cabinet General View GENERAL DESCRIPTION...
- Page 10 Telemark TT-10/15 Power Supplies GENERAL DESCRIPTION...
-
Page 11: Specifications
• Current cutback response Less than 100 microseconds HV/Power Cabinet • Input Power D models: 208/240 volts, 3-phase, 60 Hz. TT-10: 50 amps. (plus 15A for control circuitry) TT-15: 60 amps. E models: 380/415 volts, 3-phase, 50 Hz. TT-10: 40 amps. -
Page 12: Filament Transformer
Telemark TT-10/15 Power Supplies • Output current (maximum) TT-10: 1.0 amp. TT-15: 1.5 amps. Filament Transformer • Primary voltage 0 to 220 volts, 1-phase, 50/60 Hz • Secondary Power 8 volts at 50 Amps • Insulation rating, secondary to primary and core 22 kV DC Note: Other transformer voltages are available upon special request. -
Page 13: Installation
Telemark TT-10/15 Power Supply INSTALLATION Introduction Please see Figure 1-A, General View, Power Supply The TT Electron Beam Power Supply Control and Sweep are designed to be mounted in a standard 19 inch electronic instrument cabinet. Any suitable place on a vacuum system that has a standard 19 inch wide opening may be used. The control module could, for example, be set directly on a system cabinet top for easy access. - Page 14 Telemark TT-10/15 Power Supply Figure 3-A Single Source Vacuum Tank Grounding Installation NOTE - THE POWER SUPPLY MUST BE CONNECTED TO AN ISOLATED EARTH GROUND AS SHOWN IN FIG. 3-A AND 3-B, FAILURE TO CONNECT THE POWER SUPPLY TO AN...
- Page 15 Telemark TT-10/15 Power Supply Figure 3-B Multi Source Vacuum Tank Grounding Installation must be approximately 6 feet apart and the resistance between the rods (without the cable connection) should be 3 ohms or less. The resistance of the soil can be reduced by adding copper sulfate or salt water around the rods.
- Page 16 Telemark TT-10/15 Power Supply ground. If no building ground exists, rods must be driven in sufficient number and connected to the building structure to assure a suitable ground. Do not depend on water pipes for the system ground connection. It is safe to assume that, because of multiple joints and sealing compounds, water pipes will not be an earth ground.
-
Page 17: Inter-Module Connections
Telemark TT-10/15 Power Supply High Voltage Shielded Cable See Figure 3-C Approximately 20 feet of RG-213/U high voltage coaxial cable is provided for connection of the power supply output to the source transformer and is shipped connected to emission control module. - Page 18 Telemark TT-10/15 Power Supply Figure 3-D Source Inter-Module Connections INSTALLATION...
- Page 19 Telemark TT-10/15 Power Supply WARNING - ALL STATEMENTS REGARDING OPERATOR AND EQUIPMENT SAFETY ARE VOID IF THE EXTERNAL INTERLOCKS ARE NOT INSTALLED AS REQUIRED. This interlock is provided for the insertion of additional interlocks that the user may require to turn the source off. These may include crucible rotation interlocks, etc. The normally open contacts of each interlock should be connected in series and terminated through pins 1 and 6 of J1 should be closed for normal operation.
-
Page 20: Hv/Power Cabinet
Telemark TT-10/15 Power Supply The three position Emission Current Mode switch selects which signal controls the source current value. Remote control adjust is through J4 from a PLC (Programmable Logic Control). Hand held control using the optional hand held current control unit that plugs into... - Page 21 Telemark TT-10/15 Power Supply Figure 3-E Control Module Connections INSTALLATION...
- Page 22 3Ø 208/240V, 4 wire, 60Hz source. “E” models are to be connected to a 3Ø 380/415V, 5 wire, 50Hz source. (“D” models; TT-10: 40A, TT-15: 50A. “E” models; TT-10: 40A, TT-15: 50A), each hot line is protected by circuit breakers, located on the front panel of HV/Power cabinet.
- Page 23 WARNING: Leaving the common ungrounded at the tank could damage the Sweep. TT-10/15 POWER SUPPLY CONNECTION - J1 The interface between the Controller and the supply is the special 15-P Male D-Sub to 25-P female D-Sub. The Controller option allows Electron-Beam Power Supply operation via the Sweeper’s special Controller/Joystick Module.
- Page 24 Telemark TT-10/15 Power Supply REMOTE PATTERN-SELECTION CONNECTION - J2 The customer may control external selection of the Sweep Select Module’s pattern banks, accomplished through this male 9-pin D-sub. An indexer or computer may be used in conjunction with the Sweep Select Module to choose which of its four pattern-banks is active.
- Page 25 Telemark TT-10/15 Power Supplies CONTROLS AND INDICATORS Control Module Please refer to Fig. 4-A, Control Module Front View. The front panel controls are grouped according to the three basic functions to be controlled. Lines on the panel enclose the controls and indicators associated with each group.
- Page 26 Telemark TT-10/15 Power Supplies High Voltage Controls and Interlock Indicators HIGH VOLTAGE, OFF - The on/off function is provided by a pair of push-buttons on the main control panel High Voltage group. The off button lights when High Voltage power is off.
- Page 27 Telemark TT-10/15 Power Supplies The state of the High Voltage interlocks is continuously checked. If any condition is not correct, the corresponding indicator will not be lit. The High Voltage Indicator lights are (left to right): AIR/CAB - A pressure sensor is used to insure proper airflow in the tube box.
- Page 28 Special circuitry protects the power supply, and may cause interruption of the power supply at a setting exceeding the maximum rated current (1 Amp for TT-10, 1.5 Amp for TT-15) cutback. The state of all Source interlocks is continuously checked. If any condition is not correct, the corresponding indicator will not be lit.
-
Page 29: Standard Sweep Control Module Chassis
Reset must be pressed on control unit to restart system. Standard Sweep Control Module Chassis See figure 4-C ON/OFF SWITCH—-Provides Sweeper power, not TT-10/15 Controller power. MODE (CONTROL / SWEEP SELECT) SWITCH—-selects between Control on the left and Sweep Select on the right. -
Page 30: Xy Sweep Controller (With Memory Module) (Optional)
Telemark TT-10/15 Power Supplies Figure 4-C Control Module Chassis, Front View 3 & 4 POSITION L.E.D.s—-show the relative position of the beam (in two axis—Lateral [left & right] and Longitudinal [near & far]) in the pocket. NOTE: DIRECT OBSERVATION OF BEAM POSITION SHOULD BE MADE. -
Page 31: Standard Sweep Select Module (Memory Module)
Telemark TT-10/15 Power Supplies Figure 4-D Sweep Module, Front View With the MODE switch in the TRIANGLE setting, the Lateral and Longitudinal Amplitudes and Frequencies of the beam are set with the corresponding knobs. The Joystick is used to position the beam. The resulting beam movement is in a diamond(s) pattern. - Page 32 Telemark TT-10/15 Power Supplies Figure 4-E Sweep Select Module, Front View MANUAL/AUTO SWITCH - Changes the control of the Sweep Select module from the knob on the front panel (2) to the remote input from J2 on the back panel. Note: in AUTO mode,...
- Page 33 Telemark TT-10/15 Power Supplies With the MODE switch in the TRIANGLE setting, the Lateral and Longitudinal Positions, Amplitudes, and Frequencies of the beam are set with the corresponding knobs. The resulting beam movement is in a diamond(s) pattern. 5 & 6 POSITION - Moves the beam (in two axis—Lateral [left &...
- Page 34 Telemark TT-10/15 Power Supplies 4-10 CONTROLS AND INDICATORS...
-
Page 35: Operation
Telemark TT-10/15 Power Supplies OPERATION Introduction This section describes the normal operating procedures for the Telemark TT Power Supplies. Preliminary Precautions Before turning on the system for the first time, it is essential that the following conditions are observed: The ground system is correctly installed as described in detail in Chapter 3 (Installation), System Grounding Practice. -
Page 36: Operation
Telemark TT-10/15 Power Supplies Depress the Controller Reset, to reset interlocks. It will take about 30 seconds for the HV/Power Cabinet fans to reach normal speed. Once the fans have reached normal speed the air switch will close, then the AIR/CAB interlock can be reset. -
Page 37: Xy Sweep (With Memory Module) Setup
Telemark TT-10/15 Power Supplies XY Sweep (with Memory Module) Setup The following is the procedure to set the Sweep Module Controller/Joystick Module for initializing operating levels. (This may be done with the Module plugged into the front panel or extended by cable.) With the HV/Emission off, place the front-panel switch “control/sweep select”... -
Page 38: Xy Sweep With Memory Module Operation
Telemark TT-10/15 Power Supplies XY Sweep with Memory Module Operation The system is now operational. The position of the E-beam in the crucible can be moved or swept by adjustment of the Sweeper removable module controls. Patterns are determined using the Controller/Joystick Module while watching the E-beam in the vacuum tank’s EB gun crucible.
