Summary of Contents for Booth TRM9HC
- Page 1 Product Manual TRM9HC Water Cooler Part Number 3B8108 Issue OR...
-
Page 2: Table Of Contents
Operate the unit within (ambient) operating temperatures; 16⁰C to 38⁰C. Introduction The TRM9HC is a dry block chiller designed to provide chilled still water by passing water through a stainless steel water coil in the “cold block”. The TRM9HC in standard configuration is designed as a single product chiller with an option of two depending on targeted drink temperature. - Page 3 Introduction and Specification Specification Dimensions 470mm(W) Compressor Cubigel NLY12RAa 425mm(D) 260mm(H) Dry Weight 27Kg This product contains fluorinated greenhouse gas with a GWP of 3 in an Supply 220-240Vac/50Hz hermetically sealed system Climatic Class Power Refrigerant 168W 290a 55g Consumption (0.055Kg)
-
Page 4: Installation
Installation and Commissioning The TRM9HC unit should be located on a firm level surface capable of holding the weight, as close to the dispense point as possible, and orientated so that the on/off switch and Eliwell control are accessible. Ensure at least 100mm of space is left all- round the unit to allow adequate airflow for cooling. -
Page 5: Cleaning
Cleaning Important: The frequency of the following cleaning procedures should be determined locally and may vary depending on machine usage and environmental conditions. Warm water should be no higher than 45°C. After any cleaning procedure, dispense 1 litre of water from each tap to ensure any cleaning residue is flushed out. - Page 6 Cleaning General Cleaning - Parts not in contact with food products Important: It is recommended that the procedure should be performed at least every 6 months. Condenser. At regular intervals, determined by local environmental conditions, the condenser should be thoroughly cleaned with a small stiff brush and/or a vacuum cleaner. Do not use screwdrivers or other sharp implements which may puncture the fins.
-
Page 7: Schematics
Electrical Schematic... - Page 8 Water Schematic...
-
Page 9: Fault Finding
Fault Finding Prior to any fault finding, please ensure all product connections to the chiller are sound and that the incoming supply is turned on. Also ensure that all electrical connections to the chiller and in the chiller are secure and in good condition, the power is on and that the chiller has had adequate time to reach operating temperature. -
Page 10: Replacement Parts
Spare Parts 3B7692 Fans 1A6794 Eliwell Controller 1B6430 Power Switch... -
Page 11: Removal, Transportation And Disposal
Removal, Transportation and Disposal Important: Before removal from the installation, ensure all electrical, product and gas connections are disconnected. Disposal of Scrap Units It is illegal to simply scrap a refrigeration unit. Before a unit can be scrapped it must first have the gas removed by a specialist using special equipment. - Page 12 Booth Dispensers Ltd, Moor Park Avenue, Blackpool, Lancashire, FY2 0LZ, UK +44 1253 501800...
