- Page 1 Product Manual EXL651 Still and Carbonated Water Cooler Part Number 3B6220 Issue A (24/05/16)
-
Page 2: Table Of Contents
Disposal Introduction The EXL651 is an ice-bank cooler designed for installation in a cupboard under a worktop, and incorporates two water cooling coils. It can either be installed in conjunction with a separate ambient carbonator, the EXL171, to provide still and carbonated water, or on its own to provide still water only. -
Page 3: Installation & Commissioning
Templates are provided to help in the location of ventilation openings that need to be • cut into the cabinet base, and kick space, and are designed to allow the EXL651 to be installed against the left hand side of the cabinet, viewed from the front. - Page 4 Installation and Commissioning Place the EXL651 into the cabinet with the rubber bump-stops to the rear, aligning the • left side to the left side of the cabinet. Push in until the bump stops contact the rear of the cabinet. The exhaust grill on the bottom of the machine will now align with the cut- out in the base of the cabinet.
- Page 5 Installation and Commissioning...
- Page 6 Installation and Commissioning All dimensions are based around a standard 600mm wide kitchen cabinet. Top View 36 32 Front View Front View Extended Cutout Standard Cutout...
-
Page 7: Spare Parts
Spare Parts Item No Description Part No High Side Protector 3B3963 Axial Fan 1B5514 Agitator Assembly 1A5237 Control Thermostat 1A4714... -
Page 8: Fault Finding
Fault Finding Prior to any fault finding, please ensure all water connections to the chiller are sound and that the incoming water supply is turned on. Also ensure that all electrical connections to the chiller and in the chiller are secure and in good condition, the power is on and that the chiller has had adequate time to reach operating temperature. -
Page 9: Wiring Schematic
Wiring Schematic FUSED MAINS PLUG CONDENSOR FANS AGITATOR IEC CONNECTOR CONTROL THERMOSTAT CARBONATOR CONNECTOR COMPRESSOR NOTE SOME EARTH HIGH SIDE CABLES (G/Y) PROTECTOR OMITTED FOR CLARITY... -
Page 10: Removal, Transportation
It is illegal to simply scrap a refrigeration unit. Before a unit can be scrapped it must first have the gas removed by a specialist using special equipment. Please contact Booth Dispensers Ltd., who will be happy to provide a quotation for disposal.
