Table of Contents
3. Packing list
Model No.
05.SLK.T6B
05.SLK.T6B.2P
05.SLK.EXT.2M
05.SLK.END.10M
expansion bolts & screws , M4x30
05.SLK.FIX.KIT
Cable tie, white Nylon 5x150mm
4. Warning
1- Please follow the instructions for installation.
2- Do not modify the fixture or the components.
3- Rated voltage 180-265VAC, 50/60Hz.
4- Do not use the product in environments with high
temperature or high humidity.
5- The product must be installed by professional technicians
and the mains power must be isolated before installation.
4
Description
Quantity
Shaft light
Fixing bracket
Extension cable, L=2m
End cable, L=10m
Rawl plug, Ø6
6x
12x
5x
1x
15x
10x
10x
Manufactured under ISO 9001
User Manual
Shaft light 05.SLK.T6B.12W
Shaft light 05.SLK.T6B.16W
Version UM.SLK.T6B.17D
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Weco 05.SLK.EXT.2M
Summary of Contents for Weco 05.SLK.EXT.2M
- Page 1 3. Packing list Model No. Description Quantity Shaft light 05.SLK.T6B User Manual Fixing bracket 05.SLK.T6B.2P 05.SLK.EXT.2M Extension cable, L=2m 05.SLK.END.10M End cable, L=10m Shaft light 05.SLK.T6B.12W expansion bolts & screws , M4x30 Shaft light 05.SLK.T6B.16W Rawl plug, Ø6 05.SLK.FIX.KIT Cable tie, white Nylon 5x150mm 4.
- Page 2 1. Installation 2. Technical features 1- The installation should begin at the top of the shaft and work downwards. 2- Install the extension cables ‘05.SLK.T6B.EXT.2M’ on one side of each shaft light ’05.SLK.T6B’. 3- Install the brackets 05.SLK.T6B.2P on both side of the aluminium housing.
