Summary of Contents for Genebre 5971
- Page 1 Genebre Building. Av. de Joan Carles I, 46-48 08908 L'Hospitalet de Llobregat. Barcelona (Spain) genebre@genebre.es - www.genebre.es INSTALLATION, OPERATION AND MAINTENANCE MANUAL Declutchable Gear Box for Emergency Control GENEBRE Ref.: 5971 GENEBRE S.A. LAST UPDATE: 16/07/2020 UPDATE NUMBER: 0...
- Page 2 Genebre Building. Av. de Joan Carles I, 46-48 08908 L'Hospitalet de Llobregat. Barcelona (Spain) genebre@genebre.es - www.genebre.es Installation, operation and maintenance instructions 1. Assembly Drawing .................. 3 …………………………………………………………………... 3 1.1 Parts List ……...…………………..............4 2. Storage ………..……............. 4 3. Installation instructions 3.1 Preparation...
- Page 3 Genebre Building. Av. de Joan Carles I, 46-48 08908 L'Hospitalet de Llobregat. Barcelona (Spain) genebre@genebre.es - www.genebre.es 1. Assembly drawing 1.1 Parts list Nº Name Material Surface Treatment Body Epoxy coating Adjust bolts AISI 304 ------ Gear Carbon Steel ------...
- Page 4 Genebre Building. Av. de Joan Carles I, 46-48 08908 L'Hospitalet de Llobregat. Barcelona (Spain) genebre@genebre.es - www.genebre.es 2. Storage During storage it is recommended to keep the Gear Operator in the same position as delivered, with the included protective wrapping to avoid damages or dirt accumulation. The wrap must not be removed until the operator is to be installed.
- Page 5 Genebre Building. Av. de Joan Carles I, 46-48 08908 L'Hospitalet de Llobregat. Barcelona (Spain) genebre@genebre.es - www.genebre.es 3.4 Adjustment of the regulation screws The unit is already adjusted in the factory at 0º and 90º, however it could be necessary a later adjustment in Open and/or Close position of the valve.
- Page 6 Genebre Building. Av. de Joan Carles I, 46-48 08908 L'Hospitalet de Llobregat. Barcelona (Spain) genebre@genebre.es - www.genebre.es Lock Device Handle 4.3 From Automatic to Manual 1-Pull upwards the lock device (part.9) and turn the handle (part.10) upwards. 2-Let the lock device (part.9) down and move the handle (part.10) to position it.
- Page 7 Genebre Building. Av. de Joan Carles I, 46-48 08908 L'Hospitalet de Llobregat. Barcelona (Spain) genebre@genebre.es - www.genebre.es 4.4 Torques The maximum allowable output torque of the gear operator is as listed below: Torque (Nm) Ref. Input Output 5971 04 5971 05...
- Page 8 Genebre Building. Av. de Joan Carles I, 46-48 08908 L'Hospitalet de Llobregat. Barcelona (Spain) genebre@genebre.es - www.genebre.es 5. Maintenance operations Gear operators are designed so that they do not need any lubrication and/or periodical maintenance during their life cycle. However, periodical checks will be useful to extend the service life of the product.
